SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts
SITRANS L
Controllers
SITRANS LT500 with ultrasonic
transducer inputs - Parameter
configuration charts
Commissioning Manual
7ML60..
10/2023
AG101623
Introduction
Description
Planning/configuring
1
2
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SITRANS LT500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Siemens SITRANS LT500

Summary of Contents for Siemens SITRANS LT500

  • Page 1 SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Introduction Description SITRANS L Planning/configuring Controllers SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual 7ML60.. 10/2023 AG101623...

  • Page 2: Legal Information

    Note the following: WARNING Siemens products may only be used for the applications described in the catalog and in the relevant technical documentation. If products and components from other manufacturers are used, these must be recommended or approved by Siemens. Proper transport, storage, installation, assembly, commissioning, operation and maintenance are required to ensure that the products operate safely and without any problems.

  • Page 3: Table Of Contents

    Volume application ......................8 Volume flow application ....................11 Pump control application ....................17 Basic control application ....................20 Alarms application ......................21 Custom application ......................30 SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...

  • Page 4: Introduction

    • Pump control • Basic control • Alarms Equipment: • Siemens SITRANS LT500 device (for configuration once parameter values have been recorded) • Remote sensor(s) Note While every effort is made to verify the following information, no warranty of accuracy or usability is expressed or implied.

  • Page 5: Description

    Description Overview SITRANS LT500 has one Quick commissioning wizard (used for various application types), and wizards for Pump control, Basic control and Alarms. All wizards are located under the Quick start menu on the device. These wizards guide you through the configuration of parameters essential for the proper settings to support the application.

  • Page 6: Planning/Configuring

    Step: Select application: Level (used for Level or Space or Distance) Wizard step Parameter Options (default noted by asterisk) Step: Length units Length units • • • • • SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 7 Response rate • Slow (0.1 m/min fill/empty rate) • Medium (1.0 m/min fill/empty rate)* • Fast (10.0 m/min fill/empty rate) Material type • Liquid* • Solid Notes: SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...

  • Page 8: Volume Application

    • gal (UK) (imperial gallons) • bu (bushels) • bbl (US) (31.5 gallon • Custom (set outside of barrels) wizard) • bbl-beer (31 US gallon barrels) SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 9 Response rate • Slow (0.1 m/min fill/empty rate) • Medium (1.0 m/min fill/empty rate)* • Fast (10.0 m/min fill/empty rate) Material type • Liquid* • Solid SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 10 Set data points outside of wizard if applicable to application. Record values in separate "Custom ap- plication" chart. Vessel dimension A Vessel dimension L Maximum volume Notes: SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...

  • Page 11: Volume Flow Application

    Wizard - Quick commissioning Step: Select application: Volume flow Wizard step Parameter Options (default noted by asterisk) Step: Units Length units • • • • • SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 12 • gal (UK)/h (imperial • in³/d (cubic inches per gallons per hour) day) • gal (UK)/d (imperial • yd³/s (cubic yards per gallons per day) second) SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 13 (UK) (imperial • ft3 (cubic feet) gallons) • yd3 (cubic yards) • bbl (US) (31.5 gallon barrels) • bu (bushels) • Custom (set outside of wizard) SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 14 Response rate • Slow (0.1 m/min fill/empty rate) • Medium (1.0 m/min fill/empty rate)* • Fast (10.0 m/min fill/empty rate) Material type • Liquid* • Solid SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 15 Throat width • Hump height • Throat length • Slope U-flume • Approach diame- BS 3680/ISO 4373 • Throat diameter • Hump height • Throat length SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 16 32 tion" chart. • Y-value 1 to Y- value 32 Step: Flow settings Maximum head (common) Zero head offset Maximum flow Low flow cut-off Notes: SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...

  • Page 17: Pump Control Application

    Pump 2 • Relay output 1 • Relay output 2 • Relay output 3 • Relay output 4 • Relay output 5 • Relay output 6 SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 18 Step: Pump run times Run time pump 1 Run time pump 2 Run time pump 3 Run time pump 4 Run time pump 5 Run time pump 6 SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 19 Off setpoint pump 3 On setpoint pump 4 Off setpoint pump 4 On setpoint pump 5 Off setpoint pump 5 On setpoint pump 6 Off setpoint pump 6 Notes: SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...

  • Page 20: Basic Control Application

    Off setpoint relay 3 On setpoint relay 4 Off setpoint relay 4 On setpoint relay 5 Off setpoint relay 5 On setpoint relay 6 Off setpoint relay 6 Notes: SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...

  • Page 21: Alarms Application

    External TS-3 Step: Alarm Alarm • Level sources sources • Space • Distance • Head • Volume • Volume flow • Sensor temperature • Sensor diagnostics SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 22 [ ] 378 Auxiliary temperature below warning [ ] 378 Auxiliary temperature below warning limit limit [ ] 379 Auxiliary temperature below alarm [ ] 379 Auxiliary temperature below alarm limit limit SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 23 [ ] Relay output 2 [ ] Relay output 3 [ ] Relay output 4 [ ] Relay output 5 [ ] Relay output 6 SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 24 [ ] 379 Auxiliary temperature below alarm [ ] 379 Auxiliary temperature below alarm limit limit [ ] Sensor diagnostics [ ] Sensor diagnostics SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 25 [ ] 379 Auxiliary temperature below alarm [ ] 379 Auxiliary temperature below alarm limit limit [ ] Sensor diagnostics [ ] Sensor diagnostics SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 26 [ ] 379 Auxiliary temperature below alarm [ ] 379 Auxiliary temperature below alarm limit limit [ ] Sensor diagnostics [ ] Sensor diagnostics SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 27 [ ] 379 Auxiliary temperature below alarm [ ] 379 Auxiliary temperature below alarm limit limit [ ] Sensor diagnostics [ ] Sensor diagnostics SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 28 [ ] 379 Auxiliary temperature below alarm [ ] 379 Auxiliary temperature below alarm limit limit [ ] Sensor diagnostics [ ] Sensor diagnostics SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
  • Page 29 [ ] 379 Auxiliary temperature below alarm [ ] 379 Auxiliary temperature below alarm limit limit [ ] Sensor diagnostics [ ] Sensor diagnostics Notes: SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...

  • Page 30: Custom Application

    Y-value 26 X-value 27 Y-value 27 X-value 28 Y-value 28 X-value 29 Y-value 29 X-value 30 Y-value 30 X-value 31 Y-value 31 X-value 32 Y-value 32 SITRANS LT500 with ultrasonic transducer inputs - Parameter configuration charts Commissioning Manual, 10/2023, AG101623...
