Hopeland Shine 100 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
HH100
Shine 100
User Manual
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Shine 100 and is the answer not in the manual?

Questions and answers

Related Manuals for Hopeland Shine 100

Summary of Contents for Hopeland Shine 100

  • Page 1 HH100 Shine 100 User Manual - 1 -...
  • Page 2 Welcome to become user of Hopeland RFID products. Thank you for choosing the integrated reader Shine 100, hope to bring convenience for your work - 2 -...

  • Page 3: Table Of Contents

    Shine 100 User Manual CONTENTS 1.TECHNICAL SPECIFICATIONS ..........................- 5 - ................................- 5 - 1.1 F EATURES ................... - 5 - 1.2 M UNCTIONS ECHNICAL ERFORMANCE 1.2.1 Product Features ............................- 5 - 1.2.2 Typical Applications ..........................- 5 - 1.2.3 Specifications ..............................
  • Page 4 Shine 100 User Manual 5.2.3 Baseband Configuration ........................- 29 - 5.2.4 Advanced Baseband Settings ......................- 30 - ............................... - 31 - 5.3 R EADER ETTINGS 5.3.1 Ethernet Configuration ........................... - 31 - 5.3.2 Wireless Network Configuration ......................- 32 - 5.3.3 RS485 Configuration ..........................

  • Page 5: Technical Specifications

    Shine 100 User Manual 1.Technical Specifications 1.1 Features Shine HH100 is a high performance integrated UHF RFID reader with built-in Android OS 9. which has strong computing power, large storage capacity, rich interfaces, open development environment, and convenient extension of custom applications. it supports ISO18000-6C/6B protocols.
  • Page 6 Shine 100 User Manual Air interface protocol: ISO18000-6B/C EPC C1G2 all mandatory commands Built-in Android 9.0 operating system Rich communication interfaces (RJ-45, RS-485,4G, WiFi, Bluetooth, Wiegand interface) Adjustable RF output power POE power supply (optional) Working mode: fixed frequency/frequency hopping optional I/O interface: 2 optocoupler inputs, 2 relay outputs (drive capacity: DC 30V/ 2A, AC 125V/0.3A)
  • Page 7 Shine 100 User Manual Power Parameters Equipment power supply: DC 9V～30V (60W); POE: IEEE802.3af/at/bt standard (optional) Working power consumption: 30W (output power 35dBm) Environmental Parameters Working temperature: -25℃~+70℃ Storage temperature: -40℃~+85℃ Working humidity: 10%～95%RH without condensation Compliance With Certification Compliant with China Radio Model Approval...

  • Page 8: Sketch Map

    Shine 100 User Manual Sketch map 2.1 Physical construction Picture 2-1 Structure diagram of Shine 100 reader Shine 100 Reader Volume Parameter is: 276mm×276mm×70mm 2.2 Net Weight HH100：1.76kg 2.3 Interface Diagram 2.3.1 Power, Communication And I/O Interfaces Picture 2-2 Schematic diagram of reader LED indicator panel...

  • Page 9: I/Ointerface And Communication Schematic Diagram

    Shine 100 User Manual The description of the LED indicator panel is shown in Table 2-1: Table 2-2 LED indicator description LED Label Label Description Status Description ANT1 Antenna 1 indicator Indicates that the built-in antenna is working ANT2 Antenna 2 indicator...

  • Page 10: Diagram Of External Connection Cables

    Shine 100 User Manual 2.5 Diagram of external connection cables 2.5.1 Output A(power and communication interface) cable instruction Cable specification: black insulated outer skin with metal shielding mesh, 14 inner cores, outside diameter 7.8mm, main cable length 4m, each branch cable length 1m. as shown in Figure 2-4, the aviation plug is connected to the reader output A.
  • Page 11 Shine 100 User Manual The other end of the cable is a bare and tinned wire end, and each function definition is distinguished by the color of the cable. Table 2-2 I/O control aviation cable interface definition table Pin ID Pin Description Relay 1# output;...
  • Page 12 Shine 100 User Manual GPO Usage Example: Relay type GPO: GPO is equivalent to a switch, logic ‘0’ means open circuit, logic ‘1’ means closed, default is open circuit state. You can connect the alarm light, buzzer, etc. to the GPO for use.

  • Page 13: Coaxial Rf Feeder Cable (Optional)

    Shine 100 User Manual connect reader Wiegand 1 to Wiegand 1 of controller, connect reader GND to Wiegand controller GND 2.5.3 Coaxial RF Feeder Cable (optional) Picture 2-6 schematic diagram of feeder line RF cable TNC(Reverse polarity, internal thread, inner pin) connector connect with reader antenna TNC connector, RF cable SMA connector connect with external circular polarization antenna’s SMA connector, cable maximum length is 5m, impedance 50Ω, insertion loss is...
  • Page 14 Shine 100 User Manual Figure 2-7 Network application connection - 14 -...

  • Page 15: Installation Instructions

    Shine 100 User Manual Installation Instructions 3.1 Precautions To ensure the normal and stable operation of the device and your personal property and safety, please carefully read the following notes before install HH100 reader. 1. Firstly, check whether the power socket is connected to the ground, and to see whether the local power supply voltage is in accordance with the applicable voltage range of the reader;...

  • Page 16: Device Connection

    Shine 100 User Manual 3.3 Device Connection 3.3.1 Connect Power Adapter Or PoE Switch a.Connect Power Adapter Plug the power cord into the AC power supply outlet and then plug the other end of the power cord into the power connector of the reader and fasten it.

  • Page 17: Connect External Antenna And Rf Cable

    Shine 100 User Manual 3.3.2 Connect External Antenna And RF Cable The reader built with four/eight TNC coaxial cable connectors for connecting external antennas, select low consumption RF cable, connectors should be tightened (Ensure to be waterproof when install outdoors);...

  • Page 18: Install Reader

    Shine 100 User Manual Lock Open Re-install the cover of the SIM card slot. 3.4 Install Reader The reading and writing range of the reader depends on the onsite application, the tilt angle of the antenna is adjusted to achieve the best reading and writing performance.

  • Page 19: Android Os Demonstration Operation

    Shine 100 User Manual Android OS Demonstration Operation 4.2 Display Reader Android OS to PC via Scrcpy Using Scrcpy on a PC to display Reader Android OS on a PC.You can download Scrcpy through the link below or search and download by yourself.

  • Page 20: Wifi Settings

    Shine 100 User Manual 4.3 WiFi Settings Shine series readers have a built-in WiFi module. You can set WiFi parameters through the Demo software, or you can set the WiFi parameters through the Android OS. 1. After the reader is powered on, connect the supplied WiFi/Bluetooth shared antenna to the reader’s WiFi/Bluetooth shared antenna interface...

  • Page 21: Bluetooth Settings

    Shine 100 User Manual 4.4 Bluetooth Settings Shine series readers have a built-in Bluetooth module, which can be paired with the reader’s Bluetooth through a PC. After the Bluetooth serial port is generated, the Demo software can use this Bluetooth serial port to communicate with the reader.
  • Page 22 Shine 100 User Manual 3. Pair the Bluetooth name with the PC system. After the pairing is completed, check the Bluetooth serial port generated between the PC and the reader's Bluetooth. The port with outgoing direction, which is the Bluetooth serial port number that the demo can use for communication.
  • Page 23 Shine 100 User Manual - 23 -...

  • Page 24: Mobile Network Settings

    Shine 100 User Manual 4.5 Mobile Network Settings Reader has built-in 4G function and supports global 4G frequency band.Reader Android OS is used to set the relevant parameters of the mobile network. 1. According to the content in chapter 3.3.4, install the mobile phone SIM card when the reader is turned off 2.
  • Page 25 Shine 100 User Manual - 25 -...
  • Page 26 Shine 100 User Manual - 26 -...

  • Page 27: Web Page Operation Instructions

    Shine 100 User Manual Web page Operation Instructions 5.1 System Login 5.1.1 Login It is recommended to use Google Chrome to log in. When logging in, please enter the URL of the reader in the address bar, such as: http://192.168.1.116:8080/. The login interface is shown in Figure 5.1.1.

  • Page 28: Rfid Settings

    Shine 100 User Manual Figure 5.1.2 5.2 RFID Settings The RFID setting menu includes antenna configuration, frequency configuration,baseband configuration and advanced baseband configuration. 5.2.1 Antenna Configuration Click RFID Settings-->Antenna Power under the left navigation to enter the antenna configuration page, as shown in Figure 5.2.1.

  • Page 29: Frequency Configuration

    Shine 100 User Manual Figure 5.2.1 5.2.2 Frequency Configuration Click RFID Settings-->Frequency under the left navigation to enter the frequency configuration page, as shown in Figure 5.2.2. Frequency can set the working frequency band, frequency hopping mode and working frequency points of the device. When the Freq Hopping mode selects Auto, the frequency list cannot be selected.

  • Page 30: Advanced Baseband Settings

    Shine 100 User Manual Figure 5.2.3 5.2.4 Advanced Baseband Settings Click RFID Settings-->Advanced Baseband under the left navigation to enter the advanced baseband settings page, as shown in Figure 5.2.4. In the Advanced Baseband Settings page, antenna switching mode, dynamic Q algorithm, and special tag inventory can be configured.

  • Page 31: Reader Settings

    Shine 100 User Manual Figure 5.2.4 5.3 Reader Settings The reader settings contains Ethernet configuration, wireless network configuration, RS485 configuration and advanced network parameters. 5.3.1 Ethernet Configuration Click Reader Settings-->Ethernet under the left navigation to enter the Ethernet configuration page, which is shown in Figure 5.3.1.

  • Page 32: Wireless Network Configuration

    Shine 100 User Manual Figure 5.3.1 Note: The IP address here is the set value, not the actual value (the actual IP may be different after enabling DHCP) Note: Ethernet settings need to restart reader to take effect 5.3.2 Wireless Network Configuration Click Reader Settings-->WiFi under the left navigation to enter the wireless network...

  • Page 33: Rs485 Configuration

    Shine 100 User Manual Figure 5.3.2 Note: The IP address here is the set value, not the actual value (the actual IP may be different after enabling DHCP) 5.3.3 RS485 Configuration Click Reader Settings-->RS485 under the left navigation to enter the RS485 configuration page, which is shown in Figure 5.3.3.

  • Page 34: Advanced Network Parameters

    Shine 100 User Manual Figure 5.3.3 Note: RS485 settings need to be restart reader to take effect 5.3.4 Advanced Network Parameters Click Reader Settings-->Network under the left navigation to enter the advanced network parameter setting page, which is shown in Figure 5.3.4.

  • Page 35: Filter Settings

    Shine 100 User Manual Figure 5.4.1 Note: The correct firmware must be used to upgrade, otherwise the device will not function properly. 5.4.2 Filter Settings Click Advanced Settings-->Filter Settings under the left navigation to enter the filter settings page, which is shown in Figure 5.4.2.

  • Page 36: Task Settings

    Shine 100 User Manual Figure 5.4.2 5.4.3 Task Settings Click Advanced Settings-->Task Settings under the left navigation to enter the task settings page, which is shown in Figure 5.4.3. The task settings interface allows you to view the task status and control the enable/disable of the task.

  • Page 37: Offline Cache

    Shine 100 User Manual 5.4.3.1 Offline Cache The offline cache task is used to cache the read data into the database when the reader is disconnected during the tag reading process. After the host is reconnected, offline data for this period can be retrieved.

  • Page 38: Httppost Upload

    Shine 100 User Manual Figure 5.4.3.5.1 5.4.3.6 HttpPost Upload The HttpPost upload task is to transmit the tag data in JSON format to the specified server URL. Parameters such as tag data fields and upload interval can be configured through the common parameter of the configuration interface, as shown in Figure 5.4.3.6.1;...

  • Page 39: Mqtt Upload

    Shine 100 User Manual Figure 5.4.3.6.1 Figure 5.4.3.6.2 5.4.3.7 MQTT Upload The MQTT upload task is to transmit the tag data to the specified MQTT server in JSON format. Parameters such as tag data fields and upload interval can be configured through the common parameter of the configuration interface, as shown in Figure 5.4.3.7.1;...

  • Page 40: Mysql Upload

    Shine 100 User Manual Figure 5.4.3.7.1 Figure 5.4.3.7.2 5.4.3.8 MySQL Upload The MySQL upload task is to write tag data into the specified MySQL database. Parameters such as tag data fields and upload interval can be configured through the common parameter of the configuration interface, as shown in Figure 5.4.3.8.1; server information can be configured through the specified parameter of the configuration interface, as shown in Figure 5.4.3.8.2.
  • Page 41 Shine 100 User Manual Create the same database name and table in the MySQL database, and create the table structure according to the sample SQL script. The order of the fields doesn't matter, as long as the data types of the fields are correct, as shown in Figure 5.4.3.8.3. After starting the reader to read tags, the reader can transmit the read tag data to the specified MySQL database, as shown in Figure 5.4.3.8.4.

  • Page 42: Mssql Upload

    Shine 100 User Manual Figure 5.4.3.8.3 Figure 5.4.3.8.4 5.4.3.9 MSSQL Upload The MSSQL upload task is to write tag data into the specified MSSQL database. Parameters such as tag data fields and upload interval can be configured through the common parameter of the configuration interface, as shown in Figure 5.4.3.9.1; server information can be configured through the specified parameter of the configuration interface, as shown in Figure 5.4.3.9.2.
  • Page 43 Shine 100 User Manual the reader to read tags, the reader can transmit the read tag data to the specified MS SQL database, as shown in Figure 5.4.3.9.4. Figure 5.4.3.9.1 Figure 5.4.3.9.2 - 43 -...
  • Page 44 Shine 100 User Manual Figure 5.4.3.9.3 Figure 5.4.3.9.4 - 44 -...

  • Page 45: Appendix A Tag Field Correspondence Table

    Shine 100 User Manual Appendix A Tag Field Correspondence Table The JSON data and the corresponding fields of the database follow Table A.1. Tag Data Field Description Timestamp timestamp DateTime format: yyyy-MM-dd HH:mm:ss.SSS EPC data String format, minimum length 24 characters...

  • Page 46: Log Management

    Shine 100 User Manual Figure 5.4.4.1 5.5 Log Management The log management menu contains operation log and tag log. 5.5.1 Operation Log Click Log Management-->Operation Log under the left navigation to enter the operation log page, which is shown in Figure 5.5.1.1.

  • Page 47: Tag Log

    Shine 100 User Manual Figure 5.5.1.1 5.5.2 Tag Log Click Log Management-->Tag Log under the left navigation to enter the tag log page, which is shown in Figure 5.5.2.1. The tag log is the tag data recorded by the local tag log task.

  • Page 48: Common Failures

    The network port cannot be connected： The default IP address of the Shine 100 reader is set at the factory: 192.168.1.116. Make sure that the IP address of the PC and the IP address of the reader are in the same network segment, such as "192.168.1.XXX".

  • Page 49: Packaging Accessories And Storage

    Carton box size:420mm*316mm*168mm 7.2 Accessories In order to facilitate future storage and transportation, after unpacking the Shine 100 reader, properly store the box and packaging materials. In addition to the reader, the box also includes the accessories required for the use of the product. Please confirm whether the product and accessories are complete according to the product packing list.

  • Page 50: Storage Requirements

    Shine 100 User Manual LAN Cable Included Customized aviation cable power Included communication Customized aviation external IO cable Included Installation kit Included warranty card Included Certificateofapproval Included 4G antenna Included Bluetooth / WIFI antenna Included 7.3 Storage Requirements Shine 340/380 readershouldbestoredinbelowconditions: ...

  • Page 51: After-Sale Service

    Generally,we will provide timely amendments to this manual.If its not provided timely, please consult our service department. ShenzhenHopelandTechnologiesCo.,Ltd. Guarantee card of Shenzhen Hopeland Technologies Co., Ltd Product Name Model No. Product Code...
