- Page 1 This Owner's Manual is provided and hosted by Appliance Factory Parts. BROAN GSH3K Owner's Manual Shop genuine replacement parts for BROAN GSH3K Find Your BROAN HVAC Parts - Select From 1309 Models -------- Manual continues below --------...
- Page 2 HEPA Filtration, GSHH3K Fresh Air and *Patents pending Energy Recovery Ventilation* GSEH3K RESIDENTIAL USE ONLY. INSTALLER: LEAVE THIS MANUAL WITH CONSUMER. REGISTER YOUR PRODUCT ON LINE AT: www.broan.com/register For additional information - visit www.Broan.com 05690 rev. 5 Broan-NuTone LLC 99043224...
-
Page 3: About This Manual
NOTE: Indicates supplementary information needed to fully complete an instruction. We welcome any suggestions concerning this manual and/or the product, or ways to better serve you. Please forward all correspondence at the address below: Broan-NuTone LLC Indoor Air Quality Mkt. 926 W. State St.,... -
Page 4: Table Of Contents
TABLE OF CONTENTS ..........4 BOUT THESE UNITS ............5-8 ONTROLS 2.1 Main Switch..............5 2.2 Operating ACCGSC1 Controller ........5 2.3 Operating 40425 Controller .........6-8 .............9-12 AINTENANCE 3.1 Semi-annual Maintenance .........9-11 3.2 Annual Maintenance .............11 3.3 Optional Alpine/pine Filter..........12 ..........13 ROUBLESHOOTING ............14 ARRANTY - 3 -... -
Page 5: About These Units
1. ABOUT THESE UNITS WARNING TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSON(S) OBSERVE THE FOLLOWING: 1. This unit is intented for residential installation only. 2. Installation must be done in accordance with all applicable codes and standards, including fire-rated construction codes and standards. -
Page 6: Controls
2. CONTROLS 2.1 M WITCH All units are equipped with a 3-position main switch, located on the front panel. The unit is intented for use with a wall controller (provided, see below). The main switch is to remain in either the “OFF” or “Normal/Remote” modes ONLY. The “Normal/Remote” mode allows the homeowner to operate the product from the wall controller (supplied with the unit), typically mounted near a thermostat or other convenient location. -
Page 7: Operating 40425 Controller
2. CONTROLS (CONT’D) 2.3 O 40425 C PERATING ONTROLLER The included wall control 40425 is intented for GSHH3K and GSEH3K units only. The wall control is in OFF mode when power is applied for the first time. The mode does not change following a power failure. 2.3.1 40425 C ONTROLLER ESCRIPTION... -
Page 8: Off Mode
2. CONTROLS (CONT’D) 2.3.2 U 40425 C ’ SING ONTROLLER CONT ECIRCULATION CIRC The unit recirculates air. However, The unit is off. every hour, the unit exchanges The outdoor temperature* air for 6 minutes so that is not displayed. it can obtain a reading of the outdoor temperature*. - Page 9 2. CONTROLS (CONT’D) 2.3.3 40425 W ONTROLLER ONFIGURATION See the configuration table below for the list of configuration parameters. Press the Menu button for 3 seconds to enter or exit the configuration menu. NOTE: The wall control automatically saves any changes and exits the configuration menu if no button is pressed within the next 60 seconds.
-
Page 10: Maintenance
3. MAINTENANCE WARNING Risk of electrical shocks. Before performing any maintenance or servicing, always disconnect the unit from its power source. 3.1 S ANNUAL AINTENANCE ESSENTIAL Your wall controller (ACCGSC1 or 40425) tells you when to perform this maintenance when the Filter Maintenance light is flashing. Otherwise, maintenance should be performed every 6 months to ensure your unit proper operation for years to come. - Page 11 3. MAINTENANCE (CONT’D) 3.1 S ’ ANNUAL AINTENANCE ESSENTIAL CONT Using your thumbs, push on the prefilter side to disengage it from the filter cartridge. Then, slide it out of the filter cartridge and discard it. Install the new prefilter by reversing this operation. VD0092 VD0093 1) Filter cartridge...
-
Page 12: Semi-Annual Maintenance
3. MAINTENANCE (CONT’D) 3.1 S ’ ANNUAL AINTENANCE ESSENTIAL CONT For HEPA Filtration, Fresh Air and Energy Recovery model GSEH3K only CAUTION The GSEH3K energy recovery core cannot be washed with water. Slide out the two core filters (item 1) from the energy recovery core and wash them under hot water with mild soap. -
Page 13: Optional Alpine/Pine Filter
3. MAINTENANCE (CONT’D) 3.3 O PTIONAL LPINE PINE ILTER During pollen season, or as needed, remove the assembled hood from its backplate by removing its 2 retaining screws. VD0124 screw Then, slide out the optional Alpine/pine filter and clean it under water. Let dry before reinstalling it on the assembled hood. -
Page 14: Troubleshooting
Refer servicing to qualified service personnel. If the unit seems not working properly, call your installer or the nearest approved Service Center. You can also reach our Customer Service Departments or Technical Support listed below. Broan-NuTone LLC • Customer Service Department: Telephone: 1-800-558-1711 Fax: 1-800-356-5862 •... -
Page 15: Warranty
This warranty gives you specific legal rights and you may also have other rights, which vary from state to state. This warranty supersedes all prior warranties. In order to qualify for a warranty claim, the owner of a Broan-NuTone WHOLE-HOUSE AIR FILTRATION SYSTEM must have the model and serial number along with a proof of the original purchase date.
