OPERATOR'S MANUAL
MANUEL D'UTILISATION
MANUAL DEL OPERADOR
20 in. 40 VOLT LAWN MOWER
20 po, TONDEUSE 40 V
20 pulg., PODADORA 40 V
RY401011/RY401011VNM
 Important Safety Instructions ......... 2-4
 Symbols ......................................... 5-6
 Features .............................................7
 Assembly ....................................... 8-9
 Operation ..................................... 9-11
 Maintenance .............................. 12-13
 Troubleshooting ...............................14
 Parts Ordering and
Service ............................... Back Page
WARNING:
To reduce the
risk of injury, the user must read and
understand the operator's manual
before using this product.
SAVE THIS MANUAL FOR
FUTURE REFERENCE
 Instructions importantes
concernant la securite ..................... 2-4
 Symboles ....................................... 5-6
 Caractéristiques .................................7
 Assemblage ................................... 8-9
 Utilisation ..................................... 9-11
 Entretien ..................................... 12-13
 Dépannage .......................................14
 Commande de pièces
et réparation ..................... Page arrière
AVERTISSEMENT :
réduire les risques de blessures,
l'utilisateur doit lire et veiller à bien
comprendre le manuel d'utilisation
avant d'employer ce produit.
CONSERVER CE MANUEL
POUR FUTURE RÉFÉRENCE
 Instrucciones de seguidad
importantes .................................... 2-4
 Símbolos ........................................ 5-6
 Características ...................................7
 Armado .......................................... 8-9
 Funcionamiento ........................... 9-11
 Mantenimiento ........................... 12-13
 Corrección de problemas ................14
 Pedidos de piezas
y servicio ....................... Pág. posterior
Pour
ADVERTENCIA:
el riesgo de lesiones, el usuario debe
leer y comprender el manual del
operador antes de usar este producto.
GUARDE ESTE MANUAL
PARA FUTURAS CONSULTAS
Para reducir

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RY401011VNM and is the answer not in the manual?

Questions and answers

Related Manuals for Ryobi RY401011VNM

Summary of Contents for Ryobi RY401011VNM

  • Page 1 MANUEL D’UTILISATION MANUAL DEL OPERADOR 20 in. 40 VOLT LAWN MOWER 20 po, TONDEUSE 40 V 20 pulg., PODADORA 40 V RY401011/RY401011VNM  Important Safety Instructions ..2-4  Instructions importantes  Instrucciones de seguidad concernant la securite ..... 2-4 importantes ........
  • Page 2 See this fold-out section for all of the figures referenced in the operator’s manual. Consulter l’encart à volets afin d’examiner toutes les figures mentionnées dans le manuel d’utilisation. Consulte esta sección desplegable para ver todas las figuras a las que se hace referencia en el manual del operador. Fig.
  • Page 3 Fig. 2 Fig. 4 A - Handle adjustment knob (bouton de réglage de la poignée, perilla de ajuste del mango) B - Lower handle (poignée inférieure, mango inferior) C - To unlock (pour déverrouiller, para desbloquear) A - Frame (support, armazón) D - To lock (pour verrouiller, para asegurar) B - Bag (sac, bolsa) C - Handle (poignée, mango)
  • Page 4 Fig. 6 Fig. 9 Fig. 11 A - Height adjustment lever (levier de réglage de la hauteur, palanca de ajuste de altura) B - Lowest blade setting (le plus bas réglage de A - Grass catcher handle (poignée de collecteur la lame, ajuste más bajo de la hoja) d’herbe, mango del receptor de hierba) C - Highest blade setting (le plus haut réglage...
  • Page 5 Fig. 13 Fig. 16 Fig. 17 TO STORE THE MACHINE IN THE HORIZONTAL POSITION POUR REMISER L’ÉQUIPEMENT EN POSITION HORIZONTALE PARA GUARDAR LA MÁQUINA EN POSICIÓN HORIZONTAL 15° MAXIMUM 15° MAXIMUM 15° MAXIMAL 15° MÁXIMA 15° MAXIMAL 15° MÁXIMA Fig. 14 Fig.

  • Page 6: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS  Stay alert – Watch what you are doing and use common sense when operating the lawn mower. Do not operate WARNING: the mower while tired, upset, or under the influence of READ AND UNDERSTAND ALL INSTRUCTIONS. drugs, alcohol, or medication.
  • Page 7 IMPORTANT SAFETY INSTRUCTIONS  Clear the work area before each use. Remove all objects  Do not pull the mower backward unless absolutely nec- such as rocks, tree nuts, sticks, metal, wire, bones, toys, essary. If you must back the mower away from a wall or or other objects which can be thrown by the blade.Stay obstruction, first look down and behind to avoid tripping behind the handle when the motor is running.
  • Page 8 IMPORTANT SAFETY INSTRUCTIONS  Battery tools do not have to be plugged into an electrical reach of children. The start key and battery packs should outlet; therefore, they are always in operating condition. also be removed and stored in a separate location out of Be aware of possible hazards when not using your bat- the reach of children.
  • Page 9 SYMBOLS The following signal words and meanings are intended to explain the levels of risk associated with this product. SYMBOL SIGNAL MEANING Indicates a hazardous situation, which, if not avoided, will result in death or DANGER: serious injury. Indicates a hazardous situation, which, if not avoided, could result in death or WARNING: serious injury.
  • Page 10 SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION This product uses lithium-ion (Li-ion) batteries. Local, state, or federal laws may prohibit disposal of batteries in ordinary trash.
  • Page 11 FEATURES PRODUCT SPECIFICATIONS Motor ..................................40 Volt DC Deck Size ..................................20 in. Height Adjustments ............................1-1/2 in. to 4 in. Wheel Size ..............................8 in. front, 10 in. rear KNOW YOUR LAWN MOWER MULCHING PLUG See Figure 1. When installed, the mulching plug covers the rear discharge The safe use of this product requires an understanding of opening and allows the mower blade to cut and recut for the information on the product and in this operator’s manual...

  • Page 12: Packing List

    ASSEMBLY UNPACKING WARNING: This product requires assembly. To prevent accidental starting, do not make any adjust-  Carefully remove the product and any accessories from ments or installations with the start key or battery pack the box. Make sure that all items listed in the packing list inserted.

  • Page 13: Operation

    ASSEMBLY INSTALLING THE GRASS CATCHER (FOR  Gently push down on the mulching plug to ensure the metal lock is fully seated in the slot. The mower will not REAR BAGGING OPERATION) start if the metal lock is not fully seated. See Figures 6 - 7.
  • Page 14 For complete charging instructions, refer to the Operator’s Manuals for your RYOBI battery pack and charger models.  When cutting heavy grass, reduce walking speed to allow for more effective cutting and a proper discharge of the clippings.

  • Page 15: Emptying The Grass Catcher

    OPERATION  Clean the underside of the mower deck after each use  Always be sure of your footing. A slip and fall can cause to remove grass clippings, leaves, dirt, and any other serious personal injury. If you feel you are losing your bal- accumulated debris.
