- Page 1 User Manual TPH 1m Temperature and Humidity Sensor Scan the QR code or enter following URL to get the latest version: https://docs.mobatime.cloud/TPH-1m BE-801435.1-TPH 1m | 2025-04-25...
-
Page 3: Important Notes
The information in this document is subject to change without notice. The latest version of this document is available for download at https://docs.mobatime.cloud/TPH-1m . This User Manual has been composed with the utmost care to explain all the details to ensure a safe and stable operation of this product. -
Page 4: Table Of Contents
Table of Contents 1. Safety ........ -
Page 5: Safety
TPH 1m – Temperature and Humidity Sensor | User Manual Safety 1 Safety Read the safety instructions carefully and follow all the instructions. This ensures safe and reliable operation of this device. 1.1. Instructions and Symbols Symbols used throughout this document and their meaning are as follows: A note or important information. -
Page 6: Installation
Safety TPH 1m – Temperature and Humidity Sensor | User Manual Never open the housing of this product, for it poses mortal danger from electric shock or may even cause a fire. Keep packaging such as plastic films away from children. There is the risk of suffocation of misused. -
Page 7: Maintenance And Cleaning
TPH 1m – Temperature and Humidity Sensor | User Manual Safety 1.5. Maintenance and Cleaning • If the product and/or the connecting cable is damaged, do not touch it: there is mortal danger from electric shock! First, turn off the power supply to all poles of the product. -
Page 8: Introduction
TPH 1m – Temperature and Humidity Sensor | User Manual 2 Introduction Versatile temperature and humidity sensor designed for seamless integration with digital clocks. The TPH 1m sensor is available in 1 m variant, offering a direct and hassle-free connection. -
Page 9: Technical Data
TPH 1m – Temperature and Humidity Sensor | User Manual Technical data 3 Technical data Parameter TPH 1m Scope of Measured Temperatures -40 °C to +80 °C Measuring Accuracy – Temperature ±0.3 °C at 25 °C Scope of Measured Humidity... -
Page 10: Connection To Digital Clock
TPH 1m – Temperature and Humidity Sensor | User Manual 4 Connection to Digital Clock To the digital clock, one or two sensors TPH 1m (or combine TPH 1m + any other sensor) can be connected. In the case of two temperature sensors, they share a common power supply. -
Page 11: Screw Connectors
TPH 1m – Temperature and Humidity Sensor | User Manual Connection to Digital Clock Two Sensors Connection Wire Color Connector Red (both sensors) Yellow (sensor 1) TEMP1 Yellow or Blue (sensor 2) TEMP2 Black (both sensors) or − White (sensor 2) 4.3. -
Page 12: Digital Clock Settings
Digital Clock Settings TPH 1m – Temperature and Humidity Sensor | User Manual 5 Digital Clock Settings SENx Enter the digital clock main menu, navigate to the submenu and proceed to enter. Navigate to item and check whether the value is set to The digital clock will display the measured temperature within about 20 seconds after connection.
