Summary of Contents for Colnago V4Rs

  • Page 1 V4Rs Assembly guide...
  • Page 2: Table Of Contents

    Table of contents Assembly guide Integrated handlebar cable routing Frame cable routing & brake installation Bottom bracket installation Torque settings tab...
  • Page 3: Assembly Guide

    1. Colnago strongly recommends that the bike should be assembled by a professional bike mechanic. RIGHT 2. Colnago Ernesto & C. s.r.l. avoids any liability over damage or harm to things and people caused by an incorrect application of the instructions shown in this manual.
  • Page 4: Integrated Handlebar Cable Routing

    Integrated handlebar cable routing Integrated handlebar cable routing The Grey connector must exit form the central hole, Cables are interely routed through the handlebar. Purple and orange passing through the stem. connectors exit from the right side, the grey one from the center, the blue one from the left.
  • Page 5 Integrated handlebar cable routing Integrated handlebar cable routing Route the cable through the handlebar with the help of a guiding The cockpit is ready. The EPS groupset cables and the hydraulic object (usually this is a mechanical shifter cable). hoses pass inside the stem. Place the spacers under the handlebar if needed and cover the rear brake line with the noise- cancelling rubber.
  • Page 6: Frame Cable Routing & Brake Installation

    Frame cable routing & brake installation Frame cable routing & brake installation Prepare the power unit. Gather the cables outside the right side of the bottom bracket shell. Insert the Power unit’s cables through the seat tube Route the EPS groupset cables for every single position, (top to bottom).
  • Page 7 Frame cable routing & brake installation Frame cable routing & brake installation Route the EPS groupset cables for every single position, Connect the Hydraulic brake hose with the rear brake caliper. following the specific instructions. Connect the Hydraulic brake hose with the rear brake caliper. Make sure that the EPS cables are in between the two hydraulic hoses.
  • Page 8 Frame cable routing & brake installation Frame cable routing & brake installation The front brake hose passes throught the head tube. Connect the cable into the EPS interface unit following the specific instructions. Insert the front brake hose inside the fork Connect the EPS cable with the rear derailleur.
  • Page 9 Frame cable routing & brake installation Frame cable routing & brake installation Connect the EPS cable with the front derailleur. Bolt the front brake caliper to the fork leg. Bolt the rear brake caliper on the chain stay. Connect both the brake hoses to the relative brake calipers.
  • Page 10: Bottom Bracket Installation

    Lock in the cups with the specific T47 bottom bracket tool. put some grease over the thread. Torque setting is shown in the table below. Thread the cups in, together with the plastic cable-guiding cylinder. The V4Rs frame is ready to be fitted with the rest of the components.
  • Page 11: Torque Settings Tab

    5 Nm 4 mm Allen key THE USE OF THE TORQUE WRENCH (fork) Colnago is concerned about the resistance and quality of their frames. In order to guarantee the perfect conservation and durability Standard stem bolts 5 Nm 4 mm Allen key...
  • Page 12 Torque settings tab DESCRIPTION MAXIMUM TORQUE TOOL (approx.) Bottle Cage bolts 2,5 Nm 4 mm Allen key Wheel thru-axle 4-5 Nm 5 mm Allen key Brake Calipers bolts 6-8 Nm 4 mm Allen key (on frame) Pedals 35 Nm 6/8 mm Allen key Rear Derailleur on Hanger 10-12 Nm 5 mm Allen key...
  • Page 13 info@colnago.com...
