18-HE17D7-4 Installation Operation Maintenance Electronic Air Cleaner Furnace Only Models Air Handler Only Models TFE145A9FR3 TFE215A1AH3, A9AH3 TFE175A9FR3 TFE235A1AH3, A9AH3 TFE210A9FR3 TFE260A1AH3, A9AH3 TFE245A9FR3 ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES IMPORTANT — This Document is customer property and is to remain with this unit.
Installer’s Guide Discharge Air Side- Use inner Double Mounting mounting holes Entering Air Side- Holes On Flange Single Row of for Side Mounting Holes Installation On Flange Air Flow Install gasket material 1 Inch toward inner edge. Pre-Filter Cut to length required. Guides Open Position...
Installer’s Guide ELECTRICAL Use outer mounting holes The air cleaner unit has an air flow sensor installed. There- for Bottom fore, control wiring is not required. Installation FURNACE & AIR HANDLER - 120 VAC models These models require a 3 prong, grounded, 120 VAC outlet with a minimum circuit protection of 15 amps.
Installer’s Guide When the blower stops, the green light will turn OFF. Voltage OZONE REDUCTION FEATURE at power pack cell contact and air cleaner cells is removed. All electronic air cleaners produce a small quantity of ozone that is within established limits. Some customers may notice an odor MAINTENANCE especially at high altitudes, low air flow rates or temporarily after For maximum efficiency the air cleaner cells and pre-filter should...
Installer’s Guide In some cases the green light will remain OFF during this initial FUSE REPLACEMENT activation of the air cleaner. This would indicate that the cell(s) The fuse is located in the fuse holder inside the power pack are not completely dry. The green light should turn ON once the next to the female power plug.
Installer’s Guide TROUBLESHOOTING SERVICE INDICATION SERVICE CHECKS 1. Power is not being supplied to the air cleaner. Blower A. Check that power switch is "ON " light OFF Green operating B. Check that the power cord is connected to the outlet and the power door. C.
Tab on power tray must be on outside of flange on cover Figure 13. Assembling Power Tray and Cover American Standard Inc. 6200 Troup Highway Tyler, TX 75707 Since the manufacturer has a policy of continuous product and product data improvement, it reserves the right...
