GLOBAL FURNITURE ALLIANCE U5990-GR Assembly Instructions

MODEL : U5990-GR
Thank you for purchasing this quality product. Be sure to check all packing material
carefully for small parts that may have come loose inside the carton during shipment.
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior to start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast & easy assembly.
Product Dimension (W x D x H) - inches
STEP 1: Attach the Backrest (B) to the Seat (A)
STEP 3: Open the Footrest by PULL out the handle.
ASSEMBLY INSTRUCTIONS
B
C
A
Description : GLIDER RECLINER
PART LIST :
No. Description
A
SEAT BASE
B
BACKREST
C
LEFT WING
D
RIGHT WING
STEP 2:
Attach the Wing (C/D) to the
Backrest (B)
B
ASSEMBLY COMPLETED
Diagram Quantity
1
1
1
1
D
A
Made in VietNam
