I
NSTALLATION
Thank you for choosing Ambassador Marine.
Your new Ambassador Marine faucet, sprayer, shower or
accessory will give you years of trouble-free performance.
Please read these instructions carefully before installing your
new item. If you have any additional questions about the
installation of this product, please feel free to contact one of
our friendly customer service representatives at 800.270.4262.
1
2
3
I
NSTRUCTIONS
Towel Ring / Robe Hook / Cup Holder / Soap Dish / Single Post TP Holder
1) Hold item on the wall where desired. With a pencil, lightly trace a circle completely around
the base of the item. Remove the item. Hold a mounting bracket directly in the center of the
outline (see figure 1). Trace a circle around the mounting bracket and the two mounting screw
holes.
2) Mount the bracket as shown (see figure 2). For mounting into wood, fiberglass, or other solid
surface, drill a 1/8" starter hole and attach the bracket to the wall.
3) Secure the item to the bracket (see figure 3) with the set screw pointing down. Tighten the
set screw.
18" Towel Bar / 24" Towel Bar / Double Post TP Holder
1) Hold one of the posts on the wall where desired. With a pencil, lightly trace a circle
completely around the base of the post. Remove the post. Hold a mounting bracket directly in
the center of the outline (see figure 1). Trace a circle around the mounting bracket and the two
mounting screw holes.
2) Mount the bracket as shown (see figure 2). For mounting into wood, fiberglass, or other solid
surface, drill a 1/8" starter hole and attach the bracket to the wall.
3) Secure the post to the bracket (see figure 3) with the set screw pointing down. Tighten the
set screw.
4) For the other end, merely set the bar or roller into the mounted post and hold the other post
at the correct spot. NOTE: Mount the second post "in" tightly so that there is no side to side
movement of the bar. USE A BUBBLE LEVEL TO INSURE THAT THE BAR IS LEVEL. Trace a circle
around the second post (see figure 1) and mount.
130-1325-CG
(OEM)
131-1325-CG
(Retail)
Estancia / Pacifica
18" Towel Bar Set
Chrome/18k Gold
