Custom Dynamics CD-RG-WT-15-B Installation Instructions

Part Numbers:
CD-RG-WT-15-B
CD-RG-WTSEQ-15-B
Package Contents:
- LED Windshield Trim Assemblies (Pair)
- Wiring Harness (2)
- 10-32 Button Head Cap Screws (4)
- Washers: Large Metal (4), Small Metal (4), Rubber (4)
- Instructions (1)
Fitment:
2015-2023 Harley-Davidson® Road Glide
(FLTRX), Road Glide Special (FLTRXS), 2022-2023 Road
Glide ST (FLTRXST) and CVO
(FLTRKSE), 2020-2024 Road Glide Limited (FLTRK), 2018-
2022 CVO Road Glide (FLTRXSE), 2016-2019 Road Glide
Ultra (FLTRU), 2020-2022 CVO
(FLTRUSE) and 2023-2024 Road Glide 3 (FLTRT).
ATTENTION
Please read all Information below before Installation
Warning: Disconnect negative battery cable from battery; refer to owner's
manual. Failure to do so may result in electrical shock, injury, or fire. Secure
negative battery cable away from positive side of battery and all other positive
voltage sources on vehicle.
Safety First: Make sure the bike is parked on a level surface and bike's me-
chanical components are cool to the touch.
Notice: This product is designed and intended for use as auxiliary lighting on
motorcycles only. This product is NOT intended to replace any original equip-
ment lighting installed on the motorcycle and should not be used for that pur-
pose. This product must be wired in such a fashion that it does not interfere
with any original equipment lighting.
Note: You will have to remove the front fairing dash and windshield in order to
complete this installation. Please refer to your manufacturer's service manual
if unsure of this procedure.
Cleaning: Take special care in cleaning the finish. Use only Alcohol or Iso-
Heet and a fine microfiber cloth to remove dirt or debris. Never use abrasive
polishes or cleaners as these can scratch the finish.
Note: Failure to use the provided mounting hardware will void all warranties.
Note: Over-tightening the mounting hardware will cause the paint to chip
which is not covered under the warranty.
Questions? Email: info@CustomDynamics.com
Custom Dynamics® Road Glide LED Windshield Trim
We thank you for purchasing the Custom Dynamics® Road Glide LED
Windshield Trim. Our products utilize the latest technology and high-
est quality components to ensure you the most reliable service. We
offer one of the best warranty programs in the industry and we back
our products with excellent customer support, if you have questions
before or during installation of this product please call Custom Dy-
namics® at 1 (800) 382-1388.
CD-RG-WT-15-C
CD-RG-WTSEQ-15-C
Road Glide Limited
Road Glide Ultra
or Call us at: 1 (800) 382-1388 M-TH 8:30AM-5:30PM / FR 9:30AM-5:30PM EST
Installation Instructions
Installation:
1. Remove and discard the 4 OEM windshield screws, they will not
be reused. Remove windshield and set aside in a safe place to
prevent damage. Shown in Figure 1.
1 1
2. Remove the top vent, it is secured with retaining clips. Position
yourself in front of the motorcycle and lift straight up on the top
vent and release it from the retaining clips and set aside in a safe
place to prevent damage. Shown in Figure 2.
2
