Stanley SL5HS Instruction Manual

2M LITHIUM-ION LED SPOTLIGHT
INSTRUCTION MANUAL
SAVE THIS INSTRUCTION MANUAL FOR FUTURE
REFERENCE.
BC
Copyright © 2024
Baccus Global LLC, Boca Raton, FL 33432
(877) 571-2391
This device complies with part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Changes or modifications not approved by the party responsible for compliance could void
user's authority to operate the equipment.
SAFETY GUIDELINES /
DEFINITIONS
DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death
or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury.
CAUTION: Used without the safety alert symbol indicates potentially hazardous situation which, if
not avoided, may result in property damage.
RISK OF UNSAFE OPERATION. When using tools or equipment, basic safety precautions should
always be followed to reduce the risk of personal injury. Improper operation, maintenance or
modification of tools or equipment could result in serious injury and property damage. There
are certain applications for which tools and equipment are designed. Manufacturer strongly
recommends that this product NOT be modified and/or used for any application other than for
which it was designed. Read and understand all warnings and operating instructions before using
any tool or equipment.
READ ALL INSTRUCTIONS
WARNING: Read all instructions before operating the spotlight. Failure to follow all instructions
listed below may result in electric shock, fire and/or serious injury.
IMPORTANT SAFETY
INSTRUCTIONS
GENERAL SAFETY WARNINGS AND INSTRUCTIONS
WARNING: RISK OF FIRE, ELECTRIC SHOCK, BURST HAZARD, OR INJURY TO PERSONS:
• LED gets HOT quickly!
• Do not touch the LED at any time when operating.
• Only contact trigger when turning on.
• Do not touch hot lens or enclosure.
• Do not remain in light if skin feels warm.
• Do not operate the spotlight with a missing or damaged lens or enclosure.
• Do not operate if the spotlight is damaged in any way.
WARNING: WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAUTIONS SHOULD ALWAYS
BE FOLLOWED, INCLUDING THE FOLLOWING:
• The spotlight and the supplied charging cable are not toys and cannot be played with as toys. To
reduce the risk of injury, close supervision is necessary when these units are used near children.
• Use only attachments recommended or sold by the manufacturer.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK:
• Do not put the spotlight in water or other liquid. Do not place or store this light where it can fall
or be pulled into water or become wet.
• Charge indoors only. Do not expose charging cable to water or any other liquid.
• Do not clean this appliance with a water spray or any similar liquid.
• Use only the charging cable supplied by the manufacturer to charge and recharge.
WARNING: FIRE HAZARD:
• Never contact combustible material to the lens.
• Keep spotlight lamp away from materials that may burn.
CAUTION: TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE:
• All lights give off heat:
– Do not touch lens while operating.
– Keep combustibles away from spotlight lens. Extreme heat can cause fires.
– Never place the light face down on any surface when lit, charging or not in use. Never store
the light face down on any surface.
• Never look directly into the light or shine the light into another person's eyes.
• Keep sharp objects away from lens — it can crack or break.
• Do not immerse spotlight in water.
• Do not expose this unit to extremely high temperatures.
• Do not drop or throw spotlight. It contains glass and a lithium-ion battery.
• Use only with USB charging cable that is provided with unit. Plug in the charging cable at the
light first, then plug into the charging source.
• After charging/recharging, disconnect charging cable and wait 5 minutes before use.
• Do not crush, cut, pull or expose charging cable to extreme heat.
• Position charging cable so it does not become entangled or become a safety hazard.
• Keep charging cable away from sharp edges.
• Use in a dry location only.
• There are no user-serviceable parts inside. Do not attempt to disassemble any other parts of
the unit.
• To reduce risk of damage to electric plug and cord, pull by plug rather than cord when
disconnecting.
• Do not attempt to charge the unit if the charging cable is damaged.
SPECIFIC SAFETY INSTRUCTIONS FOR LITHIUM-ION
BATTERIES
WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, BURST HAZARD, OR INJURY TO
PERSONS OR PROPERTY:
Lithium-ion batteries are small, compact and ideal for providing long-lasting power to this unit.
However, they must be used and charged properly. Improper use can result in serious injury, fire,
or death.
• Lithium-ion batteries can explode in the presence of a source of ignition. Do not use the product
in the presence of an open flame.
• Do not place this lithium-ion battery powered unit in fire or apply heat to it.
• Do not subject this lithium-ion battery powered unit to strong impacts or shocks. The battery
in this unit contains safety and protection devices which, if damaged, may cause the battery to
generate heat, rupture or ignite.
• Do not expose this lithium-ion battery powered unit to water or salt water, or allow the battery
to get wet.
• Avoid storing this lithium-ion battery powered unit in the basement, bathroom or other areas of
the house that are or may become wet or humid or where moisture may concentrate.
• Do not leave this lithium-ion battery powered unit in direct sunlight, or use or store the unit
inside cars in hot weather. Doing so may cause the battery to generate heat, rupture, or ignite.
Using the battery in this manner may also result in a loss of performance and a shortened life
expectancy.
• Never charge this unit near heat or flammable objects.
• NEVER THROW WATER ON A BURNING LI-ION BATTERY! If a lithium-ion battery does catch on
fire, it will burn even more violently if it comes in contact with water or even moisture in the
air. A fire extinguisher must be used.
Battery Charging and Capacity
This unit is delivered in a partially charged state – you must fully charge it before using it for the
first time.
SL5HS
When stored at room temperature with a full charge, Li-ion batteries will begin to discharge from
the time they are manufactured, even when unused. Deep discharges also decrease their capacity.
Battery life can be extended by the following:
• Charge battery to full capacity before storage.
• Optimal storage temperature for this unit is between 5°C and 20°C (41°F and 68°F).
• Never discharge the battery fully.
• Charge after each use.
• Always charge at least once every 3-6 months if not in frequent use to prevent overdischarge.
Transportation of Lithium-Ion Batteries
• Always check all applicable local, national, and international regulations before transporting a
unit containing a Lithium-Ion battery.
• Transporting an end-of-life, damaged, or recalled battery may, in certain cases, be specifically
limited or prohibited.
SAVE THESE INSTRUCTIONS
INTRODUCTION
Congratulations on purchasing your new Stanley 2M Lithium-Ion LED Spotlight. Read this
®
Instruction Manual and follow the instructions carefully before using your new spotlight.
FEATURES
1
2
3
4 6
5
8
9
10
1. Swing-up Stand
2. 5-Position On/Off Trigger (Full/High/Low/Halo/Off)
3. Pistol Grip Handle
4. Area Lights (total of 8 around the Lens)
5. Main Beam LED
6 Battery/Charge Status LED Indicator
7. Micro-USB Charging Port
8. USB Charging Cable
9. Regular USB Plug
10. Micro-USB Plug
READING THE BATTERY/CHARGE STATUS LED
INDICATOR
The battery and charging status LED indicator is located on the back of the unit. It lights or flashes
in three colors to indicate the following:
When charging:
Green: Battery is in a fully charged state.
Green (flashing): Battery is in a high partially charged state.
Orange (flashing): Battery is in a low partially charged state.
Red (flashing): Battery needs to be recharged.
Red (flashing rapidly): The battery of the unit is overheated due to extensive use or recharging.
The charging process will stop at this stage and will automatically resume after a cool down period.
When operating:
Green: Battery is operating at full voltage.
Orange: Battery is operating at partial voltage.
Red: Battery is operating at low voltage, and should be recharged or the built-in low voltage
protection will be activated and the unit will automatically shut down shortly.
Red (flashing rapidly): The battery of the unit is overheated (due to extensive use or recharging),
or is too cold (the ambient temperature has dropped below -20°C). Operation will stop at this stage.
CHARGING/RECHARGING THE SPOTLIGHT
This unit is shipped in a partially charged state. Charge unit after purchase and BEFORE first use
until the battery/charge status LED indicator lights green.
Recharge after each use until the battery/charge status LED indicator lights green.
IMPORTANT: When the unit is not in use, we recommend that the battery is charged at least
every 3 to 6 months.
WARNING: Only charge product using a Listed Class 2 USB power adapter that is compliant
with applicable country regulations and international/regional safety standards. Using adapters
that do not meet applicable safety standards could result in injury.
CAUTION: TO REDUCE THE RISK OF INJURY OR PROPERTY DAMAGE:
• Never place the light face down on any surface when charging.
• Failure to keep the battery charged will cause permanent damage and result in poor
performance.
Charging/recharging using the USB charging cable and a device
with a USB power port (not supplied)
1. Make sure the spotlight is off.
2. Insert the micro-USB plug of the USB charging cable into the micro USB charging port on the
back of spotlight.
3. Insert the regular USB plug of the USB charging cable into a device's functional USB power
port. The battery/charge status LED indicator will light or flash in one of three colours (as
described in the "Reading the Battery/Charge Status LED Indicator" section) to indicate the
charging status.
4. Charge until the battery/charge status LED indicator lights green.
5. When charging is complete, disconnect the USB charging cable from the device's USB power
port and the spotlight. Store the cable in a safe place.
OPERATING THE SPOTLIGHT
The 5-Position On/Off Trigger turns the unit on and off, and is also used to choose the following
modes:
FULL - all LEDs;
HIGH - Main Beam LED in its high (brightest) setting;
LOW – Main Beam LED in its low (dimmest) setting; or
HALO – 8 Area LED lights.
CAUTION: DO NOT OPERATE WHILE CHARGING .
Disconnect the charging cable, then select the light mode as follows:
To turn the spotlight on and use the Main Beam LED Press the trigger once.
and 8 area lights at once
To use the Main Beam LED alone in its brightest Press the trigger a second time within 5 seconds.
setting
To use the Main Beam LED alone in its dimmer Press the trigger a third time within 5 seconds.
setting
To switch the spotlight to HALO mode, using just the Press the trigger a fourth time within 5 seconds.
8 area LED lights
To turn the spotlight off Either press the trigger a fifth time within 5
seconds, or press the trigger once after 5 seconds
in any mode.
Note:
The battery/charge status LED indicator will light in one of three colors (as described in the "Reading
the Battery/Charge Status LED" section) to indicate the battery status. If the light's battery voltage is nearly
low, the unit will switch automatically to Halo mode even if another Light Mode has been selected.
Using the Swing-up Stand
Lift the Swing-up Stand up, invert the unit and set it upon a flat, stable surface for hands-free operation.
CARE AND MAINTENANCE
All batteries lose energy from self-discharge over time and more rapidly at higher temperatures.
When the unit is not in use, we recommend that the battery is charged at least every 3 to 6
months.
From time to time wipe the outside of the appliance with a soft cloth. Do not immerse the
appliance in water.
There are no user-replaceable parts. Periodically inspect the condition of connectors and wires.
Battery replacement/disposal
BATTERY REPLACEMENT
The battery should last the service life of the unit. Service life is dependent on a number of factors
including but not limited to the number of recharge cycles, and proper care and maintenance of
the battery by the end user. Contact manufacturer for any information you may need.
SAFE BATTERY DISPOSAL
Contains a lithium-ion battery, which must be disposed of
properly. Recycling is required. Failure to comply with local,
state and federal regulations can result in fines, or imprisonment.
Please recycle.
WARNINGS:
• Do not dispose of the battery in fire as this may result in an explosion.
• Before disposing of the battery, protect exposed terminals with heavy-duty electrical tape to
prevent shorting (shorting can result in injury or fire).
• Do not expose battery to fire or intense heat as it may explode.
TROUBLESHOOTING
The spotlight will not charge
• Check that the spotlight is turned off.
• Check that the USB charging cable is properly connected to the charging source and to the
spotlight.
• The unit may have shut down to protect the battery from overheating after a long period of
operation or charging. Disconnect the USB charging cable from the spotlight. Allow the spotlight
to cool down for a period before resuming charging.
The spotlight will not operate
• Make sure the On/Off Trigger has been pressed to turn the spotlight on.
• The internal battery may be completely discharged. Charge the unit following the directions given
in this manual.
• The unit may have shut down to protect the battery from overheating after a long period of
operation or charging; or the ambient temperature has dropped below –20°C. Allow the spotlight
to cool down or warm up for a period before resuming operation.
• If the ambient temperature is too hot or too cold the spotlight will not operate.
If the unit does not charge or operate after taking the steps given above, contact the
manufacturer at (877) 571-2391.
ACCESSORIES
Recommended accessories for use with your tool may be available from the manufacturer. If you
need assistance regarding accessories, please contact the manufacturer at (877) 571-2391.
WARNING: The use of any accessory not recommended for use with this appliance could be
hazardous.
TECHNICAL ASSISTANCE
For Customer Service or Technical Assistance, contact the manufacturer at 1-877-571-2391.
ONE-YEAR LIMITED MANUFACTURER'S WARRANTY
The manufacturer, Baccus Global LLC, warrants this product against defects in materials and
workmanship for a period of ONE (1) YEAR commencing from the date of retail purchase by
the original end-user purchaser or from the date of delivery of the good, whichever occurs later
("Warranty Period").
7
If there is a defect and a valid claim is received by the manufacturer within the Warranty Period,
the defective product can be replaced in the following ways: (1) Return the product to the
manufacturer for replacement. Proof of purchase may be required by manufacturer. (2) Return the
product to the retailer where product was purchased for an exchange (provided that the store is
a participating retailer). Returns to retailer should be made within the time period of the retailer's
return policy for exchanges only. Proof of purchase may be required. Please check with the retailer
for their specific return policy regarding returns that are beyond the time set for exchanges.
This manufacturer's warranty does not apply to accessories, bulbs, fuses and batteries; defects
resulting from normal wear and tear, accidents; damages sustained during shipping; alterations;
unauthorized use; neglect, misuse, abuse; and failure to follow instructions for care and
maintenance for the product.
This manufacturer's warranty gives you, the original retail purchaser, specific legal rights and you
may have other rights which vary from state to state or province to province. This product is not
intended for commercial use. To register your product with the manufacturer, please visit www.
BaccusGlobal.com.
The photos in this manual may differ from the actual unit.
SPECIFICATIONS
Light
Bulb:
Battery:
Input:
To purchase optional accessories, contact the manufacturer at (877) 571-2391.
STANLEY ® AND THE STANLEY ® LOGO ARE
REGISTERED TRADEMARKS OF STANLEY BLACK +
DECKER INC. OR ONE OF ITS AFFILIATES, AND ARE
USED UNDER LICENSE.
Main LED bulb and 8 white LEDs
Lithium-Ion, 3.7 V DC
5V DC, 1A
Imported by Baccus Global LLC,
225 NE Mizner Blvd., Suite 301, Boca Raton, FL 33432
www.baccusglobal.com 1-877-571-2391
RD082124
