PuraLev
This manual contains information necessary for the safe and proper use of the PuraLev
Included are specifications for the standard configurations and instructions regarding its use, installation,
operation, adjustment, inspection and maintenance. For detailed description of the menu structure and the
configuration possibilities with the touch screen user interface the console software manual PL-4067-00 can
be consulted. For the configurations and features described in this manual revision the console software
LCO V1.09 R19 or higher is needed. For special configurations of the system refer to accompanying
information. Please familiarize yourself with the contents of the manual to ensure the safe and effective use
of this product. After reading this manual, please store the manual where the personnel responsible for
operating the pump system can readily refer to it at any time.
PL-4049-00, Rev03, DCO# 23-129
PuraLev
LCO-600
®
200SU/MU and PuraLev
USER MANUAL
User Manual for LCO-600 Console
®
Console
®
www.levitronix.com
600SU/MU
®
LCO-600 Console.
First Release: 19-Oct-2015
Last Update: 30-Jun-2023
Advertisement
Table of Contents
Related Manuals for Levitronix PuraLev LCO-600
Summary of Contents for Levitronix PuraLev LCO-600
- Page 1 User Manual for LCO-600 Console www.levitronix.com ® PuraLev Console LCO-600 ® ® PuraLev 200SU/MU and PuraLev 600SU/MU USER MANUAL ® This manual contains information necessary for the safe and proper use of the PuraLev LCO-600 Console. Included are specifications for the standard configurations and instructions regarding its use, installation, operation, adjustment, inspection and maintenance.
-
Page 2: Table Of Contents
User Manual for LCO-600 Console www.levitronix.com Table of Contents SAFETY PRECAUTIONS..................................3 SPECIFICATIONS ....................................4 Specification of Console Components ............................4 System Overview and General Specification ..........................8 2.2.1 Basic Stand-Alone System Configuration................................8 2.2.2 Extended System Configuration ..................................8 General Environmental Conditions..............................9 Basic Dimensions of Console ................................9 ENGINEERING INFORMATION ................................10... -
Page 3: Safety Precautions
Concerning safety precautions for motor, pump and sensors refer to the corresponding manuals. CAUTION ® Do not under any circumstances open the console enclosure. Levitronix does not assume responsibility for any damage, which occurs under such circumstances. -
Page 4: Specifications
® ® ® Note 1: Options with gamma irradiation available. Note 2: See Levitronix user manuals of PuraLev 200/600SU and and PuraLev 200/600MU for more detailed specifications) Note 3: Sterile fitting option available. Figure 1: LCO-600 console with compatible motors and pump heads... - Page 5 Article # Calibrated Liquid SU Flow Pipe Fitting, ID Note Barb, 1/8” LFSC-i05X.1-001 (0.2/1 lpm) 100-30490 LFP-05SU / 05SU.1 ® See relevant Levitronix LFSC-i09X.1-001 (4 lpm) 100-30491 LFP-09SU Barb, 1/4" technical brochures for Barb, 3/8” ® LEVIFLOW Clamp-On LFSC-i13X.1-001 (20 lpm)
- Page 6 User Manual for LCO-600 Console www.levitronix.com Pos. Component Article Name Article # Fittings Specification Wet Material Note 3/8” Hose Barb PREPS-N-038 190-10375 PendoTECH Single-Use PREPS-N-5-5 190-10373 3/4" Sanitary Clamp Pressure range: See PendoTECH literature for Polysulfone Pressure Sensors PREPS-N-1-1 190-10374 1"...
- Page 7 User Manual for LCO-600 Console www.levitronix.com Pos. Component Article Name Part # Characteristics Special Feature / Description ® LEVIFLOW Cable Jacket Material LFI-C.1-30 (3m) 190-10308 Interconnect Cable Main Purpose Connection between flow sensor LFSC-D/LFS-SU and console IP Cable Signal 4 Cable Jacket Material ICS-3.1-30 (3m)
-
Page 8: System Overview And General Specification
User Manual for LCO-600 Console www.levitronix.com 2.2 System Overview and General Specification 2.2.1 Basic Stand-Alone System Configuration Figure 5 With the stand-alone pump system configuration, as illustrated in , the speed of the pump can be set manually ® and the flow can be monitored with a LEVIFLOW flow sensor. -
Page 9: General Environmental Conditions
User Manual for LCO-600 Console www.levitronix.com 2.3 General Environmental Conditions Usage Indoor (Laboratory, Industrial environments) Altitude Up to 2000 m Operating ambient temperature 10 to 40 °C Storage ambient temperature (Extremes for Transportation) -20 to 70 °C 15 – 95% (non-condensing) Operating humidity range (relative humidity) 15 –... -
Page 10: Engineering Information
User Manual for LCO-600 Console www.levitronix.com 3 Engineering Information 3.1 IP Rating The console is designed and tested to meet IP66. As illustrated in Figure 8 the IP68 rated fan and the heat exchange area is sealed from the inside of the console. -
Page 11: Installation
User Manual for LCO-600 Console www.levitronix.com 4 Installation 4.1 Mechanical Installation The console LCO-600 is made for desktop operation on a horizontal surface or can be wall-mounted to an appropriate vertical surface. For wall-mounting the four pre-assembled rubber stands on the bottom must be removed. -
Page 12: Electrical Installation
User Manual for LCO-600 Console www.levitronix.com 4.2 Electrical Installation 4.2.1 Connection Overview Figure 11 shows the various interfaces of the console. The corresponding designations are listed in Table 10. Figure 11: Interfaces of console LPC-600.1 Note 1: All connectors come delivered with a protective cap for a min. IP66 rated sealing if unused. -
Page 13: Plc Interface
Pressure. Table 11: PLC connector of Console 1: Wires of compatible cables: ICS-2.1-xx 2: Designations are for standard firmware. Example of User Interface Levitronix Console PLC Inter face Circuit 24 VDC 11: Analog Out High Pin 4..20 mA 12: Analog Out Low Pin 33-750 Ω... -
Page 14: Analog Input With 24Vdc Supply
For speed control of fan cooling module FCM-600. Table 12: Analog Input with 24 VDC Supply (M12 female socket, 5 pos.) 1: Depends on used cable. 2: Designations are for standard firmware. Levitronix Console Typical Sensor Analog In / 24 VDC (4-20mA Signal Output Interface and 24 VDC Supply) max. -
Page 15: General Installation Instructions
User Manual for LCO-600 Console www.levitronix.com 4.2.4 General Installation Instructions CAUTION ® ® Do not connect the PuraLev 200 and PuraLev 600 motors to the console at the same time, as they can not be operated simultaneously. WARNING Hazardous voltage may be present. -
Page 16: Operation
User Manual for LCO-600 Console www.levitronix.com 5 Operation The console contains a self-explaining touch screen user interface with various menus to operate, configure and troubleshoot the system. In this section only the basic functions for a safe usage are explained. For more details consult the LCO Console Software Manual PL-4067-00. -
Page 17: Auto-Resume Feature
The LCO-600 console software offers the possibility to update itself as well as the underlying components © firmware versions. A new software/firmware package will be provided by Levitronix as a single file with the file ending *.levi. Follow the procedure below for an update: 1. -
Page 18: Maintenance
If problems or failures can’t be solved with the help of the notification on the console screen, it is recommended to capture a data log during operation, as described in LCO Console Software Manual PL-4067-00, until the ® failure appears and then send the data log file to the Levitronix Technical Service Department or the appropriate key account manager. -
Page 19: Appendix
9.1 Regulatory Status 9.1.1 CE and UKCA Marking ® The Levitronix LCO-600 Console, in its various configurations as listed below, conforms with the below mentioned European Directives and UK Statutory Instruments. The console is designed to be used in laboratory and industrial production environments of Life Science markets like Biotech and Pharmaceutical processing. -
Page 20: Symbols And Signal Words
User Manual for LCO-600 Console www.levitronix.com 9.2 Symbols and Signal Words Symbol / Description Type Source Signal Word Indication of an imminently hazardous situation that, if not DANGER avoided, will result in death or severe injury. Limited to the Signal word...
