- Page 1 QuickStart Guide FortiWiFi 50G SFP FWF-50G-SFP, FWF-51G-SFP FWF-50G-SFP-QSG-20240523.indd 1 FWF-50G-SFP-QSG-20240523.indd 1 5/23/2024 10:34:01 AM 5/23/2024 10:34:01 AM...
- Page 2 FortiGate Cloud Experience simplified cloud provisioning, security analytics, remote access, hosted log retention and reporting at https://fortigate.forticloud.com FortiExplorer Go Rapidly provision, deploy and manage your Fortinet Security Fabric Platform, free on iOS and Android: https://docs.fortinet.com/product/fortiexplorer-go/ FWF-50G-SFP-QSG-20240523.indd 2 FWF-50G-SFP-QSG-20240523.indd 2 5/23/2024 10:34:01 AM...
-
Page 3: Package Contents
Package Contents FortiWiFi 50G SFP FWF-50G-SFP 1x FortiWiFi Device 1x QuickStart Guide 3x AC Adapter Plugs 1x DC Power Adapter (US, EU, UK) 3x Antennas 1x Ethernet Cable FWF-50G-SFP-QSG-20240523.indd 3 FWF-50G-SFP-QSG-20240523.indd 3 5/23/2024 10:34:01 AM 5/23/2024 10:34:01 AM... - Page 4 Setup FortiExplorer Go Install Enable Follow the on-screen FortiExplorer Go Bluetooth instructions Port 1 If Static IP: 192.168.1.1/24 Ethernet Cable FWF-50G-SFP-QSG-20240523.indd 4 FWF-50G-SFP-QSG-20240523.indd 4 5/23/2024 10:34:02 AM 5/23/2024 10:34:02 AM...
- Page 5 None (available for purchase) Flow Control: None Console Port FortiGate Cloud Login to https://fortigate.forticloud.com using your Fortinet Credentials, then click Add FortiGate and enter the Cloudkey Internet Ethernet Cable WAN port FWF-50G-SFP-QSG-20240523.indd 5 FWF-50G-SFP-QSG-20240523.indd 5 5/23/2024 10:34:02 AM 5/23/2024 10:34:02 AM...
- Page 6 Flashing Blue: BLE in discovery Off: BLE not connected Signed Firmware BIOS Security Level Controlled by Signed Firmware Switch, see Admin Guide at https://docs.fortinet.com Green: Security Level 2 (default) Amber: Security Level 1 Red: Security Level 0 FWF-50G-SFP-QSG-20240523.indd 6 FWF-50G-SFP-QSG-20240523.indd 6...
- Page 7 LINK/ACT SPEED WIFI Green: WiFi is on Green: Power detected Green: WiFi activity Off: Power not detected Flashing Off: WiFi is off STATUS Green: Operating normally Green: Booting up Flashing Off: Device is off Green: HA enabled (normal) Amber: HA enabled (failover) Off: HA disabled Ethernet Ports LINK/ACT...
- Page 8 Rear FWF-50G-SFP WIFI WIFI Signed Firmware Power Input 12V DC, 100-240V AC, 50/60Hz adapter USB 3.0 Port (USB-A) CONSOLE Port (RJ-45) CLI management Signed Firmware Switch FWF-50G-SFP-QSG-20240523.indd 8 FWF-50G-SFP-QSG-20240523.indd 8 5/23/2024 10:34:02 AM 5/23/2024 10:34:02 AM...
- Page 9 WIFI WIFI SFP Port (SFP) Ports (5x RJ-45) WAN, A – FortiLink, 3, 2, 1 Antenna Connector (3x SMA) FWF-50G-SFP-QSG-20240523.indd 9 FWF-50G-SFP-QSG-20240523.indd 9 5/23/2024 10:34:02 AM 5/23/2024 10:34:02 AM...
-
Page 10: Cautions And Warnings
Cautions and Warnings Environmental specifications Ambient operating temperature: 0°C to 40°C Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature, Storage Temperature, Humidity, and Altitude) Référez à la Fiche Technique de ce produit pour les caractéristiques environnementales (Température de fonctionnement, température de stockage, humidité et l’altitude). Safety Battery –... -
Page 11: Regulatory Notices
Regulatory Notices Federal Communication Commission (FCC) – USA This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. - Page 12 EU or countries that have implemented the EU Directives and/or spectrum regulation. Any Fortinet products not obtained directly from Fortinet or Fortinet’s authorized partners may not comply with EU Directives and Fortinet makes no assurances for such products.
- Page 13 Denna produkt överensstämmer med direktiv 2014/53/EU. Note: The full Declaration of Conformity for this product is available in the link below: https://site.fortinet.com/ProductRegulatory/EU The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range in the following countries:...
- Page 14 This product is in compliance with Statutory Instrument 1206 Radio Equipment Regulations 2017 The full Declaration of Conformity for this product is available in the link below: https://site.fortinet.com/ProductRegulatory/UK The device is restricted to indoor use only when operating in the 5150 to 5350 MHz frequency range in the following countries: FWF-50G-SFP-QSG-20240523.indd 14...
- Page 15 FWF-50G-SFP-QSG-20240523.indd 15 FWF-50G-SFP-QSG-20240523.indd 15 5/23/2024 10:34:03 AM 5/23/2024 10:34:03 AM...
- Page 16 Nothing herein represents any binding commitment by Fortinet, and Fortinet disclaims all warranties, whether express or implied, except to the extent Fortinet enters a binding written contract, signed by Fortinet’s SVP Legal and above, with a purchaser that expressly warrants that the identified product will perform according to certain expressly-identified performance metrics and, in such event, only the specific performance metrics expressly identified in such binding written contract shall be binding on Fortinet.
