INSTRUCTIONS FOR USE
Test pressure sensor cable, for pressure sensor socket
Test cable, for ARGON socket
Pressure reducers, adjustable
Test hose, for argon connector
Test probe, Ø 2.3 mm, for ARGON socket
Blockage tool, for test probe
Maintenance set, for ESG-300 System
ESG-300 SYSTEM
Simulator, for foot switch
Simulator, for sparks
Load resistor, 3000 Ω
Load resistor, 4000 Ω
WA80003S
WA80008S
WA80004S
WA80009S
WA80005S
WA80010S
WA80006S
WA80011S
WA80007S
WA80012S
Test tools
WA80013S
WA80014S
WA80015S
WA80016S
WA80017S

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ESG-300 and is the answer not in the manual?

Questions and answers

Related Manuals for Olympus ESG-300

Summary of Contents for Olympus ESG-300

  • Page 1 Test hose, for argon connector Test probe, Ø 2.3 mm, for ARGON socket Test pressure sensor cable, for pressure sensor socket Blockage tool, for test probe Load resistor, 3000 Ω Load resistor, 4000 Ω Maintenance set, for ESG-300 System WA80003S WA80008S WA80013S WA80004S WA80009S...

  • Page 3: Table Of Contents

    3.7 Test probe, Ø 2.3 mm, for ARGON socket ..............14 3.8 Test pressure sensor cable, for pressure sensor socket ..........14 3.9 Blockage tool, for test probe ...................15 3.10 Load resistors ........................15 3.11 Maintenance set, for ESG-300 system ................16 3.12 Symbols ........................16 3.13 Warranty ........................16 4 Use.............................17 5 Maintenance ........................18...

  • Page 5: General Information

    These instructions for use contain a description of the maintenance test tools for ESG-300 and APU-300 that are required for the annual safety check of the ESG-300 system. These instructions for use do not contain information on performing the safety check.

  • Page 6: Name Plates

    The products are provided with name plates for identification. When products are small, the name plates are attached to their packaging. The following figure illustrates the structure of the name plates. OLYMPUS WINTER & IBE GmbH Xxxxxxxxxxxxxxxxxxxx Kuehnstr. 61 22045 Hamburg, Germany...

  • Page 7: Safety Information

    The blockage tool is intended for leakage tests of the APU-300 system. Load resistors WA80015S, WA80016S The load resistors are intended to perform peak voltage tests of the ESG-300 system. Maintenance set, for ESG-300 system WA80017S The maintenance set for the ESG-300 system is intended for performing maintenance work...

  • Page 8: User Qualification

    The following safety messages apply to the general handling of the products. This information is to be supplemented by the dangers, warnings and cautions given in the maintenance manual of the ESG-300 system and in the instructions for use of any product being used with these products.
  • Page 9 Safety information • Before connecting the products to the devices, make sure the electrical power supply of the devices is switched off. • Before use, check all cables and connectors for damage. Only use undamaged products. Risks of injury due to tripping hazards or due to falling parts •...

  • Page 10: Product Description

    Each item is delivered with these instructions for use. • Before use, check that all items listed below are available. • Contact an Olympus representative or an authorized service center if any items are missing or damaged. WA80003S: Simulator, for foot switch...

  • Page 11: Simulator, For Foot Switch

    The foot switch simulator is used for simulating a foot switch when testing and calibrating the ESG-300 system. - The foot switch plug connects the simulator to the ESG-300. - When switching on the power switch, activation of the coagulation pedal of a foot switch can be simulated.

  • Page 12: Test Cable, For Argon Socket

    2) Banana plug The test cable is intended to connect the APU-300 to the sparks simulator for functional tests of the ESG-300 system. - The plug connects the test cable to the ARGON socket of the APU-300. - The banana plug connects the test cable to the red connector of the sparks simulator.

  • Page 13: Test Hose, For Argon Connector

    Product description - The quick release coupling connects the pressure reducer to the APU‑300 or to a flow meter. - The pressure regulator adjusts the outlet pressure that is needed for the respective test. - The input pressure gauge displays the pressure of the argon gas cylinder. - The outlet pressure gauge displays the outlet pressure of the pressure reducer.

  • Page 14: Test Probe, Ø 2.3 Mm, For Argon Socket

    Product description 3.7 Test probe, Ø 2.3 mm, for ARGON socket WA80012S 1) Outlet 2) Plug for ARGON socket The test probe is used for testing and calibrating the APU-300. - The plug connects the test probe to the APU-300. - The outlet is connected to the blockage tool.

  • Page 15: Blockage Tool, For Test Probe

    1) Red connector 2) Black connector The load resistors are used to perform peak voltage tests of the ESG-300 system. - The red connector connects the load resistor to the ESG-300. - The black connector connects the load resistor to an electrosurgical analyzer.

  • Page 16: Maintenance Set, For Esg-300 System

    Product description - WA80016S: load resistor, 4000 Ω 3.11 Maintenance set, for ESG-300 system WA80017S The maintenance set for the ESG-300 system contains the following products which are described above: - WA80003S - WA80004S - WA80005S - WA80011S - WA80012S...

  • Page 17: Use

    4 Use The products are used for the annual safety check of the electrosurgical generator ESG-300 and the argon plasma coagulation unit APU-300. • For detailed information on performing the safety check refer to the maintenance manual of the ESG-300 system.

  • Page 18: Maintenance

    • For WA80007S, WA80008S, WA80010S: Check the O-rings in the gas cylinder connections for damage. 5.3 Functional test of the sparks simulator A functional test of the sparks simulator (WA80004S) must be performed annually. • Refer to the maintenance manual for the ESG-300 system.

  • Page 19: Packaging, Transport And Storage

    Packaging, transport and storage 6 Packaging, transport and storage 6.1 Packaging and transport For packaging and transport, observe the following instructions: • If possible, use the original cardboard packaging for the transport of the product. • Wrap each product individually to prevent abrasion and impact during transport. •...

  • Page 20: Repair, Shipment And Disposal

    7 Repair, shipment and disposal 7.1 Repair There is no repair service. • Do not send the product to Olympus for repair. • Do not attempt to repair or modify the product. 7.2 Shipment When sending products to an authorized service center for warranty claims, note the following.

  • Page 21: Ordering Information

    Test probe, Ø 2.3 mm, for ARGON socket WA80012S Test pressure sensor cable, for pressure sensor socket WA80013S Blockage tool, for test probe WA80014S Load resistor, 3000 Ω WA80015S Load resistor, 4000 Ω WA80016S Maintenance set, for ESG-300 system WA80017S...

  • Page 22: Technical Data

    Technical data 9 Technical data 9.1 Specifications 9.1.1 Simulator, for foot switch (WA80003S) Size Width ..........................112 mm Height ..........................37 mm Depth ..........................62 mm Weight ..........................0.3 kg Cable length .......................1500 mm Electrical data Nominal voltage ......................5 V DC Nominal current ......................10 mA Protection class (housing) ....................
  • Page 23 Technical data 9.1.4 Pressure reducers, adjustable, 0-10 bar (WA80006S, WA80007S, WA80008S, WA80009S, WA80010S) Size Width ..........................2400 mm Height ...........................390 mm Depth ..........................360 mm Weight ..........................2.5 kg Connections Inlet connection, WA80006S ..................DIN 477-6 Inlet connection, WA80007S .................. DIN 477-10 Inlet connection, WA80008S ..................CGA-580 Inlet connection, WA80009S ..................BS 341-3 Inlet connection, WA80010S ..................
  • Page 24 Technical data Pressure Inlet pressure ......................max. 2.5 bar Expected service life WA80012S ..................... 50 mating cycles 9.1.7 Test pressure sensor cable, for pressure sensor socket (WA80013S) Size Weight ..........................0.2 kg Cable length .......................2100 mm Electrical data Nominal voltage ......................5 V DC Nominal current ........................

  • Page 25: Ambient Conditions

    Technical data 9.2 Ambient conditions Operating conditions Ambient temperature ..............10 to 40 °C (50 to 104 °F) Relative humidity ................30 to 80 %, non-condensing Storage conditions Temperature ................. -25 to 60 °C (-30 to 140 °F) Relative humidity ......................10 to 85 %...
  • Page 28 W9213430_01 2017-11-21 © Copyright 2017 Olympus Winter & Ibe GmbH...
