Siemens TA3DG02 Installation Instructions

s
Power Distribution Connectors
Conectores de Distribución de Energía
Connecteurs de distribution de puissance
Installation Instructions / Instructivo de Instalación
Hazardous Voltage. Hazardous Voltage.
Will cause death or serious injury. Will cause death or serious injury.
Turn off and lock out all power supplying this device before Turn off and lock out all power supplying this device before
working on this device. working on this device.
Replace all covers before power supplying this device is Replace all covers before power supplying this device is
turned on. turned on.
Use only with Siemens certified Components.
Utilizar únicamente con componentes certificados de Siemens.
A utiliser uniquement avec les composants certifiés Siemens.
Special Purpose - Not for general use when
used with connectors below:
Proposito Especial - No para uso general
cuando es usado con conectores debajo:
NOTE - These instructions do not purport to cover all details or variations in equipment, or to provide for every possible
contingency to be met in connection with installation, operation or maintenance. Should further information be desired or
should particular problems arise, which are not covered sufficiently for the purchaser's purposes, the matter should be
referred to the local Siemens sales office. The contents of this instruction manual shall not become part of or modify any
prior or existing agreement, commitment or relationship. The sales contract contains the entire obligation of Siemens. The
warranty contained in the contract between the parties is the sole warranty of Siemens. Any statements contained herein
do not create new warranties or modify the existing warranty.
Trademarks - Unless otherwise noted, all names identified by ® are registered trademarks of Siemens AG or Siemens
Industry, Inc. The remaining trademarks in this publication may be trademarks whose use by third parties for their own
purposes could violate the rights of the owner.
s
WARNING
8 0 6 9 4 0 A 0 2
Tensión peligrosa. Tensión peligrosa.
Puede causar la muerte o lesiones graves. Puede causar la muerte o lesiones graves.
Desenergice totalmente antes de instalar o darle servicio. Desenergice totalmente antes de instalar o darle servicio.
Reemplace todas las barreras y cubiertas antes de Reemplace todas las barreras y cubiertas antes de
energizar el interruptor. energizar el interruptor.
10 – 32 UNF X 1.0"
TA3DG02 / 3VL9202-4TP01
3X - 3TA3DG02 / 3VL9202-4TP31
1 / 3
U.S. Cat. No. Euro Order No.
Item:
TA3DG02 3VL9202-4TP01
3VL9202-4TP31
3TA3DG02
3VL9204-4TP01
TA6DG04
3TA6DG04 3VL9204-4TP31
TA3FG20 3VL9302-4TP01
3VL9302-4TP31
3TA3FG20
3VL9304-4TP01
TA6FG04
3TA6FG04 3VL9304-4TP31
Item:For Use With Frame DG, FG
Para Usar Con Caja Base DG, FG
Tension dangereuse. Tension dangereuse.
Danger de mort ou risque de blessures graves. Danger de mort ou risque de blessures graves.
Couper l'alimentation de l'appareil et barrer avant de Couper l'alimentation de l'appareil et barrer avant de
travailler. travailler.
Remplacez touts les couverts avant que Remplacez touts les couverts avant que
l'approvisionnement de pouvoir soit alimenté. l'approvisionnement de pouvoir soit alimenté.
1/8"
5/32"
Cal. ISO 6789
10 – 32 UNF X 1.0"
TA6DG04 / 3VL9204-4TP01
3X - 3TA6DG04 / 3VL9204-4TP31
I.L. No. 806940A02
3/16"
1/4"
