  • Page 1 EN User Manual | Washer Dryer LWN8E8636F aeg.com\register...

  • Page 2: Table Of Contents

    Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. PRODUCT DESCRIPTION................7 4. TECHNICAL DATA..................8 5.

  • Page 3: General Safety

    • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved.
  • Page 4 • Do not install the appliance behind a lockable door, a sliding door or a door with a hinge on the opposite side, that would prevent the appliance door from being fully open. • Connect the mains plug to the mains socket only at the end of the installation process.

  • Page 5: Safety Instructions

    be washed separately with an extra amount of detergent before being dried in the washer dryer. • Do not use the appliance if items have been soiled with industrial chemicals. • Do not dry unwashed items in the wash dryer. •...

  • Page 6: Electrical Connection

    • The floor area on which the appliance is to Service Centre for the replacement of the be installed must be flat, stable, heat inlet hose. resistant and clean. • When unpacking the appliance, It is • Keep the transit bolts in a safe place. If the possible to see water flowing from the appliance is to be moved in the future they drain hose.

  • Page 7: Product Description

    consequences and might void the These lamps are intended to withstand guarantee. extreme physical conditions in household • The following spare parts will be available appliances, such as temperature, for 10 years after the model has been vibration, humidity, or are intended to discontinued: motor and motor brushes, signal information about the operational transmission between motor and drum,...

  • Page 8: Technical Data

    • Get usage advice, troubleshooting, service and repair information (also available at aeg.com/ support ) • Buy accessories, Consumable and Original Spare parts for you appliance (also available at aeg.com/ shop ) 4. TECHNICAL DATA Dimension Width/ Height/ Total depth 59.6 cm /81.9 cm /55.3 cm...
  • Page 9 5.1 Be prepared for installation 5.2 The appliance is equipped with ... It is recommended that installation is carried out by two persons. 5.3 Unpacking WARNING! Use the gloves. WARNING! Remove all the packaging and the transit bolts before installing the appliance. 1.
  • Page 10 3. Remove the protection from the bottom. 4. Return the appliance in vertical position and remove the socket protection. 5. Remove the power supply cable and the drain hose from the hose holders. It is possible to see water flowing from the drain hose.

  • Page 11: Positioning And Levelling

    7. Close the holes with the plastic caps you find in the user manual bag. Put the smallest cap F in upper hole and the two bigger caps G in lower holes. We recommend that you keep the packaging and the transit bolts for any movement of the appliance.
  • Page 12 5.5 Hose and cable connection 1100 mm 1450 mm 1230 mm 960 mm 1360 mm 900 mm The inlet hose 1. Remove the inlet hose from inside the drum. 2. To connect the water inlet hose towards the proper direction and with the proper inclination, check the position of the water tap before connecting it to the back of the appliance.

  • Page 13: Water Drainage

    5. Connect the water inlet hose to the cold water tap with 3/4 thread. WARNING! The inlet water shall not exceed 25 °C. WARNING! Make sure that there are no leaks from the couplings. Use the hose supplied with appliance. Do not use an extension hose if the inlet hose is too short.
  • Page 14 To a wall-pipe Directly to a built-in drain pipe in the room wall and tighten it with the supplied cable tie L. You can extend the drain hose to maximum 400 cm. Contact the service centre for the other drain hose and the extension. 5.6 Building in This appliance has been designed to be built into the kitchen furniture.
  • Page 15 The appliance is also equipped with an adhesive sponge pad H that you can find inside the drum. Attach it on the top of the appliance where indicated in the drawing. When levelling the appliance under the furniture, DO NOT squeeze the sponge pad. Before proceeding with appliance building in, bring it near the recess and preposition the inlet hose, the drain hose and the mains cable.
  • Page 16 Reversibility of the cupboard door Carry out the cupboard door reversibility before the appliance is built in completely. If the cupboard door has to be opened from left to right, invert the position of the hinge supports M with the magnetic plate N and lower plate O. Make sure that the plate with magnet is on the upper position.
  • Page 17 Set the position of the lower hole respecting dimensions and distances shown in the drawing 16-22 mm (449 mm). Countersink the holes. Ø 35 mm 12,5 - 14 mm 22±1,5 mm 595-598 mm Hinges To mount the hinges it is necessary to drill two holes (dia.
  • Page 18 Counter-magnet The appliance is pre set for a magnetic closure. For a correct closure: 1. Position the screw C and the counter-magnet D on the magnetic plate N. Lean the cupboard door against the screw until it leaves a mark. 2.

  • Page 19: Control Panel

    6. CONTROL PANEL 6.1 Control panel description Inicio Diferido touch button Modo - Secar touch button and The permanent options are set by permanent Anti-crease option holding pressed the relative button for at Time Manager touch button and least 3 seconds. permanent Child Lock option Programme dial Manchas touch button and permanent...
  • Page 20 6.2 Display The Temperature area: Temperature indicator . Cold water indicator. Door locked indicator. Child safety lock indicator. The digital indicator can show: • Programme duration (e. g. , washing and/or drying phase). • Delay time (e. g. • Cycle end ( •...

  • Page 21: Dial And Buttons

    OkoMix phase indicator. Drum clean indicator. This is a recommendation to perform the drum cleaning. Re‐ fer to paragraph "Cleaning the drum" in "Care and cleaning" chapter. Anti-crease phase indicator. Read the 'Permanent Anti-crease' paragraph for more details. Drying phase indicator. The spin area: Spin speed indicator No Spin indicator.

  • Page 22: Permanent Extra Rinse

    When it is activated, the appliance will default • Activate the Rinse Hold option. to this option after you switch it off or change/ The final spin is not performed. The water reset the programme. of the last rinse is not drained out to prevent the fabrics from creasing.

  • Page 23: Child Lock

    When you set a washing programme, the 7.11 Child Lock display shows the default duration and With this option you can prevent children from dashes. playing with the control panel. Touch Time Manager button to reduce the To activate/deactivate this option, hold the programme duration according to your needs.
  • Page 24 • Press the On/Off button for a few seconds you have to dry (refer to "Timed drying" to activate or the deactivate the appliance. table). The display shows the set value. • Turning the programme dial in another Each time you touch this button the time position.

  • Page 25: Programmes

    8. PROGRAMMES 8.1 Programme Chart Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1600 rpm 8.0 kg 1600 rpm - Eco 40-60 (Wash 400 rpm only mode) 40 °C White cotton and fast-coloured cotton.
  • Page 26 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1.0 kg Cottons, Synthetics, Delicates. Short and gentle steam pro‐ gramme to refresh even your very delicate garments, includ‐ Vapor ing very delicate garments with sequins, lace etc.
  • Page 27 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range 1200 rpm 3.0 kg Synthetic sport items. This programme is designed to gently (1200- 400 wash modern outdoor sportswear and is also suitable for Sports rpm) gym, cycling or jogging clothes or similar.
  • Page 28 Programme Reference Maxi‐ Programme description Default tempera‐ spin speed (Type of load and level of soiling) ture Spin speed load Temperature range range Reset position. The display shows dashes only. According to Commission Regulation EU 2019/2023. This programme at default temperature and spin speed, in washing only mode, with rated capacity 8.0 kg is able to clean normally soiled cotton laundry declared to be washable at 40 °C or 60 °C, together in the same cycle.
  • Page 29 Programme ■ ■ Vapor ■ ■ ■ Centrif.\Drenar ■ ■ ■ ■ ■ ■ Aclarado/Enxag. ■ ■ ■ Limp. Máquina ■ ■ ■ ■ ■ ■ ■ ■ ■ Higienizar ■ ■ ■ ■ ■ ■ ■ Sports ■ ■ ■...

  • Page 30: Automatic Drying

    ▲ ▲ Delicados ▲ ▲ Higienizar ▲ ▲ ▲ Higienizar ▲ ▲ ▲ Sports ▲ ▲ Outdoor ▲ ▲ Lana\Lãs ▲ ▲ Camisas20’ Lava +Seca60´ At temperature higher than 60 °C the use of powder detergent is recommended. ▲ = Recommended Woolmark Company for the washing of wool garments labelled as “hand wash”...

  • Page 31: Timed Drying

    Dryness Level Type of fabric Load Cottons and Linen up to 4.0 kg (bathrobes, bath towels, etc) Extra Dry For towelling materials Denim garments up to 3.0 kg Cottons and Linen up to 4.0 kg (bathrobes, bath towels, etc) Cupboard Dry For items to be stored Synthetics and mixed fabrics up to 3.0 kg...

  • Page 32: Settings

    Dryness Level Type of fabric Load Spin Suggested du‐ (kg) speed ration (mins) (rpm) Synthetics and mixed fabrics 1200 135 - 150 (jumpers, blouses, underwear, household and bed linen) 1200 45 - 55 Delicates 1200 155 - 165 (acrylics, viscose and delicate mixed fabrics) 1200 95 - 105 Wool...

  • Page 33: Before First Use

    10. BEFORE FIRST USE 1. Make sure that the electrical power is 4. Set and start a programme for cotton at available and the water tap is open. the highest temperature without any 2. Pour 2 litres of water into the detergent laundry in the drum.

  • Page 34: Setting A Programme

    With the flap in the position DOWN: • Do not use gelatinous or thick liquid - Flap for powder or liquid detergent. detergents. • Do not exceed to liquid detergent dose indicated on the flap. • Do not set the prewash phase. Always follow the instructions that you •...

  • Page 35: Starting A Programme With The Delay Start

    11.6 Starting a programme 2. Touch the Inicio Diferido button repeatedly until the display shows the Touch the Inicio/Pausa button to start the desired delay time. programme. It is not possible to start the 3. Touch the Inicio/Pausa button again programme when the indicator of the button to start the new countdown.

  • Page 36: Interrupting A Programme And Changing The Options

    If the ProSense Technology has About 20 minutes after the programme completed and the water filling has start, the programme duration could be already started, the new programme adjusted again depending on the starts without repeating the ProSense capacity of water absorption of the Technology.

  • Page 37: Stand-By Function

    The indicator of the Inicio/Pausa button The option indicator Rinse Hold goes off. disappears. The door unlocks and the indicator goes off. If you have selected No Spin , the 1. Press button On/Off to deactivate the appliance will only drain the water. appliance.

  • Page 38: At The End Of The Drying Programme

    12.1 Complete wash&dry programme To have a good drying by using less energy and in a shorter time, the Non-automatic wash&dry programmes appliance does not let you set a too low In some washing programmes, you can spin speed for the items to be washed combine Modo - Lavar and Modo - Secar for and dried.

  • Page 39: Daily Use - Drying Only

    remove the laundry when the phase is 1. Remove the laundry from the appliance. almost completed or completed. The 2. Make sure that the drum is empty. indicator remains lit. • Press the On/Off button for some seconds After drying phase, clean the drum, the to deactivate the appliance.

  • Page 40: Fluff In The Fabrics

    13.4 At the end of the drying almost completed or completed. The programme indicator remains lit. • Press the On/Off button for some seconds • The appliance stops automatically. to deactivate the appliance. • The acoustic signals operate (if they are active).

  • Page 41: Stubborn Stains

    15.2 Stubborn stains • Do not wash white and coloured items together. For some stains, water and detergent is not • Some coloured items can discolour with sufficient. the first wash. We recommend that you wash them separately for the first couple We recommend that you pre-treat these of times.

  • Page 42: Ecological Hints

    • Do not mix different types of detergents. In areas where the water is soft it is not • Use less detergent if: necessary to use a water softener. – you are washing a small load, To find out the water hardness in your area, –...

  • Page 43: Additional Drying

    • type of laundry Experience will help you to dry the laundry • weight of the load better. Take note of the duration of the cycles done before. 15.10 Additional drying To avoid the static charge at the end of the drying cycle: If, at the end of the drying programme, the laundry is still damp, set a short drying cycle...

  • Page 44: Maintenance Wash

    CAUTION! Do not use alcohol, solvents or chemical products. CAUTION! Do not clean the metal surfaces with chlorine-based detergent. 16.4 Descaling Clean it when needed, using ammonia cream cleanser agent without scratching the seal surface. If the water in your area is hard or medium hard, we recommend that you use a water softener for washing Always obey the instructions that you find...

  • Page 45: Cleaning The Detergent Dispenser

    the recess. Use a small brush to clean the recess. Occasionally, at the end of a cycle the display may show the icon : this is a recommendation to perform the “drum cleaning”. Once the drum cleaning has been performed, the icon disappears. 16.8 Cleaning the detergent dispenser To prevent possible deposits of dried...
  • Page 46 WARNING! • Do not remove the filter while the appliance operates. • Do not clean the pump if the water in the appliance is hot. Wait until the water cools down Proceed as described in following diagrams to clean the pump filter: 1.
  • Page 47 6. Turn the filter anti-clockwise to remove it 7. If it is necessary, remove fluff and objects from the filter recess. Make sure that the impeller of the pump can rotate. If it does not rotate, contact the Authorised Service Centre.

  • Page 48: Cleaning The Inlet Hose And The Valve Filter

    10. Close the pump cover. When you drain the water with the emergency drain procedure, you must activate the drain system again: 1. Put 2 litres of water in the main wash compartment of the detergent dispenser. 2. Start the programme to drain the water. 16.10 Cleaning the inlet hose and remove any deposit, collected over the time.

  • Page 49: Emergency Drain

    16.11 Emergency drain 1. Disconnect the mains plug from the mains socket. If the appliance cannot drain the water, carry 2. Close the water tap. out the same procedure, described in 3. Put the two ends of the inlet hose in a 'Cleaning the drain pump' paragraph.
  • Page 50 With some problems, the display shows an alarm code and the Inicio/ Pausa button may flash continuously: If the appliance is overloaded, remove some items from the drum and/or keep pressed the door while touching the Inicio/Pausa button until the indicator stops flashing (see the picture below).
  • Page 51 • Disconnect the appliance and close the water tap. Contact the Authorised Service Centre. The anti-flood device is on. If the display shows other alarm codes, deactivate and activate the appliance. If the problem continues, contact the Authorised Service Centre. In case of different problem with the appliance check the table below for possible solutions.

  • Page 52: Emergency Door Opening

    Problem Possible solution • Increase the detergent quantity or use a different detergent. • Use special products to remove the stubborn stains before you wash the laun‐ The washing results are not dry. satisfactory. • Make sure that you set the correct temperature. •...

  • Page 53: Consumption Values

    appliance door. The emergency unlock 4. Take out the laundry and then close the trigger is located where indicated by the appliance door. following picture. 18. CONSUMPTION VALUES 18.1 Introduction See the web link www.theenergylabel.eu for detailed information about Energy Label. The QR code on the energy label supplied with the appliance provides a web link to the information related to the performance of the appliance in the EU EPREL database.

  • Page 54: Washing Only

    Values and programme duration may differ depending on different conditions (e.g. room temperature, water temperature and pressure, load size and type of laundry, supply voltage) and also if you change the default setting of a programme. 18.3 According to Commission Regulation Eu 2019/2023 Washing only Eco 40-60 pro‐...

  • Page 55: Environmental Concerns

    Programme rpm 1) Litres hh:mm °C Algod. 1.350 85.0 03:25 44.00 55.0 1600 60°C Algod. 0.250 85.0 02:50 44.00 20.0 1600 20°C Sintéticos 0.650 75.0 02:25 35.00 40.0 1200 40°C Delicados 0.360 50.0 01:10 35.00 30.0 1200 30°C Lana\Lãs 0.200 55.0 01:05 30.00...
  • Page 56 157075030-B-412024...
