Delta Electronics SIG3015 Specification Sheet

SMT Power Inductor
SIG3015 Type
Features
RoHS compliant.
Halogen free compliant.
Low profile (1.5mm max. height ), SMD type.
Shielded
Self-leads, suitable for high density mounting.
High energy storage and low DCR.
Provided with embossed carrier tape packing.
Ideal for power source circuits, DC-DC converter, DC-AC inverters
inductor applications.
In addition to the standard versions shown here,
customized inductors are available to meet your exact requirements.

Mechanical Dimension:

A
B

Electrical Characteristics:

1
L
PART NO.
(uH)
SIG3015 - 1R0 1.0
SIG3015 - 1R5 1.5
SIG3015 - 2R2 2.2
SIG3015 - 3R3 3.3
SIG3015 - 4R7 4.7
SIG3015 - 6R8 6.8
SIG3015 - 100 10.0
SIG3015 - 150 15.0
SIG3015 - 220 22.0
SIG3015 - 330 33.0
SIG3015 - 470 47.0
1. Tolerance of inductance:
2. Isat is the DC current which cause the inductance drop 30% typical of its nominal inductance without current.
3. Ir is the DC current which cause the surface temperature of the part increase less than 40
4. Operating temperature: -25 C to 120 C (including self-temperature rise).
DELTA ELECTRONICS, INC.
(TAOYUAN PLANT CPBG)
C
E
o
25 : 100KHz, 0.1V C
2
3
Ir
DCR Isat
(Adc)
(Adc)
(m ) Max.
32 2.10 2.10
48 1.80 1.82
72 1.48 1.50
96 1.21 1.23
144 1.02 1.04
192 0.87 0.88
276 0.70 0.71
432 0.56 0.56
624 0.47 0.47
1008 0.39 0.37
1609 0.32 0.30
30% for 1.0~1.5uH, 20% for 2.2~47uH.
o o
252, SAN YING ROAD, KUEISAN INDUSTRIAL ZONE, TAOYUAN SHIEN, 333, TAIWAN, R.O.C.
TEL: 886-3-3591968; FAX: 886-3-3591991
http://www.deltaww.com
RECOMMENDED PAD PA TTERNS
D
2.7
0.8
D
2.2
SELF-RESONANT
FREQUENCY
(MHz)Min.
100
87
64
49
40
36
28
23
20
18
17
23
UNIT : mm/inch
A = 3.00 0.1 / 0.118 0.004
B = 3.00 0.1 / 0.118 0.004
C = 1.50 / 0.059 MAX.
D = 0.90 0.2 / 0.035 0.008
E = 1.90 0.2 / 0.075 0.008
o
C.
