Philips Optivision MVP507 Series Mounting Instruction

Optivision
MVP507 Range
Mounting instruction
ta
IP65 IP44
35°
光源腔
Product Name
产品名称
MVP507
1
The burning position of horizontal for MHN-LA1000W/2000W should be allowed ±5°
光源MHN-LA1000W/2000W在水平位置的点燃允许角度±5°
Allowed installing position for outdoor
户外允许安装位置
5°
0°
5°
2
2
1
Philips Lighting Luminaires (Shanghai) Co., Ltd.
Address: No. 2688, Huyi Road, Jiading, Shanghai, China
Postalcode: 201801
飞利浦灯具（上海）有限公司
地址：中国上海市嘉定区马陆镇沪宜公路2688号
邮编：201801
安装说明
Optic Gear
电器腔
Lamp
光源
SON-T600W
SON-T1000W
MHN-LA1000W
MHN-LA2000W
640
576
59
5°
0°
5°
Reflect
V/Hz
反射器 电压/频率
WB 220V/50Hz
WB 220V/50Hz
WB 220V/50Hz
WB/MB/NB 380V/50Hz
3×Ø22
75
150
Aiming object through adial
0
通过刻度盘瞄准目标
M10(2×)
50N.m
>20m
0.12m 2
m
1
1
3.5
3.5
652
50
S=16
3
Open the glass slowly when maintenance
维护时慢慢打开玻璃
4441 000 63792
17.2
17.2
17.2
17.2
