INSTALLATION REQUIREMENTS
SMEG S.p.A. thank you for choosing this product.
Pre-installation operations to be performed by the client:
Room preparations, as needed.
Pre-installation of properly operating systems, in compliance with the requirements and
regulations in force.
Positioning of the machine.
Refer to this manual for detailed instructions on the steps mentioned above.
SMEG S.p.A. declines responsibility for damage to persons or property resulting from improperly
regulated or defective systems or for any installation of the appliance and/or accessories performed by
unauthorized personnel.
Any operation performed on the appliance by unauthorized personnel will invalidate the warranty.
05
03/01/2024
04
25/03/2022
03
17/12/2020
02
01/07/2019
01
01/06/2018
DOC. REV.
INSTALLATION REQUIREMENTS
WD6010 – GW6010
WD7010 – GW7010
WD7015 – GW7015
Requirements for models equipped with softener, ref. optional accessory code "WD-DEC10", added.
IP21 rating of devices and fittings for accessories specified.
Updated ref. and dimensions of WD 7015TECO models added. WD7015TECO models have distinctive
dimensional characteristics.
Revisions:
-
Addition covering automatic loading and unloading systems for WD7015, CB7015 models.
-
Notes relating to optional "air and steam shutter" component.
-
Addition for WD6010 models with steam connection, WD6010V and derived models.
-
Revision of steam flow-rate required by devices.
Revision for internal use.
First issue, including models WD7015, GW7015.
DATE
WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015
NOTE
Pag. 1 - 24
Advertisement
Table of Contents
Related Manuals for Smeg WD6010
Summary of Contents for Smeg WD6010
- Page 1 Refer to this manual for detailed instructions on the steps mentioned above. SMEG S.p.A. declines responsibility for damage to persons or property resulting from improperly regulated or defective systems or for any installation of the appliance and/or accessories performed by unauthorized personnel.
-
Page 2: Table Of Contents
WD7015 - GW7015: DIMENSIONS - AUTOMATIC LOADING/UNLOADING SYSTEM “CB7015” ........21 6.4.1 CB7015 ................................. 21 6.4.2 WD7015 - CB7015, OVERALL DIMENSIONS CALCULATION .................. 22 INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 2 - 24... -
Page 3: Electrical System Requirements
Refer to the Technical Data sheet for the device's electrical connection specifications. INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 3 - 24... -
Page 4: Technical Data
8°C - 60°C ( 46°F - 140°F) Max. hardness: 0.5 °f (0ppm CaCO3) Max. conductivity / pH: 30 µS/cm / 5÷8 pH TDS max 40 mg/litro INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 4 - 24... -
Page 5: Electrical Connections
Electrical protection required: 3P+N, 32 A 3P+N, 40 A Cable and section: 5 x 6 mm2 5 x 10 mm2 Power: 13 kW 20 kW INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 5 - 24... - Page 6 30 lt/min 70 lt/min Max. height: 700 mm Max. temperature: 95 °C (203°F) * On WD7015TECO models the wall drain is always possible. INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 6 - 24...
-
Page 7: Net Weight
[The weight values shown here are appropriately increased to consider the presence of optional components, the maximum water load, the maximum processable load in the tank and the presence of detergent tanks]. INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 7 - 24... -
Page 8: Technical Data - Automatic Loading And Unloading Systems - Cb7015
[Installation environment reference conditions: prescribed limits for the washer disinfector] Interno IP RATING IPX3 HEAT EMISSION INTO THE ROOM (Emissione di calore trascurabile) INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 8 - 24... -
Page 9: General Notes
Wall drain hose connection, if the drain pump (optional) is fitted: the end of the drain hose must be fixed permanently to the hose fitting, using hose clamps. INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 9 - 24... -
Page 10: Access To The Electrical Cable, To The Water Charging Hoses And To The Steam Connections
Exceptions are models WD6010T and GW6010T, for which cable and water hoses are only accessible from below. On all “V” Steam models of the WD6010 and GW6010 series (e.g. “WD6010V”): the steam connections are only accessible from below. -
Page 11: Air And Steam Shutter
Contact the authorised after-sales service for information and explanations (refer to optionals “ESVC10” and “ESVC15”). Air and steam shutter - guideline illustration of ESVC optionals INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 11 - 24... -
Page 12: Wd6010 - Gw6010 Dimensions
4 WD6010 – GW6010 DIMENSIONS 4.1 6010 - DOUBLE DOOR VERSION INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 12 - 24... -
Page 13: 6010 - Single Door Version
4.2 6010 - SINGLE DOOR VERSION INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 13 - 24... -
Page 14: 6010 - Connections
4.3 6010 - CONNECTIONS INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 14 - 24... -
Page 15: Wd7010 - Gw7010 Dimensions
5 WD7010 – GW7010 DIMENSIONS 5.1 7010 - DOUBLE DOOR VERSION INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 15 - 24... -
Page 16: 7010 - Single Door Version
5.2 7010 - SINGLE DOOR VERSION INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 16 - 24... -
Page 17: 7010 - Connections
5.3 7010 – CONNECTIONS INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 17 - 24... -
Page 18: Wd7015 - Gw7015 Dimensions
6 WD7015 – GW7015 DIMENSIONS 6.1 WD7015 - GW7015 – CONNECTIONS INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 18 - 24... -
Page 19: Wd7015 - Gw7015: Dimensions - Single Door Version
6.2 WD7015 - GW7015: DIMENSIONS – SINGLE DOOR VERSION INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 19 - 24... -
Page 20: Wd7015 - Gw7015: Dimensions - Double Door Version
6.3 WD7015 - GW7015: DIMENSIONS – DOUBLE DOOR VERSION INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 20 - 24... -
Page 21: Wd7015 - Gw7015: Dimensions - Automatic Loading/Unloading System "Cb7015
L2 - WIDTH [mm] H - HEIGHT [mm] CB7015L1 CB7015L2 1666 CB7015L3 2497 CB7015L1T CB7015L2T 1666 CB7015L3T 2497 CB7015U1 CB7015U2 1666 CB7015U3 2497 INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 21 - 24... -
Page 22: Wd7015 - Cb7015, Overall Dimensions Calculation
Two multi-purpose trolleys (one per side) - 2x916= 1832 mm e. Two operator manoeuvring Spaces “S” (one on each side) - 2x600=1200 mm Resulting total: 7362 mm (7.4 metres). INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 22 - 24... - Page 23 The figure shows a schematic view of the detergents storage area “DET. AREA”, which must be provided in cases in which unit CB7015 is not equipped with an integral tank compartment. INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 23 - 24...
-
Page 24: International Customers
Via Leonardo da Vinci, 4 42016 Guastalla – Reggio Emilia - Italy www.smeg-instruments.com International Customers Please contact your Local Smeg Distributor or write an email to service.instruments@smeg.it INSTALLATION REQUIREMENTS WD6010 - GW6010 - WD7010 - GW7010 - WD7015 - GW7015 Pag. 24 - 24...
