IdeaFormer IR3V2 User Manual

Hide thumbs

Advertisement

Table of Contents

IDEAFORMER IR3V2
USER MANUAL
www.ideaformer-3d.com
STRIVE TO CREATE EXCELLENT QUALITY

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IR3V2 and is the answer not in the manual?

Questions and answers

Related Manuals for IdeaFormer IR3V2

Summary of Contents for IdeaFormer IR3V2

  • Page 1 IDEAFORMER IR3V2 USER MANUAL www.ideaformer-3d.com STRIVE TO CREATE EXCELLENT QUALITY...
  • Page 2 Video Tutorial https://www.youtube.com/@ideaformer2353...

  • Page 3: Table Of Contents

    Content Notes Product Introduction Parts List Product Assembly Usage Steps Function Descriptions...
  • Page 4 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 5 User Precautions： 1.To ensure device safety, please use the power adapter included with the printer. 2.Please place the printer in a well-ventilated, shady, and dust-free environment to ensure its stable operation. 3.When plugging or unplugging the power cord, please ensure your hands are dry.

  • Page 6: Product Introduction

    Product Introduction Product Overview ① Infinite z-axis ② Metal conveyor belt ③ Automatic leveling ④ high-speed printing...
  • Page 7 Product Parameter Printing technology： 250×250×∞mm （X*Y*Z） Print size： Product size： 700×436×506mm Package size： 770*510*320mm Print accuracy： ±0.1mm Layer thickness： 0.1-0.4mm Nozzle diameter： 0.4mm Printing speed： 300mm/s Filament materials： PLA,Silk PLA,Wood PLA,PETG etc. Slicing software： Ideamaker Input format： STL,OBJ etc. Output format： gcode Printing method：...

  • Page 8: Parts List

    Parts List Conveyor belt Fixed plates Filament Frame&Print platform holder Screen Camera Filament Type-C cable Controller motion sensor Micro SD USB flash Filament Power Cable drive M4*6 M4*8 M5*18 M5*20 Teflon Screws Nozzle Diagonal pliers Tweezers Needle Cable tie Instruction Manual T-nut Wrenches...

  • Page 9: Product Assembly

    Product Assembly Install the XY-axis Frame 1.Place both the conveyor belt platform and the XY-axis frame sideways, and secure them with two M5*14 cup head hexagon socket screws. 2.Then use M5*14 round head socket cap screws to install the fixed plate on one side onto the aluminum profile.
  • Page 10 To measure if the frame's angle is 45 degrees, use a triangle ruler. If the measurement is not 45 degrees, please loosen the screws and make the necessary adjustments. ！ 45° M5*14 Cup Head M5*14 Round Head...
  • Page 11 Check if the XY-axis movement is smooth. To enhance the stable operation of printers, it is recommended to regularly check the smoothness of XY-axis movement and apply an appropriate amount of lubricant, as well as promptly clean dust and impurities from the tracks, ensuring continued efficient and precise performance.
  • Page 12 Install Screen&Filament Holder Screen，Filament Holder，M4*6 x4，T-nuts x4 M4*6+T-nut M4*6+T-nut...
  • Page 13 Wire Connection Connect the screen，the X and Y motors, the filament motion sensor，the print head and power cable. xy-motor connection screen camera printing head sensor...
  • Page 14 Teflon connection Securely tie the print head cable and Teflon tubing with ties and fasten them to the bracket. Otherwise, there's a risk of them getting tangled with the motor, leading to layer shifting during printing, and in severe cases, potentially damaging the printer. ！...

  • Page 15: Usage Steps

    Usage Steps After completing the assembly, Power on and wait for main interface.The process consists of five steps: 1.Autoleveling. 2.Connect to WiFi. 3.Preheat and load filament. 4.Install the software and upload the file. 5.Start printing and demoulding. Autoleveling Autoleveling is a must! Skipping this step can damage your printer's steel belt. So, right after you turn on your printer, make sure to start the autoleveling.
  • Page 16 3.leveling is complete, Tap② Accept to finalize auto-leveling and save your settings. ② You don't need to perform auto leveling every time you turn on the printer. It's only necessary when the model fails to adhere properly, or when you replace the XY motors ！...
  • Page 17 If the data difference between the leftmost and rightmost points exceeds ±0.2, loosen the two screws inside ① and adjust the tightness of the belt by turning the screw inside ②. ① ② Normally, the belt tension has been adjusted before shipment, and you should not need to make any adjustments.
  • Page 18 Connect to WIFI & Get IP By using the IP address, you can upload sliced files and control your printer remotely, whether from a computer or a mobile device. ！ 1.Tap ①Configuration, ②Network to enter the Wi-Fi connection interface. ① ②...
  • Page 19 5.Tap the blue button ⑥ to toggle the Wi-Fi, and you will obtain the IP address. ⑥ 6.Record the printer's IP address ⑦. ⑦ If the IP address doesn't show up， try reconnecting to the network. ！ 7.Open a web browser and type in the IP address ⑩. Enter. ⑧...
  • Page 20 Preheat and Load Filament The purpose of this step is to load the filament, ensuring it is properly loaded in the printer. A test extrusion will then be performed to check if the filament passes smoothly ！ through the nozzle, minimizing the risk of printing faults. 1.First, preheating.
  • Page 21 3.Open the side wrench of the print head, manually insert the filament into the nozzle position, and then try to extrude it. ！ 4.Tap on "Extrude" ⑤ on the main screen, then tap "Extrude" ⑥ to see if the nozzle is extruding properly.
  • Page 22 Software Setup & File Upload USB flash drive contains the installation package of ideamaker and the printer configuration file. After installing the software, follow the steps to import the printer ！ configuration file. 1. After installation is complete, open the software and click finish the configuration wizard.
  • Page 23 4.inport models④. ④ 5.Start slicing⑤. ⑤ 6. After slicing, preview and then ⑥ export the file locally. ⑥ 7.Enter your 3D printer's IP address⑦ in the browser to upload the print file. ⑦ The file size limit for uploading is 490MB, and files exceeding this limit will fail to upload successfully.
  • Page 24 Start Printing&Demoulding During printing, avoid uploading files to prevent issues. Max file size is 490MB; larger files must be copied to USB for printing. ！ 1.After completing the above steps, you are ready to embark on your printing journey. ② ①...

  • Page 25: Function Descriptions

    Function Descriptions Filament Motion Sensor The filament motion sensor is designed to detect conditions such as filament exhaustion or clogging, enabling the printer to pause operation when necessary to prevent print ！ failures.After pausing, please follow these steps. 1.Select Temperature Settings: Tap① the "temperature" . ①...
  • Page 26 5.Insert the new filament, pushing it all the way to the end. Then, tap on "Extrude" ⑤ to attempt extruding the new filament to check if it flows smoothly. ⑤ 6. ⑥ Return, and then ⑦ resume the printing process. ⑥...
  • Page 27 Camera&Led Once the camera is successfully connected, you can monitor the status of the printer through its IP address. If the lighting is insufficient at night, you can choose to turn on the LED lights to enhance visibility. Click on ①the black circle, and you will see ②a slider bar for adjusting brightness. By sliding this bar, you can easily adjust the brightness ①...
  • Page 28 Remote control Remote control of printers through software such as Obico and OctoEverywhere. 1.To connect to a server via SSH using MobaXterm, first download and open the MobaXterm software. Then, click on the "Session" tab located at the top left corner of the interface.
  • Page 29 2.For the username, type "ideaformer" and for the password, type "1234" 3.Successfully accessed the printer. 4. enter the following command: cd moonraker-obico &&./install.sh 5.After seeing 'moonraker host: 127.0.0.1', press Enter four times. Then, when prompted 'Are you sure you want to continue?', type 'Y' and press Enter to confirm.
  • Page 30 6.After seeing 'Scanning the local network', please open the Obico mobile app. Note: Both the mobile device and the printer must be connected to the same Wi-Fi network, otherwise the app will not be able to ！ discover the printer. 7.Register and log in, then follow the steps in the image to bind the printer.
  • Page 31 8.Then, you will be able to control the printer.

  • Page 32: After Sales Service

    After-sales Service QQ group:193844205 Email:tech-1@bell-ideaformer.com Facebook group: Ideaformer IR3,IR3 V1,IR3 V2 conveyor belt 3D printer Skype group: https://join.skype.com/NMHILjGLDO4u Skype support :.cid.2907007ac179b00b Warranty Parts Period Hotend，Conveyor belt，Accessories, Tools, Filament, SD card No warranty Electronic Components, Printer Frame, Extruder,Timing Belt,Linear Rail, Motor...
  • Page 33 Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 34 珠海贝尔科技有限公司 Zhuhai Bell Technology co., Ltd QQ group:193844205 Email:tech-1@bell-ideaformer.com Facebook group: Ideaformer IR3, IR3 V1 , IR3 V2 conveyor belt 3D printer Skype group: https://join.skype.com/NMHILjGLDO4u Skype support :.cid.2907007ac179b00b...
