GSD WKCT2QM2501 Manual

Hui Zhou Gaoshengda Technology Co., LTD
WIFI+BT Module
IEEE 802.11 a/b/g/n/ac 2T/2R
Model Number: WKCT2QM2501
Product Descrition
The WKCT2QM2501 is a complete dual-band(2.4GHz and 5GHz)WIFI 2×2 MIMO module. This module provides a
high level of integration with a dual-stream IEEE 802.11ac MAC/ base band /radio and Bluetooth 5.2.The WLAN
operation supports 20MHz,40MHz and 80MHz channels for data rates up to 866.7Mbps. It fully complies with IEEE
802.11 a/b/g/n/ac feature rich wireless connectivity at high standards,delivers reliable,cost-effective, throughput
from an extended distance.
Product Features
◆ Complies with IEEE 802.11b/g/n for 2.4GHz and IEEE 802.11a/n/ac 5GHz Wireless LAN.
◆ Bluetooth v5.2
◆ Two transmit and Two receive path(2T2R)
◆ Works with all existing network nfrastructure.
◆ Capable of up to 128-Bit WEP Encryption.
◆ Freedom to roam while staying connected.
◆ UP to 866.7 Mbps High-Speed Transfer Rate in 802.11ac mode of operation.
◆ Operating Systems：Linux,Windows
◆ Low power consumption.
◆ Easy to install and configure.
◆ High speed USB 2.0 interface
◆ROHS compliant
Product Specification
Model WKCT2QM2501
Product Name
WIFI+BT Module
Standard 802.11 a/b/g/n/ac
Interface USB
Data Transfer Rate Up to 866.7Mbps
Modulation Method GFSK,π/4-DQPSK,8DPSK(bluetooth)
DQPSK,DBPSK,CCK(802.11b)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11g)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11n)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11a)
QPSK,BPSK,16QAM,64QAM,256QAM with OFDM (802.11ac)
Frequency Band BLUETOOTH
2402~2480 MHz
WIFI
2.4G: 2412~2462 MHz
5G: 5180~5240MHz,5260~5320MHz,5500~5720MHz,5745~5825MHz
Operation Mode Infrastructure
Security WEP, TKIP, AES, WPA, WPA2
Operating Voltage 3.3V±10%
Current Consumption
＜1000mA
Antenna Type PCB
Operating 0 ~ 70°C ambient temperature
Temperature
Storage Temperature -40 ~ 80°C ambient temperature
Humidity 5 to 95 % maximum (non-condensing)
PAGE 1 OF 6
WKCT2QM2501
Version 1.0
