Model No. PCTL59104.1
Serial No.
Write the serial number in the space
above for future reference.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing parts, please call:
1-888-936-4266
Mon.–Fri. 8h00 until 17h00 EST
(excluding holidays).
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this man-
ual for future reference.
USER'S MANUAL
Visit our website at
www.proform.com
Visit our website at

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CROSSWALK CALIBER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pro-Form CROSSWALK CALIBER

Summary of Contents for Pro-Form CROSSWALK CALIBER

  • Page 1 USER'S MANUAL Model No. PCTL59104.1 Serial No. Write the serial number in the space above for future reference. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing parts, please call: 1-888-936-4266 Mon.–Fri.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS IMPORTANT PRECAUTIONS ..............3 BEFORE YOU BEGIN .

  • Page 3: Important Precautions

    IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure that all users of this treadmill are adequately 11.
  • Page 4 20. When using iFIT.com CDs and videos, an 23. Inspect and properly tighten all parts of the electronic “chirping” sound will alert you treadmill every three months. when the speed and/or incline of the treadmill 24. Never drop or insert any object into any open- is about to change.

  • Page 5: Before You Begin

    Congratulations for purchasing the PROFORM ® reading this manual, please see the front cover of this CROSSWALK CALIBER treadmill. The CROSSWALK manual. To help us assist you, note the product model CALIBER treadmill offers an impressive array of fea- number and serial number before calling. The model tures to help you achieve your fitness goals in the con- number of the treadmill is PCTL59104.1.

  • Page 6: Assembly

    ASSEMBLY Assembly requires two persons. Set the treadmill in a cleared area and remove all packing materials. Do not 1” Tek Screw dispose of the packing materials until assembly is completed. Note: The underside of the treadmill walking belt is 1”...
  • Page 7 2. Attach six Base Pads (125) to the bottom of the Base (131) with six 1” Tek Screws (126). Note: Only four Base Pads are shown. With the help of another person, carefully tip the tread- mill so that the Base Pads (125) are resting on the floor. 3.
  • Page 8 5. See the inset drawing. Make sure that there are two U- nuts (112) in the upper end of the Right and Left Uprights (119, not shown). Extra U-nuts may be included. Identify the right Handrail (108) and the left Handrail (there is an identification sticker on each Handrail).
  • Page 9 8. With the help of another person, hold the console as- sembly near the Right Upright (119) and the left Upright (not shown). Console Assembly Connect the Wire Harness (118) to the wire harness in the console assembly. Make sure to connect the con- nectors properly (see the inset drawing);...

  • Page 10: Treadmill Operation

    TREADMILL OPERATION THE PRE-LUBRICATED WALKING BELT plug. Plug the power cord into a surge suppressor, and plug the surge suppressor into an appropriate Your treadmill features a walking belt coated with high- outlet that is properly installed and grounded in performance lubricant.

  • Page 11: Features Of The Console

    Clip Note: If there is a sheet of clear plastic on the console, remove the plastic. FEATURES OF THE CONSOLE stereo, portable stereo, computer, or VCR and play special iFIT.com CD and video programs (iFIT.com The treadmill console offers an impressive array of CDs and videocassettes are available separately).

  • Page 12: How To Turn On The Power

    is held down, the speed setting will change in in- HOW TO TURN ON THE POWER crements of 0.5 mph. To change the speed setting quickly, press the Quick Start buttons. Note: To prevent damage to the walking platform, To stop the walking belt, press the Stop button. always wear clean shoes when using the treadmill.
  • Page 13 Distance/Incline dis- To use the handgrip pulse sensor, first make sure play—This display that your hands are clean. Next, stand on the foot rails and hold the pulse bar with your palms shows the distance that on the metal contacts. Avoid moving your you have walked or run and the incline level of hands.
  • Page 14 The speed setting for the HOW TO USE PRESET PROGRAMS Current Segment first segment is shown in the flashing Current Insert the key fully into the console. Segment column of the matrix. (The incline set- tings are not shown in See HOW TO TURN ON THE POWER on the matrix.) The speed page 12.
  • Page 15 To stop the program at any time, press the Stop When you are finished exercising, remove the button. The Time/Pace display will begin to flash. key from the console. To restart the program, press the Start button or the Speed increase button. The walking belt will When the program ends, make sure that the in- begin to move at 1 mph.
  • Page 16 During heart rate pro- HOW TO USE HEART RATE PROGRAMS grams, the matrix will show a moving graphic that represents your CAUTION: heart rate. Each time a If you have heart prob- heartbeat is detected, lems, or if you are over 60 years of age and an additional peak will have been inactive, do not use the heart rate appear.
  • Page 17 If the speed or incline setting is too high or too low Press the Start button or the Speed increase at any time during the program, you can adjust the button to start the program. setting with the Speed or Incline buttons. However, each time the console compares your heart rate to A moment after the button is pressed, the tread- the current target heart rate, the speed and/or in-...
  • Page 18 HOW TO CONNECT YOUR PORTABLE STEREO HOW TO CONNECT THE TREADMILL TO YOUR CD PLAYER, VCR, OR COMPUTER Note: If your stereo has an RCA-type AUDIO OUT jack, see instruction A below. If your stereo has a 3.5mm LINE OUT jack, see instruction B. If your To use iFIT.com CDs, the treadmill must be connected stereo has only a PHONES jack, see instruction C.
  • Page 19 HOW TO CONNECT YOUR HOME STEREO HOW TO CONNECT YOUR COMPUTER Note: If your stereo has an unused LINE OUT jack, Note: If your computer has a 3.5mm LINE OUT jack, see instruction A below. If the LINE OUT jack is see instruction A.
  • Page 20 HOW TO CONNECT YOUR VCR HOW TO USE IFIT.COM CD AND VIDEO PROGRAMS Note: If your VCR has an unused AUDIO OUT jack, see instruction A below. If the AUDIO OUT jack is being used, see instruction B. If you have a TV To use iFIT.com CDs or videocassettes, the treadmill with a built-in VCR, see instruction B.
  • Page 21 • Make sure that the audio cable is properly If the speed or incline settings are too high or too low, you can manually override the settings at any connected, that it is fully plugged in, and that it is not wrapped around a power cord. time by pressing the Speed or Incline buttons on the console.
  • Page 22 Hold the handrails, step onto the walking belt, and HOW TO USE PROGRAMS DIRECTLY FROM begin walking. During the program, an electronic OUR WEB SITE “chirping” sound will alert you when the speed and/or incline of the treadmill is about to change. CAUTION: Always listen for the “chirp”...
  • Page 23 THE INFORMATION MODE/DEMO MODE THE OPTIONAL CHEST PULSE SENSOR The console features an information mode that keeps An optional chest pulse sensor adds even more track of total number of miles that the walking belt has features to the console. The chest pulse sensor provides moved and the total number of hours that the treadmill hands-free operation and allows the console’s heart has been used.

  • Page 24: How To Fold And Move The Treadmill

    HOW TO USE THE UPPER BODY ARMS As you walk on the treadmill, you can either hold the handrails or use the upper body arms. To exercise your arms, shoulders, and back for a total body workout, move the upper body arms forward and back as you walk on the treadmill.

  • Page 25: How To Move The Treadmill

    HOW TO MOVE THE TREADMILL Before moving the treadmill, convert the treadmill to the storage position as described above. Make sure that the pin on the latch knob is fully inserted into the hole in the left handgrip. 1. Hold the treadmill and place one foot on a wheel. 2.

  • Page 26: Troubleshooting

    TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call the toll-free telephone number on the front cover of this manual. PROBLEM: The power does not turn on SOLUTION: a.
  • Page 27 Locate the Reed Switch (47) and the Magnet (35) on the left side of the Pulley (36). Turn the Pulley until the Magnet is aligned with the Reed Switch. Make sure that the gap between the Magnet and the Reed Switch is about 3mm (1/8 in.). If necessary, loosen the Screw (16), move the Reed Switch slightly, and then retighten the Screw.
  • Page 28 PROBLEM: One of the upper body arms squeaks during use SOLUTION: a. Correcting this problem requires a small amount of white marine grease, available at most hardware stores. Turn the Resistance Knob (83) counterclock- wise until it can be removed. Remove the Resistance Cone (89) and the Upper Body Arm (95), along with the Resistance Knob Washers (120), Spring Washer (85), Thrust Washers (86), and Thrust Bearing (87).

  • Page 29: Exercise Guidelines

    EXERCISE GUIDELINES ergy. Only after the first few minutes does your body WARNING: begin to use stored fat calories for energy. If your goal Before beginning this is to burn fat, adjust the speed or incline of the tread- or any exercise program, consult your physi- mill until your heart rate is near the lowest number in cian.

  • Page 30: Part List

    PART LIST—Model No. PCTL59104.1 R0805A To locate the parts listed below, see the EXPLODED DRAWING attached in the center of this manual. Key No. Qty. Description Key No. Qty. Description Spring Top Cap Motor Star Washer Spring Nut 1/2” Screw Spring Ground Wire Spring Bottom Cap...
  • Page 31 Key No. Qty. Description Key No. Qty. Description Console Incline Motor Bolt (Top) Right Cup Holder (Top) Base Right Cup Holder (Bottom) 3/8” Star Washer Console Back Upright Bolt Accessory Door Wheel Bolt Left Handgrip (Top) Front Roller Bolt Left Handgrip (Bottom) Wheel Handrail Optic Switch Nut...

  • Page 32: How To Order Replacement Parts

    • The MODEL NUMBER of the product (PCTL59104.1) • The NAME of the product (PROFORM CROSSWALK CALIBER treadmill) ® • The SERIAL NUMBER of the product (see the front cover of this manual) • The KEY NUMBER and DESCRIPTION of the part(s) (see the PART LIST on pages 30 and 31) LIMITED WARRANTY ICON OF CANADA, INC., (ICON), warrants this product to be free from defects in workmanship and ma-...
