Stanley SL5W09 Manual

FEATURES

1. 5 watt LED bulb
2. Rubber Bezel
3. On/Off Trigger
4. Pistol Grip Handle
5. Battery/Charge Status LED Indicator
6. Micro-USB charging port (for use with the USB Charging Cable)
7. USB charging cable
8. Regular USB plug
9. Micro-USB plug

READING THE BATTERY/CHARGE STATUS LED INDICATOR

The battery and charging status LED indicator is located on the back of the unit. It lights or flashes in three colors to indicate the following:

When charging:
Green: Battery is in a fully charged state.
Green (flashing): Battery is in a high partially charged state.
Orange (flashing): Battery is in a low partially charged state.
Red (flashing): Battery needs to be recharged.
Red (flashing rapidly): The battery of the unit is overheated due to extensive use or recharging. The charging process will stop at this stage and will automatically resume after a cool down period.

When operating:
Green: Battery is operating at full voltage.
Orange: Battery is operating at partial voltage.
Red: Battery is operating at low voltage, and should be recharged or the built-in low voltage protection will be activated and the unit will automatically shut down shortly.
Red (flashing rapidly): The battery of the unit is overheated (due to extensive use or recharging), or is too cold (the ambient temperature has dropped below –20°C). Operation will stop at this stage.

CHARGING/RECHARGING THE PRODUCT

This unit is shipped in a partially charged state. Charge unit after purchase and BEFORE first use until the battery/charge status LED indicator lights green.
Recharge after each use until the battery/charge status LED indicator lights green.

When the unit is not in use, we recommend that the battery is charged at least every 3 to 6 months.

Only charge product using a Listed Class 2 USB power adapter that is compliant with applicable country regulations and international/regional safety standards. Using adapters that do not meet applicable safety standards could result in injury.

TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE:

• Never place the light face down on any surface when charging.
• Failure to keep the battery charged will cause permanent damage and result in poor performance.

Charging/recharging using the USB charging cable and a device with a USB power port (not supplied)

1. Make sure the spotlight is off.
2. Insert the micro-USB plug of the USB charging cable into the micro USB charging port on the back of spotlight.
3. Insert the regular USB plug of the USB charging cable into a device's functional USB power port. The battery/charge status LED indicator will light or flash in one of three colors (as described in the "Reading the Battery/Charge Status LED Indicator" section) to indicate the charging status.
4. Charge until the battery/charge status LED indicator lights green.
5. When charging is complete, disconnect the USB charging cable from the device's USB power port and the spotlight. Store the cable in a safe place.

OPERATING THE DEVICE

The On/Off Trigger turns the light on and off; and is also used to select the light mode.

DO NOT OPERATE WHILE CHARGING.

Disconnect the USB charging cable, then select the light mode as follows:

To protect the unit's internal battery from damage and save energy:

• If the light's battery voltage is nearly low, the unit will switch automatically to Low Light Mode even if the High Light Mode has been selected.
• If the light's battery voltage is low, the built-in low voltage protection will activate after a short period of operation, then the unit will automatically shut down. Recharge the battery before continuing use.

CARE AND MAINTENANCE

All batteries lose energy from self-discharge over time and more rapidly at higher temperatures. When the unit is not in use, we recommend that the battery is charged at least every 3 to 6 months.
If the unit gets dirty, gently clean the outer surfaces of the light unit with a soft cloth moistened with a mild solution of water and detergent.
There are no user-replaceable parts. Periodically inspect the condition of adapters, connectors and wires.

BATTERY REPLACEMENT
The battery should last the service life of the unit. Service life is dependent on a number of factors including but not limited to the number of recharge cycles, and proper care and maintenance of the battery by the end user. Contact manufacturer for any information you may need.

TROUBLESHOOTING

The unit will not charge

• Check that the light has been turned off.
• Check the connection to the light and the USB power source. Make sure there is good contact.
• Make sure the power source is functioning properly.
• The unit may have shut down to protect the battery from overheating after a long period of operation or charging. Disconnect the USB charging cable from the light and the power source. Allow the light to cool down for a period before resuming charging.

The unit will not operate

• Make sure the On/Off Trigger has been pressed to turn the spotlight on.
• The internal battery may be completely discharged. Charge the unit following the directions given in this manual.
• The unit may have shut down to protect the battery from overheating after a long period of operation or charging; or the ambient temperature has dropped below –20°C. Allow the spotlight to cool down or warm up for a period before resuming operation.
• If the ambient temperature is too hot or too cold the spotlight will not operate.

SPECIFICATIONS

SAFETY GUIDELINES / DEFINITIONS

Indicates an imminently hazardous situation which, if not avoided, will result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.

Used without the safety alert symbol indicates potentially hazardous situation which, if not avoided, may result in property damage.

RISK OF UNSAFE OPERATION. When using tools or equipment, basic safety precautions should always be followed to reduce the risk of personal injury. Improper operation, maintenance or modification of tools or equipment could result in serious injury and property damage. There are certain applications for which tools and equipment are designed. Manufacturer strongly recommends that this product NOT be modified and/or used for any application other than for which it was designed. Read and understand all warnings and operating instructions before using any tool or equipment.

READ ALL INSTRUCTIONS
Read all instructions before operating the spotlight. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury.

IMPORTANT SAFETY INSTRUCTIONS

INSTRUCTIONS PERTAINING TO RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS

RISK OF FIRE, ELECTRIC SHOCK, BURST HAZARD, OR INJURY TO PERSONS:

• LED gets HOT quickly!
• Do not touch the LED at any time when operating.
• Only contact trigger when turning on.
• Do not touch hot lens or enclosure.
• Do not remain in light if skin feels warm.
• Do not operate the spotlight with a missing or damaged lens or enclosure.
• The spotlight and the supplied charging cable are not toys and cannot be played with as toys. To reduce the risk of injury, close supervision is necessary when these units are used near children.
• Use only attachments recommended or sold by the manufacturer.

TO REDUCE THE RISK OF ELECTRIC SHOCK:

• Do not put the spotlight in water or other liquid. Do not place or store this light where it can fall or be pulled into water or become wet.
• Charge indoors only. Do not expose charging cable to water or any other liquid.
• Do not clean this appliance with a water spray or the like.
• Use only the charging cable supplied by the manufacturer to charge and recharge. Plug in the charging cable at the light first, then plug into the charging source.

FIRE HAZARD:

• Never contact combustible material to the lens.
• Keep spotlight lamp away from materials that may burn.

TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE:

• All lights give off heat:
  • Do not touch the lens while operating.
  • Keep combustibles away from spotlight lens. Extreme heat can cause fires.
  • Never place the light face down on any surface when lit, charging or not in use. Never store the light face down on any surface.
• Never look directly into the light or shine the light into another person's eyes.
• Keep sharp objects away from lens — it is glass and can break.
• Do not immerse spotlight in water.
• Do not expose this unit to extremely high temperatures.
• Do not drop or throw spotlight. It contains glass and a lithium-ion battery.
• After charging/recharging, disconnect the charging cable and wait 5 minutes before use.
• Do not crush, cut, pull or expose charging cable to extreme heat.
• Position charging cable so it does not become entangled or become a safety hazard. Keep charging cable away from sharp edges.
• Use in a dry location only.
• There are no user-serviceable parts inside. Do not attempt to disassemble any other parts of the unit.
• Do not attempt to charge the unit if the USB charging cable is damaged.

To register your product with the manufacturer, please visit www.BaccusGlobal.com.

Imported by Baccus Global LLC, 225 NE Mizner Blvd., Suite 301, Boca Raton, FL 33432
www.Baccusglobal.com 1-877-571-2391
