Riverside Furniture 46238 Assembly Instructions

email: info@riverside-furniture.com
Warning :
- Be sure to check all packing material carefully for small parts,
which may have come loose inside the carton during shipment.
- To prevent possible scratches and damage, this furniture MUST
BE ASSEMBLED BY TWO PEOPLE on a soft surface such as
a blanket or carpet.
Components and Hardware List
Chair Seat Chair Control
& Back
A B
1 pc.
Caster
Allen Head Bolt
Ø5/16 x 18 x 1-1/8"
F G
5 pcs.
Step 1
C
Step 3
D
Assembly Instructions
Metal Base
C
1 pc. 1 pc.
Spring Washer
Ø5/16 x Ø14
H
4 pcs. 4 pcs.
Vogue
Home Office
Wood Cap Pneumatic
Cylinder & Cover
D E
5 pcs.
Flat Washer Allen Key 4mm
Ø5/16 x Ø18
I J
4 pcs.
Step 2
Made in Viet Nam
46238
Upholstered Desk Chair
1 pc.
Screw M4 x 5/8"
Phillips Screwdriver
K
1 pc. 10 pcs.
If present, remove
the plastic cover
from the top end of
the cylinder before
assembling to seat.
K
Page 1 of 2
Tool Required
(Not provided)
