GSD WC5EM2601F Quick Start Manual

Hui Zhou Gaoshengda Technology Co., LTD
WIFI Module
IEEE 802.11 a/b/g/n 2T/2R
Model Number: WC5EM2601F
Product Descrition
The WC5EM2601F is a complete dual-band(2.4GHz and 5GHz)WIFI 2×2 MIMO module. This module provides a
high level of integration with a dual-stream IEEE 802.11n MAC/ base band /radio.The WLAN operation supports
20MHz,40MHz,80MHz channels for data rates up to 300Mbps. It fully complies with IEEE 802.11 a/b/g/n/ac
feature rich wireless connectivity at high standards,delivers reliable,cost-effective, throughput from an extended
distance.

Product Features

◆ Complies with IEEE 802.11b/g/n for 2.4GHz and IEEE 802.11a/n/ac 5GHz Wireless LAN.
◆ Two transmit and Two receive path(2T2R)
◆ Works with all existing network nfrastructure.
◆ Capable of up to 128-Bit WEP Encryption.
◆ Freedom to roam while staying connected.
◆ UP to 866.7 Mbps High-Speed Transfer Rate in 802.11ac mode of operation.
◆ Operating Systems：Linux,Win7, Win8, Win10,XP
◆ Low power consumption.
◆ Easy to install and configure.
◆ High speed USB 2.0 interface
◆ROHS compliant

Product Specification

WIFI Module
Model
Product Name WC5EM2601F
Standard 802.11 a /b/g/n/ac
Interface USB
Data Transfer Rate 1,2,5.5,6,11,12,18,22,24,30,36,48,54,60,90,120 and maximum of 866.7Mbps
Modulation Method DQPSK,DBPSK,CCK(802.11b)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11g)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11n)
QPSK,BPSK,16QAM,64QAM with OFDM (802.11a)
QPSK,BPSK,16QAM,64QAM,256QAM with OFDM (802.11ac)
Frequency Band 2.4G: 2412~2462 MHz
5G: 5150~5350MHz,5470~5725MHz
5725~5850MHz
Operation Mode Infrastructure
Security WEP, TKIP, AES, WPA, WPA2
Operating Voltage 3.3V±10%
＜1000mA
Current Consumption
Antenna Type PIFA
Operating 0 ~ 70°C ambient temperature
Temperature
Storage Temperature -40 ~ 80°C ambient temperature
Humidity 5 to 95 % maximum (non-condensing)
NOTICE:
◆please keep this product and accessories attached to the places which children can't touch;
◆do not splash water or other liquid onto this product, otherwise it may cause damage;
◆do not put this product near the heat source or direct sunlight, otherwise it may cause deformation or
malfunction;
◆please keep this product away from flammable or naked flame;
◆please do not repair this product by yourself. Only qualified personnel can be repaired.
PAGE 1 OF 5
WC5EM2601F
Version 1.0
