- Page 1 EDGE2KIT Model EDGE2KIT-SLV DUAL ARM CONVERSION KIT EDGE2KIT Rev A 2/17 ASSEMBLY AND ADJUSTMENT...
-
Page 2: Parts And Tools
Do not discard the packaging until satisfied that the product operates to your satisfaction. With this Edge2Kit, a single arm Edge system is converted to a dual arm system. The monitor arm assembly from the single arm system is re-used; otherwise, all components are included in the conversion kit. - Page 3 REMOVAL OF EDGE COMPONENTS EDGE2KIT DUAL ARM CONVERSION KIT Disconnect and Remove the Monitor from Edge System Monitor Arm • Disconnect the monitor cables. • If a VESA locking screw is installed, remove the screw. • Press down on the plastic tab on the VESA mount to release the VESA plate.
- Page 4 EDGE2KIT DUAL ARM CONVERSION KIT INSTALLATION OF EDGE2 BASE ASSEMBLY Remove the Edge System Base Assembly • Clamp method. Loosen the clamp knob to remove the base assembly from the table. Clamp • Grommet method. Remove the two nuts securing the...
- Page 5 INSTALLATION OF EDGE2 BASE ASSEMBLY EDGE2KIT DUAL ARM CONVERSION KIT Install Edge2 Base Assembly — Grommet Method With this method, the base assembly is secured through a grommet hole in the work surface, with a diameter between 0.78" (20mm) and 2" (51mm). Surface thickness must be between 0.6"...
-
Page 6: Monitor Installation
EDGE2KIT DUAL ARM CONVERSION KIT MONITOR INSTALLATION Install Second Monitor Arm Assembly • Insert the second monitor arm assembly (from the original Edge system) into the base assembly. Second Monitor Arm • Align the metal plate on the monitor arm bushing (from Edge System) with the set screw on the base assembly. -
Page 7: Cable Management
MONITOR INSTALLATION EDGE2KIT DUAL ARM CONVERSION KIT • Slide each VESA plate (with monitor attached) onto its VESA mount. Make sure the VESA plate clicks securely in place. — Optional: Install a VESA locking screw behind each VESA plate to prevent the tab on the VESA plate from releasing the monitors. - Page 8 EDGE2KIT DUAL ARM CONVERSION KIT MONITOR INSTALLATION Tension Adjustments There are five possible swivel and tilt tension adjustments for each of the two monitor arms: 1. Monitor swivel adjustment — Use the 2mm Allen key to adjust the set screw for the desired ease of monitor rotation.
-
Page 9: Final Adjustments
FINAL ADJUSTMENTS EDGE2KIT DUAL ARM CONVERSION KIT 180° Lock-Out Feature • Use the 2mm Allen key to secure the 180° locking screws into the base of each monitor arm assembly to limit the fixed monitor arm rotation to 180°. Fully tighten the screws, then back out one full turn. - Page 10 NOTES...
