DISPLAY
General Installation Instructions
SOURCE
Cable is directional. Connector Head marked
"SOURCE" must connect to Source. Connector
DISPLAY
Head marked "DISPLAY" must connect to Display.
SOURCE
8K
Cables installed improperly will not function.
If the Source or Display cannot provide
8K
adequate embedded 5V power external power
is required. See other side.
www.cleerlinefiber.com | info@clrtec.com
Advertisement
Table of Contents
Related Manuals for Cleerline SSF-48UHD-AOC-05m
Summary of Contents for Cleerline SSF-48UHD-AOC-05m
- Page 1 “SOURCE” must connect to Source. Connector DISPLAY Head marked “DISPLAY” must connect to Display. SOURCE Cables installed improperly will not function. If the Source or Display cannot provide adequate embedded 5V power external power is required. See other side. www.cleerlinefiber.com | info@clrtec.com...
- Page 2 If Source or Display cannot provide adequate embedded 5V power, external power supply is required. Place included HDMI to USB cord inline at Source/Tx or Display/Rx. Diagram DISPLAY shows placement at Display/Rx. Connect USB to external 5V power supply (not included). SOURCE www.cleerlinefiber.com | info@clrtec.com...
