GLOBAL FURNITURE ALLIANCE U2200-PCRLS Assembly Instruction

Model:
U2200-PCRLS
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts that may have come loose inside the carton during shipment
PARTS LIST:
NO. DESCRIPTION
A
Seat Body
B Left Backrest
C Console Backrest
Right Backrest
D
E Left wing
Right wing
F
Step 1:
Important:
1. Attach the Backrest (B/D) to the Seat (A).
2. Attach the Left/Right Wings (E/F) to the Left/Right
side of the Backrest (B/D).
E B
Step 3:
Important:
1. Connect the power wire under the Armrest frame to the power source through
out the Transformer (2) and The Plug (1).
2. Open the footrest or move the headrest by pressing the power button on/off.
ASSEMBLY INSTRUCTION
SKETCH Q'TY
1 PC
1 PC
1 PC
1 PC
1 PC
1 PC
F
D
A
#2
#1
OFF & ON
Description:
HARDWARE LIST:
NO. DESCRIPTION
Plug
1
2
Transformer
3
Screw with handle
Step 2:
Important:
Take out the Knob Screws (3) at the Console Backrest (C ) then
place the Console Backrest (C) to right location and attach to the
Seat (A) by turning the Knob Screws (3) clockwise.
POWER CONSOLE RECLINING LOVESEAT
DESCRIPTION SKETCH
5/16"*50mm
C
POWER STRIP
INSIDE OF STORAGE
3
USB 125VAV
Made in Vietnam
QTY
1 PC
1 PC
2PCS
A
