Sealey VS8117 Quick Start Manual

Thank you for purchasing a Sealey product. Manufactured to a high standard, this product will, if used according to these instructions,
and properly maintained, give you years of trouble free performance.
IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS & CAUTIONS. USE
THE PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE AND/OR
PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. KEEP THESE INSTRUCTIONS SAFE FOR FUTURE USE.
Refer to
instructions
1. SAFETY
1.1. GENERAL SAFETY
Always perform automotive testing in a safe environment.
9
Keep your work area clean and well lit.
9
Keep clothing, hair, hands, tools, test equipment, etc. away from all moving or hot engine parts.
9
Operate the tool in a well-ventilated work area.
9
DO NOT operate the tool in explosive atmospheres, such as in the presence of flammable liquids, gases, or heavy dust.
8
DO NOT use the tool around corrosive chemicals which can damage the tool.
8
DO NOT abuse the flexible cable. Never use the flexible cable to carry the tool.
8
DO NOT drop the borescope, it is not shock proof.
8
Keep bystanders and children away while operating the tool.
9
Keep the tool dry, clean, free from oil, water and grease.
9
WARNING: The handheld display unit is NOT waterproof.
‰
Handle the borescope with care. If it is dropped, check for breakage and any other conditions which may affect its operation.
9
DO NOT immerse the imager head and cable into corrosive substances, petroleum or oil.
8
DO NOT use near moving machinery.
8
DO NOT use excessive force to insert or withdraw the imager head or cable.
8
DO NOT use the tool while tired or under the influence of drugs, alcohol, or intoxicating medication.
8
DO NOT over-reach. Maintain proper footing and balance at all times.
8
DO NOT use the tool for personal or medical use in any way.
8
1.2. CHARGING SAFETY
Use only the supplied charging cable.
9
Allow clearance all around the device to allow cooling.
9
Disconnect the charging cable from the electrical supply when not in use.
9
DO NOT charge in an explosive atmosphere or in the presence of flammable material.
8
DO NOT leave camera unattended whilst recharging.
8
DO NOT exceed the maximum charging time.
8
The warnings, precautions and instructions discussed in this instruction manual cannot cover all possible conditions and situations that
9
may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product,
but must be supplied by the operator.
2. INTRODUCTION
High performance pistol grip borescopes with 5"/127mm true colour LCD display screen. Includes 2000mm long waterproof probe pod
with IP67 rating. High brightness LED auxiliary lighting enables use in multiple environments. Features video record/playback, still images
and stream live video via the AV out connection. Comfortable pistol grip handle and clear function buttons allows one handed operation.
4GB Micro SD card (supplied) stores up to 4.5 hours of video and 10,000 images, which can be transferred to a PC via the USB
connection. Features 180° screen rotation function for increased flexibility in application. Powered by lithium-ion battery pack, providing up
to 6 hours continuous use. AV and Type-C USB charging cable supplied. Supplied in storage case. The VS8118 is equipped with dual lens
for both forward and side camera view.
