CABAC HNS416TM Owner's Manual

HNS416TM
OWNER'S MANUAL
1. FEATURES
• Suits Clipsal Saturn and Saturn Zen
TM
• Includes both Timer and No-Timer functions.
• Blue LED indicates device status.
• User programmable time-out period.
• Programmable in 1 minute increments from 1 to 60 minutes.
• When ON - Quick Tap turns power OFF.
• Time-out expiry warning given within the last
10 seconds of operation.
• Retains settings even after loss of mains power.
• Configurable power up ON or OFF after loss of mains power.
• Time out set to 30 minutes out of box.
2. OPERATING CONDITIONS
• Operating Voltage:
• Operating Temperature:
• Certification Standard:
• Maximum Load:
• Minimum Load:
• Maximum Current capacity: 1.7A
• Terminals:
Note: Operation at temperature, voltage or load outside of the specifications may cause permanent damage to the unit.
3. LOAD COMPATIBILITY
Low Voltage Halogen / Dichroic Lighting with Iron-Core Transformers
Low Voltage Halogen / Dichroic Lighting with Electronic Transformers
Fluorescent Tube with Electronic Ballast
Refer to lamp manufacturer's guidelines. Lamps must be compatible with electronic switches
(1)
Note: This manual was correct at the time of manufacture. For the latest version of the manual and any technical or safety
updates refer to the website: cabac.com.au, cabac.co.nz.
Distributed by CABAC
133 122 | CABAC.COM.AU | CABAC.CO.NZ
HNS416TM Minute Timer Switch S-Premium 2-Wire
style wall plates.
TM
230V AC 50Hz
0 to +50 °C
AS 60669.2.1, CISPR 15
400VA
10VA
Screw Terminals suit 0.5mm
LOAD TYPE
(1)
LED Lamps
Incandescent / 240V Halogen / Dichroic Lamps
Dimmable Compact Fluorescent Lamps
Motors / Fans / Contactors / Relays / Transformers
to 1.5mm stranded (bootlace terminal recommended)
2 2
(1
)
(1)
or Iron Core Ballast
(1)
COMPATIBILITY
400VA
400VA
Not Compatible
400VA
400VA
Not Compatible
Not Compatible
CP15337 Rev 4, 22 November 2023
