- Page 1 Installation Guide SPDS41xx Height adjustable in-window mount for portrait screens up to 75" SPDS4101 SPDS41011 Page 1 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024 MK15-0490_V1.0 25-09-2024...
-
Page 2: Maintenance
If these installation instructions are not followed precisely, it could lead to product failure and potential personal injury. • Ergonomic Solutions / SpacePole Inc. cannot be held responsible for any product failure or personal injury, if the installation instructions are not followed correctly. -
Page 3: Tool List
1x 6,0mm Allen key 4x Ø8.4/Ø15.5x5 Spacer 4x Ø8/Ø16 washer 4x M8 nut 4x M6x12 4x M8x16 4x M8x25 4x M8x60 screw 4x M8x35 8x M8 nut cap 1x MK15-0076 4x M4x8 countersunk screw Page 3 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024... -
Page 4: Table Of Contents
1x 6,0mm Allen key 4x Ø8.4/Ø15.5x5 Spacer 4x Ø8/Ø16 washer 4x M8 nut 4x M6x12 4x M8x16 4x M8x25 4x M8x60 screw 4x M8x35 8x M8 nut cap 2x MK15-0076 4x M4x8 countersunk screw Page 4 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024... -
Page 5: Dimensions (Mm)
Dimensions [mm] SPDS4101 Page 5 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024... - Page 6 Dimensions [mm] SPDS41011 Page 6 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
- Page 7 Step 1: Install part (A) to a level floor. Use the 8x Ø9 holes. Note fixings are not included. Ø9.0 169,6 84,8 WARNING: It is the responsibility of the installer to use the correct fixings for the specific installation site. Page 7 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
-
Page 8: M8 Nut
(A) & (B). Then use the 2x M8x60mm bolt and 2x M8 nuts. Finish with adding 4x M8 end caps. M8x60 M8 nut cap M8 nut Cable options: A) Cables to floor box B) Cables to external source Page 8 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024... -
Page 9: M8 Nut Cap
Install the two (C) parts & route the cable through the cable management hole. Use the 2x M8x60mm bolt and 2x M8 nuts. Finish with adding 4x M8 end caps. M8x60 M8 nut M8 nut cap Positioning holes Page 9 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024... -
Page 10: M4X8 Countersunk Screw
Steps Step 4: Use 4x M6 x 8mm countersunk screws and install part (D). M4x8 Countersunk screw Cables Page 10 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024... - Page 11 Steps Step 5: Use 4x M6 x 8mm countersunk screws and install part (D). M4x8 Countersunk screw Page 11 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
-
Page 12: Ø8.4/Ø15.5X5 Spacer
M6 screws. Ø8,5 holes are used for M8 screws. 4x Ø8.4/Ø15.5x5 Spacer 4x Ø8/Ø16 washer 4x M6x12 4x M8x16 4x M8x25 4x M8x35 MK15-0076 SPDS4101 has 2x VESA brackets SPDS41011 has 4x VESA brackets Page 12 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024... - Page 13 Step 7: Install the screen at the desired height. The screen can sit on either side of part (C). Part (E) hooks into the holes of part (C). Positioning holes Mounting holes Page 13 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
- Page 14 Steps Step 8: To lock the screen to the in-window floor stand install 4x M6x20mm screws M6x20mm Page 14 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
- Page 15 Steps Step 9: Connect the cables to the screen. Page 15 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
- Page 16 Steps Step 10: For SPDS41011 only - to mount the second screen, repeat step 6 to 9. This results in the Dual-sided adjustable in-window mount. Page 16 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
- Page 17 Steps Step 11: Install part (F) to part (A). Part (F) can be fixed using 4x M4x8mm countersunk screws. M4x8 countersunk screw Page 17 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
- Page 18 Steps Step 12: If cables are run into floor box, then install the plug, to close off the base. NOTE: Valid for both SPDS4101 & SPDS41011 Ø44.5 plug Page 18 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
- Page 19 This page intentionally left blank Page 19 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
- Page 20 Page 20 of 20 COPYRIGHT © ERGONOMIC SOLUTIONS 2024...
