WiSilica Radiar AR10 Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Radiar AR10
Radiar AR10 is a BLE5.2 controllable, dual-channel 0-10V room controller. The device
is powered by 277VAC voltage, also has a 20A relay to use it as a room controller or as
a plug-load controller. It comes with Class-1 and Class-2 dual channel 0-10V dimming
outputs, 0-10V sensor input, and 12V auxiliary output. The high output ratings within
the device makes it suitable to control multiple numbers of light fixtures within a
room. The device comes with 150mm external wire antenna for communication.
The
Lumos
Controls
ecosystem
comprises
controllers,
sensors,
switches,
modules, drivers, gateways, and analytical dashboards, and can be connected to the
Lumos Controls cloud for data analytics and configuration
management.
The
lighting network's configuration, commissioning, and controlling can be done
super-quick from any mobile device. The ecosystem is listed by the Design
Lights
Consortium
(DLC), qualifying it for energy conservation incentive
programs and rebates utility companies in North America.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Radiar AR10 and is the answer not in the manual?

Questions and answers

Related Manuals for WiSilica Radiar AR10

Summary of Contents for WiSilica Radiar AR10

  • Page 1 Radiar AR10 Radiar AR10 is a BLE5.2 controllable, dual-channel 0-10V room controller. The device is powered by 277VAC voltage, also has a 20A relay to use it as a room controller or as a plug-load controller. It comes with Class-1 and Class-2 dual channel 0-10V dimming outputs, 0-10V sensor input, and 12V auxiliary output.

  • Page 2: Table Of Contents

    Radiar AR10 Table of Contents Features ................................3 Specifications ..............................3 Dimensions ................................ 5 Wire Description............................... 5 Antenna Information ............................7 Wiring Types ..............................7 Wiring Diagram ..............................8 Items included in the package box ......................9 Ordering Information ............................. 9...

  • Page 3: Features

    Radiar AR10 Features  Dual channel 0-10V independent output to control intensity and color temperature (CCT).  Load control up to 20A @ 120/277VAC.  Auxiliary 12V/100mA output to power the sensors.  0-10 VDC input channel to integrate with third party sensors.
  • Page 4 Radiar AR10 Voltage Range 0-10VDC Analog input Auxiliary Output Value Remarks Voltage 12VDC Current 100mA Bluetooth Value Remarks Frequency 2402-2480 MHz Max output power 8 dBm Receive sensitivity -95 dBm vary depending on the Connection distance (device to 45m (146 ft)

  • Page 5: Dimensions

    Radiar AR10 Dimensions Wire Description...
  • Page 6 Radiar AR10 Class-1 outputs Name Color Guage Rating Description Line Black 12AWG (4.0mm2) 600V 120-277VAC Common White 12AWG (4.0mm2) 600V 120-277VAC Neutral Load 14AWG (2.5 mm2) 600V 120-277VAC 0-10V DIM1+ Purple 20AWG (0.5mm2) 600V 0-10VDC/100mA 0-10V DIM2+ Orange 20AWG (0.5mm2)

  • Page 7: Antenna Information

    Radiar AR10 Antenna Information 150mm wire antenna Antenna Properties Frequency range 2.4 GHz-2.5GHz Impedance 50 Ω Nominal VSWR 1.92:1 Max Return loss -10 dB Max Gain(peak) 2 dBi Cable loss 0.3 dBi Max Polarization Linear vertical Wiring Types Class-1 wiring ...

  • Page 8: Wiring Diagram

     A Class 2 wiring may be installed free within the wall or ceiling without line voltage rated insulation or protection of conduit or a cable assembly. Wiring Diagram Configuring Radiar AR10 for dimming, tuning and an external sensor control.

  • Page 9: Items Included In The Package Box

    Radiar AR10 Configuring Radiar AR10 for Plug Load Control Items included in the package box  Radiar AR10  User Manual  Antenna Ordering Information Inbuilt Communic Output Relay Power Product Code Product Description Voltage Rating Sensor Input Aux Power...
  • Page 10 Radiar AR10...
  • Page 11 Radiar AR10 Version 1.6 FCC Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This...
