Lfz24v series suppression inductors

Advertisement

LFZ24V Type

Mechanical Dimension:

26.0 Max.
1
3
6
4

Electrical Characteristics:

o
AT 25 C, 40KHz/1V Tested:
PART NO.
LFZ24V01
LFZ24V02
LFZ24V03
LFZ24V04
LFZ24V05
LFZ24V06
LFZ24V07
LFZ24V08
LFZ24V09
LFZ24V10
LFZ24V11
LFZ24V12
* WITHSTANDING VOLTAGE BETWEEN L1 & L2 1.5KV 1 MINUTE
* GOOD DIFFERENCE IN WINDING L1 & L2 INDUCTANCE
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
Unit: mm
31.0Max.
4.0 1.0
0.8
13.0 0.3
10.0 0.3
19.0 Max.
INDUCTANCE
(mH) MIN
62.0
54.0
43.0
27.0
17.0
14.0
11.0
7.8
6.4
4.8
3.5
2.3
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
EMI Common-Mode
Suppression Inductors

Schematic :

6
PRI
1
DCR
RATED CURRENT
(m ) MAX
(Aac)
2015
0.30
1815
0.40
1390
0.50
930
0.60
550
0.90
490
1.0
360
1.1
250
1.4
220
1.5
155
1.8
115
2.0
87
2.4
10
4
SEC
3
TEMPERATURE
o
RISE ( C) MAX
45
45
45
45
45
45
45
45
45
45
45
45
