GARDENIQUE OF21021 Instructions

--------------------------------------------------------------------------------------------------------------------------------------
Questions, Problems, Missing Parts? Before returning to your retailer, CALL OUR CUSTOMER
SERVICE DEPARTMENT at 1(866)869-5300 8 a.m.– 6 p.m. EST, Monday – Friday or e-mail us at
PARTS LIST:
Part# Description
01. Fountain
02. Pump
TOOLS REQUIRED FOR ASSEMBLY:
No tools required for assembly
FOUNTAIN ASSEMBLY INSTRUCTIONS:
1. Unpack the contents of the box and check to make sure that all items are accounted for and in good condition.
2. Select a flat, level surface for the assembly and final location of your fountain.
3. This fountain is intended to be mounted on the wall. It is important to make sure that the wall be able to support the weight of the fountain.
The fountain plus the water will weigh approximately 30Ibs.
4. Place the water pump in the bottom of the basin. Route the power cord of the pump through the access door on the back of the fountain and
turn the flow control knob on the pump to the maximum (+) setting.
5. Connect the water supply tube which extends from the bottom of the top to the outlet on the pump. Fig1.
6. Measure the distance between 2 hooks on the back of the fountain and mark on the wall for drilling.
7. Drill 2 holes on the wall. Depending on the structure of the wall, special anchors may have to be used.
8. Insert 2 screws into the holes. Do not screw fully into the wall. Leave about ¼" exposed to engage the hooks on the back of the fountain.
9. Hang the fountain on the wall by matching the hooks of the fountain with the heads of the screws.
10. Add clean water into the basin. The water level should be approximately 1-2" below the rim of the basin. Make sure the water not overflow
through the back access door.
11. Plug the powers cord from the pump into a properly grounded, grounding type receptacle.(GFCI)
12. If water splashes, unplug the power cord and adjust the flow control knob on the water pump.
13. To eliminate the possibility of water damage to the area around your fountain, check for leaking and excessive splashing after the initial
setup of your fountain. It is highly recommended that this fountain should be placed in an area that will not be damaged should the area
come in contact with water.
14. Do not leave your fountain running for extended periods of time when no one is present to observe the performance.
15. Check the area around your fountain on a regular basis to ensure that there is no leakage.
MAINTENANCE OF YOUR FOUNTAIN:
1. Keep water clean - using clean water will reduce mineral deposits and improve water clarity.
2. Clean the fountain periodically to prevent mineral deposits and contamination. Use warm soapy water and a stiff brush for heavily stained
surfaces. Do not use harsh chemicals as this will damage the finished surface and void the warranty.
3. Add clean water periodically to ensure that the pump is fully submersed in water.
4. To prevent algae growth, use an algaecide formulated for fountains, such as Total Pond algaecide for ponds and fountains. (Item# A20018)
5. Disconnect the power and empty the basin if the fountain will not be used for an extended time.
6. If installed outdoors and in a freeze-area of the country, ensure that all water is removed and the unit is completely dry. This product is
NOT to be operated below 41℉ (5℃) or freeze damage may occur.
PUMP INSTRUCTIONS:
SPECIAL WARNINGS & CAUTIONS:
WARNINGS:
1. To reduce the risk of electric shock, connect only to a properly grounded, grounding type receptacle.
2. Do not exceed the voltage shown on the pump.
3. Always disconnect the pump from the power source prior to beginning any maintenance or work on the pump or fountain.
4. Inspect the power cord for damage before installation and/or maintenance. Replace the entire pump if damage is found.
5. For pumps with a 3-prong, grounded type plug, do not remove the grounding pin from the plug on the power cord.
6. Do not splice or alter the length of the power cord as this will void the warranty of the pump.
CAUTIONS:
1. The fountain shall not be installed within 10 feet (3.05m) of a pool or spa. When the pump is connected to a GFCI protected circuit, the
fountain unit has the option of being installed no less than 5 feet (1.52m) from a pool or spa.
2. Use only with portable, self contained fountains no larger than 5' in any direction.
3. Use a proper power source as indicated on the pump label. Keep the cord away from high temperature and/or heat sources.
4. Do not lift the pump by its power cord.
5. Keep the fountain out of reach of children.
6. Do not let the pump run dry. Pump must be completely submerged for proper operation and cooling.
7. Do not pump heated or flammable liquids.
8.
Operate in freshwater only. Avoid heavily chlorinated water and water with high PH levels.
Item Description: Wall Fountain with Bird
customerservice@geoglobalpartners.com
Quantity Part# Description
1
1
INSTRUCTIONS
Item # OF21021
Quantity
