REMINDER
CALL 1-888-755-5641
BEFORE RETURNING TO STORE.
PACKAGE CONTENTS
Part
A
B
C
D
E
Large fiber planter
F
Small fiber planter
Tank assembly (with pump, filter and LED
G
H
I
Waterbell nozzle insert
J
Trumpet nozzle insert
K
Lower fountain head nozzle
L
B
E
Natural Fiber Two Tier Fountain and
Planter
Description
Base frame
Large frame
Small frame
Connector
ring)
Transformer
Adapter
C
F
Questions, problems, missing parts? Before returning
to your retailer, call our customer service department at
1-888-755-5641, 8 a.m.-6 p.m., EST, Monday-Friday, or
email us at customercare@gardeniquedecor.com. Or
visit our website www.gardeniquedecor.com.
Quantity
1
1
1
1
1
1
1
1
1
1
1
1
A
D
H
J
I
ITEM # DCIPF2
K
L
G
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for GARDENIQUE DCIPF2
Summary of Contents for GARDENIQUE DCIPF2
- Page 1 Natural Fiber Two Tier Fountain and Planter ITEM # DCIPF2 REMINDER Questions, problems, missing parts? Before returning to your retailer, call our customer service department at CALL 1-888-755-5641 1-888-755-5641, 8 a.m.-6 p.m., EST, Monday-Friday, or BEFORE RETURNING TO STORE. email us at customercare@gardeniquedecor.com. Or visit our website www.gardeniquedecor.com.
- Page 2 WARNINGS AND CAUTIONS: PUMP WARNING Do not exceed the voltage shown on the pump. Always disconnect pump from the power source before beginning any maintenance or work on the pump. Inspect cord for damage before installation and/or maintenance. Replace the entire pump assembly if damage is found.
- Page 3 2. Put the large fiber planter inside the frame. Fig. 2 Fig. 2 3. Make a hole appropriately 2 in. diameter in the bottom of fiber planter. Fig. 3 Fig. 3 4. Install the connector. Fig. 4 Fig. 4...
- Page 4 5. Install the small frame. Fig. 5 Fig. 5 6. Put the small fiber planter inside the frame. Fig. 6 Fig. 6...
- Page 5 7. Make a hole appropriately 3/4 in. diameter in the bottom of fiber planter by pushing the plug by hand. Fig. 7 Hole for power cord Fig. 7 8. Run the cord of pump through the new hole and connector. Use fiber cover the hole well around the cord.
- Page 6 9. Put soil inside the large fiber planter, then place plants in. Fig. 9 NOTE: Soil and plants are NOT INCLUDED. Fig. 9 10. Connect the adapter to the pump, then attach the LED ring. Fig. 10 Fig. 10 11. Choose a fountain head for the desired water effect, and assemble your choice as shown in Fig.
-
Page 7: Maintenance Procedure
12. Fill the tank with water, 2/3 up to the top. Adjust tank assembly to make sure the top of tank is level. Fig. 12 Fig. 12 13. Connect the pump to the transformer by pushing the plug into the transformer socket until it is firmly seated. Hand tighten Transformer the nut from the plug to the socket. -
Page 8: Troubleshooting
2. Pull off the filter cover and remove the filter pad. Rinse the filter pad to remove any debris. Fig. 16 Fig. 16 3. Disassemble the pump and clean the internals of the pump. Fig. 17 Fig. 17 4. Reassemble the pump and filter box kit. Fig. 18 Fig. -
Page 9: Replacement Parts List
If the performance of the pump is not satisfactory or the pump does not flow evenly: Check to make sure the pump is completely submerged in water. Check to make sure the impeller and the impeller housing are clean. ... -
Page 10: Limited Warranty
This warranty period begins on the date of purchase by the original purchaser. Unless otherwise specified all GARDENIQUE® electrical products are warranted to the user against defective material and workmanship, under normal working conditions for 1 year from the date of purchase.
