INSTALLATION AND MAINTENANCE INSTRUCTIONS
MMF-302-6A Six Zone Interface Module
SPECIFICATIONS
Normal Operating Voltage:
Stand-By Current:
Alarm Current:
Temperature Range:
Humidity:
Dimensions:
Accessories:
Wire Gauge:
External Power Supply Voltage:
Maximum IDC Wiring Resistance:
Ripple Voltage:
IDC (supervised and power limited)
DC Voltage:
Frequency:
Alarm Current:
Standby Current 6 circuits:
BEFORE INSTALLING
This information is included as a quick reference installation guide. Refer to
the appropriate Fire•Lite control panel installation manual for detailed system
information. If the modules will be installed in an existing operational system,
inform the operator and local authority that the system will be temporarily
out of service. Disconnect the power to the control panel before installing the
modules. This system contains static sensitive components. Always ground
yourself with a proper wrist strap before handling any circuits so that static
charges are removed from the body. The module housing should also be
grounded.
NOTICE: This manual should be left with the owner/user of this equipment.
COMPATIBLE TWO-WIRE SYSTEM SENSOR SMOKE DETECTORS FOR USE WITH MMF-302-6A
DET.
MODEL
1151
1451
1451DH
2151
2451
2451TH
5451
1100
1400
** 2100AT
2100B
2100D
2100S
2100TB
2100TD
2100TS
2300B
2300TB
2400
2400TH
* 2W-B
* 2W-TB
DH100LP
* Class B Only
** No Accessory will be supported by 2100AT
15-32 VDC
2.3 mA @ 24 V
40 mA (assumes all six LEDs solid on)
32°F to 120°F (0°C to 49°C)
10 to 93% Noncondensing
6.8"H x 5.8"W x 1.25"D (173 mm H x 147 mm W x 32 mm D)
CH-6A Chassis; BB-2F Cabinet; BB-6F Cabinet
12-18 AWG (0.9 mm
- 3.25 mm
)
2
2
Regulated 24 VDC
25 Ohms
0.1 volts RMS maximum
18-28 volts power limited
DC
90mA per circuit
42mA Maximum @18 VDC
56mA Maximum @24 VDC
66mA Maximum @28 VDC
DETECTOR
DET. ID
MANUFACTURER
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
A
SYSTEM SENSOR
GENERAL DESCRIPTION
The MMF-302-6A Six Zone Interface Module is intended for use in an intelli-
gent alarm system. Each module provides an interface between the intelligent
alarm system and a conventional alarm system loop. A common SLC input is
used for all modules, and the initiating device loops share a common super-
visory supply and ground. Otherwise, each monitor operates independently
from the others. Each module has its own unique address.
A pair of rotary code switches is used to set the address of the first module
from 01 to 154. The remaining modules are automatically assigned to the next
five higher addresses. Provisions are included for disabling a maximum of two
unused modules to release the addresses to be used elsewhere. Each mod-
ule also has panel controlled bicolor LED indicators. The panel can cause the
LEDs to blink, latch on, or latch off.
BASE MODEL
MAX DET.
B110LP,B401
B401, B401B
DH400
B110LP, B401
DH400, B401B,B401
B401, B401B
B401
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
N/A
1
One FireLite Place
Northford, CT 06472
Phone: 203.484.7161
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
20
I56-2066-003
7/1/2022
