Cleerline SSF-48UHD-AOC-60m Troubleshooting Manual

SSF 8K UHD HDMI AOC Troubleshooting
™
8K UHD, 48 Gbps, HDR, Plenum Jacket, CMP FT6
STEP 1 Does your cable look like the cable in Figure 1 or is your
cable's part number included below (SSF-48UHD-AOC-XXm)?
PART NUMBER
SSF-48UHD-AOC-05m
SSF-48UHD-AOC-07.5m
SSF-48UHD-AOC-10m
SSF-48UHD-AOC-12.5m
SSF-48UHD-AOC-15m
SSF-48UHD-AOC-20m
SSF-48UHD-AOC-30m
SSF-48UHD-AOC-40m
SSF-48UHD-AOC-60m
If YES, continue to step 2.
If cable is Cleerline SSF™ 4K Active Optical Cable (SSF-
UHDAOCXXM), pictured in Figure 2 (plastic heads), please
contact Cleerline Tech Support at 866-469-2487.
STEP 2 Cable is directional. Was the "Source" head connected to
source and "Display" Head to display (Figure 3)?
Figure 3
If YES, continue to step 3.
STEP 3
If YES, continue to step 4.
CLEERLINE TECHNOLOGY GROUP, LLC
USA & CAN: 886-469-2487 Int'l +1-406-541-9830
www.cleerline.com
Guide
LENGTH
5 m / 16.4 ft
7.5 m / 24.6 ft
10 m / 32.8 ft
12.5 m / 41.0 ft
15 m / 49.2 ft
20 m / 65.62 ft
30 m / 98.43 ft
40 m / 131.23 ft
60 m / 196.85 ft
Figure 1
Figure 2
Figure 4
REV : 08/26/2024
All right reserved. Subject to change without notice
Copyright 2012 Cleerline Technology Group, LLC
PAGE 1
