LCWB-003 User Information
Contents
1. LCWB-003 Overview and Specification
(1) Overview
(2) Specification
2. Customer Support
1. LCWB-003 Overview and Specification
(1)Overview
1) This is a Wi-Fi&BLE Combo module
2) Wi-Fi wireless communication with wired LAN IoT product for
protocol and application performance based on IEEE 802.11
b/g/n (HT20) standard technology
3) The RTL8720 series highly integrated Bluetooth Low Energy
controller with a UART interface. It combines a BLE Protocol
(PHY, LL, L2CAP, SM, ATT, GAP, GATT), BLE Baseband, Modem,
and BLE RF in chip, also supports BLE user GATT-based profile
application.
(Model Name : LCWB-003)
Advertisement
Related Manuals for LG LCWB-003
Summary of Contents for LG LCWB-003
- Page 1 LCWB-003 User Information (Model Name : LCWB-003) Contents 1. LCWB-003 Overview and Specification (1) Overview (2) Specification 2. Customer Support 1. LCWB-003 Overview and Specification (1)Overview 1) This is a Wi-Fi&BLE Combo module 2) Wi-Fi wireless communication with wired LAN IoT product for protocol and application performance based on IEEE 802.11...
- Page 2 (2) Specification Categories Details Model Name LCWB-003 Range of 2412 MHz ~ 2462 MHz Frequency Channel 11EA Transmission 17 dBm Output (Tolerance ±2 dBm) WIFI Reception –88 dBm (802.11b) sensitivity -75 dBm (802.11g) -72 dBm (802.11n) 802.11b : DQPSK, DBPSK, CK Modulation 802.11g/n : OFDM/64-QAM,16-QAM,...
-
Page 3: Regulation Information
This device must not be co-located or operating in conjunction with any other antenna or transmitter. • Responsible Party Information (Supplier's Declaration of Conformity) LG Electronics USA 1000 Sylvan Avenue Englewood Cliffs New Jersey, United States, 07632... - Page 4 Regulatory notice to host manufacturer according to KDB 996369 D03 OEM Manual v01 • List of applicable FCC rules This module has been granted modular approval as below listed FCC rule parts. - FCC Rule parts 15.247 • Summarize the specific operational use conditions The OEM integrator should use equivalent antennas which is the same type and equal or less gain then an antenna listed in this instruction manual.
- Page 5 Label and compliance information • End Product Labeling The module is labeled with it sown FCC ID and IC Certification Number. If the FCC ID and IC Certification Number are not visible when the module is installed inside another device, then the outside of the device into which the module is installed must also display a label referring to the enclosed module.
- Page 6 ISED • RSS-GEN, Sec. 7.1.3–(licence-exempt radio apparatus) This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) This devicemay not cause interference, and (2) This device must accept any interference, including interference that may cause undesired operation of the device.
