SMART TRIPLE PLAY® Run Brake Turn Controller with
Built in Strobe/Flasher (Patent Pending)
Fits: Universal 12VDC, Non CAN BUS Motorcycles
Important: For this system to be legal you must use RED rear turn signal lamps.
Important: This system is designed to work with single intensity rear turn signals, if you
do not have single intensity rear turn signals do not install this module. Contact Techni-
cal Support.
Important: Remove any existing Run-Brake-Turn or similar modules prior to installing
this unit.
Caution: Never install a Load Equalizer Downstream of this unit. Remove any existing
load equalizer prior to installing this unit.
Caution: Never install a trailer adapter, trailer harness or trailer controller downstream
of this unit, a trailer adapter, harness or controller must be installed on the input side
of this unit.
Caution: This unit is designed for a maximum load of 27 watts per channel. Do no ex-
ceed 27 watts per left turn signal output, 27 watts per right turn signal output, and 27
watts per brake signal output. Overloading unit could cause damage to the unit and
cause the unit to malfunction.
1. Secure motorcycle on level surface. Remove seat. Disconnect negative battery ca-
ble from the battery. Locate and unplug the lighting connector to the rear fender.
2. Wire the Smart Triple Play® Module, in-line, into the rear lighting harness according
to the diagram on page 2 and 3.
3. Re-connect the battery's negative battery cable to the negative of the battery.
4. Locate a secure place for the Smart Triple Play® unit that will not interfere with the
secure placement of the seat or side cover.
Installation Instructions
Part: GEN-SMART-TPU-UNV
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Custom Dynamics Smart Triple Play GEN-SMART-TPU-UNV
Summary of Contents for Custom Dynamics Smart Triple Play GEN-SMART-TPU-UNV
- Page 1 SMART TRIPLE PLAY® Run Brake Turn Controller with Built in Strobe/Flasher (Patent Pending) Installation Instructions Part: GEN-SMART-TPU-UNV Fits: Universal 12VDC, Non CAN BUS Motorcycles Important: For this system to be legal you must use RED rear turn signal lamps. Important: This system is designed to work with single intensity rear turn signals, if you do not have single intensity rear turn signals do not install this module.
- Page 2 SMART TRIPLE PLAY® Run Brake Turn Controller with Built in Strobe/Flasher (Patent Pending) Universal Installation Instructions 1: Locate 5 wires going to rear of bike: Power—Running Ground Brake Left Turn Right Turn Output Side Input Side 2: Cut the Brake, Left Turn, and Right Turn Wires Output Side Input Side 3.
- Page 3 SMART TRIPLE PLAY® Run Brake Turn Controller with Built in Strobe/Flasher (Patent Pending) Installation Instructions Harley Ground - Black Brake - Red (or w/Orange tracer) Left Turn - Purple Right Turn - Brown Tail/Running - Blue...
- Page 4 SMART TRIPLE PLAY® Run Brake Turn Controller with Built in Strobe/Flasher (Patent Pending) Installation Instructions 5. Initial Setup and Operation: Locate the two switches and rotary dial. Be sure the rotary dial is set to position 0. Note there is a screw diver slot to make the dial turn easer, this is not the pointer, there is small arrow on the dial , this is the pointer that should now be at position 0.
- Page 5 SMART TRIPLE PLAY® Run Brake Turn Controller with Built in Strobe/Flasher (Patent Pending) Installation Instructions 7. The Smart Triple Play ® allows you to program the running light brightness of the turn signals so they are a match to your center taillight. Turn ignition key off, be sure Switch 1 and Switch 2 are in the OFF position and the Rotary Dial •...
