Area Light
Installation Instructions
AL-Series
WHAT COMES IN THE BOX
3 pin shorting cap
Pluggable sensor socket
3 1/2 ft cable, Type 3 lens
Installation Instructions
SAFETY INSTRUCTIONS AND WARNINGS
WHEN USING ELECTRICAL EQUIPMENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE OBSERVED.
READ CAREFULLY BEFORE INSTALLING FIXTURE. RETAIN THESE INSTRUCTIONS FOR FUTURE REFERENCE.
Litetronics fixtures must be wired in accordance with the National Electrical Code and all applicable local codes.
Risk of fire or electric shock. Area light installation requires knowledge of luminaires electrical systems. If not qualified,
do not attempt installation. Contact a qualified electrician.
Be certain electrical power is OFF before and during installation and maintenance.
Area light must be connected to a wiring system with an equipment – grounding conductor.
Make sure the supply voltage is the same as the rated luminaire voltage.
Only the open holes indicated in the photographs and/or drawings may be made or altered as a result of this kit
installation. Do not leave any other open holes in an enclosure of wiring or electrical components.
To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or sharp objects.
Suitable for wet locations.
ATTENTION
1.
Please check if there is any damage during shipping. If so, please contact Litetronics customer service.
2.
Please read the installation instruction carefully to check whether all the accessories are included.
3.
After confirmation, install the fixture according to installation steps.
TOOLS NEEDED
Phillips Screwdriver
Allen Wrench
