NI-9223 Getting Started NI-9223 Getting Started ±10 V, 1 MS/s, 16- Bit, Simultaneous Input, 4-Channel C Series Voltage Input Module Contents Connector Types ......... -
Page 3: Connector Types
NI-9223 Getting Started Connector Types The NI-9223 has more than one connector type: NI-9223 with screw terminal , NI-9223 with snap in terminal, and NI-9223 with BNC. Unless the connector type is specified, NI-9223 refers to all connector types. NI-9223 Block Diagram... -
Page 4: Grounded Connections
• You must use 2-wire ferrules to create a secure connection when connecting more than one wire to a single terminal on the NI-9223 with screw terminal and NI-9223 with snap in terminal. Wiring for High-Vibration Applications If your application is subject to high vibration, NI recommends that you use the NI 9971 backshell kit to protect connections to the NI-9223 with screw terminals or NI 9990 backshell kit to protect connections to the NI-9223 with snap in terminals. -
Page 5: Cable Requirements For Emc Compliance
• Use ferrules to terminate wires to the detachable connector. Cable Requirements for EMC Compliance Select and install cables for the NI-9223 with screw terminal and NI-9223 with snap in terminal in accordance with the following requirements: • Connect the cable shield to the chassis ground (grounding screw of the chassis) using the shortest length of wire possible. - Page 6 NI-9223 Getting Started Tél. 01 47 95 99 71 e-mail : ni@es-france.com ES France - Département NI Fax. 01 47 01 16 22 Site Web : www.es-france.com 127 rue de Buzenval BP 26 - 92380 Garches ni.com...
- Page 7 For patents covering NI products/technology, refer to the appropriate location: Help»Patents in your software, the patents.txt file on your media, or the National Instruments Patent Notice at ni.com/patents. You can find information about end-user license agreements (EULAs) and third-party legal notices in the readme file for your NI product. Refer to the Export Compliance Information at ni.com/legal/export-compliance for the NI global trade compliance policy and how to obtain relevant HTS codes, ECCNs, and other import/export data.
