The instructions in this manual are intended for personnel with a general training in operation and maintenance of centrifugal pumps. Toyo Pumps reserves the right to change the design, construction material of any part without incurring the obligation of installing such changes on pumps already delivered.
TOYO PUMPS NORTH AMERICA CORPORATION 2 Terms and Conditions By placing this piece of equipment into service you agree to the Terms and Conditions below. TPNA’s acceptance to supply equipment is conditional upon the Buyer’s and subsequent Owner’s agreement that the Terms and Conditions set out below govern the relationship between the Manufacturer and Owner.
TOYO PUMPS NORTH AMERICA CORPORATION d) On equipment and materials furnished by TPNA, but manufactured by others, the Buyer shall accept in lieu of any liability or guarantees on the part of TPNA, the benefits of any guarantees (if any) that are obtained by TPNA from such manufacturers or vendors.
TOYO PUMPS NORTH AMERICA CORPORATION 2.6 Arbitration: If there is any disagreement, dispute or controversy (a "Dispute") between the parties with respect to any matter arising under this Agreement or the construction of this Agreement, then the Dispute shall be referred to and finally resolved by arbitration under the rules of the Commercial Arbitration Act, R.S.B.C.
The unit should be inspected upon arrival. If there are any product irregularities, contact HEVVY-TOYO immediately. Damage due to shipment should be reported to the carrier. Care should be taken when unpacking and moving pumps. Rough handling of the pump can cause breakage.
TOYO PUMPS NORTH AMERICA CORPORATION WARNING! Using the pump outside its temperature range could lead to electrical hazards or pump failure. 3.3 Installing the Pump 1. Lifting the pump can be done by securing a rope/chain to the eye bolts, ensuring not to drop or heavily impact the unit on contact.
5. If the cabtyre cable requires extending, use a conductor size equal to or greater than the previous cable to maintain performance and prevent overheating. For length longer than a total cable length of 100 feet consult your cable supplier or Toyo to confirm line voltage drop is less than 5% total.
Page 11
TOYO PUMPS NORTH AMERICA CORPORATION 6. Keep the power supply and cabtyre cable away from water. If the cabtyre cable needs to be submerged in water, make certain there is no damage to the insulation and any splices are completely sealed and protected from water damage.
TOYO PUMPS NORTH AMERICA CORPORATION 4 Operation 4.1 Pre-start Checks 1. Double check that the frequency and voltage ratings are correct for the pump model. Caution Using incorrect power ratings may lead to damage of the pump as well as lower performance and efficiency.
Refer to nameplate data. If current exceeds the rated value overloading the motor is the likely reason, check pump specifications. 4. Stop the test operation of the pump if abnormal sounds, vibration or odor result and contact Toyo immediately. If no problems arise, allow the pump to continue under operation. Caution Allowing the pump to operate under such non-desirable conditions may result in electrical hazard or damage.
TOYO PUMPS NORTH AMERICA CORPORATION 4.4 Shut down 1. Prior to pump shutdown lift the pump into clear fluid for several minutes to completely flush the system of any slurry. Caution Never stop the pump while pumping slurry through the lines as there is a risk the lines will plug and the pump will be buried.
TOYO PUMPS NORTH AMERICA CORPORATION 5 Storage 5.1 General Instructions The pump is protected against corrosion for the period of shipment and installation only. If the pump is not to be installed right away, find a clean, dry location for storage indoors.
Recommended OEM authorized inspection. Every 1-2 Years depending on severity of service Consult Toyo for seal refurbishment/replacement if necessary. Out of Use Clean and dry the pump for indoor storage. Rotate once a month by hand.
TOYO PUMPS NORTH AMERICA CORPORATION 6.2 Lubrication and Additional Maintenance 1. For details on approved oil and grease for pump lubrication, see Appendix. 2. Always tailor lubrication intervals to your application specific requirements. If pump is run intermittently, the oil reservoir should be examined more often.
TOYO PUMPS NORTH AMERICA CORPORATION 6.4 Electrical Check (Megger Test) Whenever the pump is serviced the following test should be performed to check the insulation resistance of the motor and cable. 1. Disconnect the cabtyre cable from the power source.
Page 19
TOYO PUMPS NORTH AMERICA CORPORATION 7. Any motor reading less than ten (10) meg-ohms (M) indicates damage in the motor in which case the motor must be checked by a qualified repair facility. Caution: It is very important that appropriate corrective action/repair be performed before the pump is returned to service if it does not pass the Megger Test.
TOYO PUMPS NORTH AMERICA CORPORATION 7 Troubleshooting Problem Possible Causes and Solutions Pump will not start. The power has not been turned on. Fuse or circuit breaker blown. The power supply is inadequate. The motor is burned out or is burning out.
Page 21
TOYO PUMPS NORTH AMERICA CORPORATION Problem Possible Causes and Solutions Lift or discharging capacity is The suction strainer is clogged and requires cleaning of debris. low. The pump may be placed on a mounting block to reduce clogging. The motor direction is reversed. See sections on Electrical and Test Operation for interchanging leads.
TOYO PUMPS NORTH AMERICA CORPORATION 8 Pump Assembly Inspect and inventory all parts before you begin assembly. Clean the parts and remove any burrs as required. Assembly should be performed in a clean, dust free area. Read instructions and drawings before you begin.
TOYO PUMPS NORTH AMERICA CORPORATION 8.1 Motor Assembly 1. Ensure the Stator Housing is secured to proper work bench. 2. Attach the studs to the Stator Housing. TED-236 Section 8 - Pump Assembly PAGE 20...
TOYO PUMPS NORTH AMERICA CORPORATION 8.2 Rotor Bearing Assembly 1. Slide the Bearing Cover onto the Rotor assembly. 2. Preheat both Inboard and Outboard Bearings to 110–115 °C (230–240 °F) in an induction heater, oven, or oil bath. Note: An induction heater will have the best results for even heating.
Page 25
TOYO PUMPS NORTH AMERICA CORPORATION 3. Attach O-ring to the Stator Housing. 4. Apply a thin coat of grease to the Inboard Bearing. Insert the Rotor Assembly into the Stator Housing. Note: Ensure bearing is seated properly. 5. Attach the Bearing Housing to the Stator Housing with socket head cap screws.
TOYO PUMPS NORTH AMERICA CORPORATION 7. Attach the Lower Stationery Seat onto the Pump Casing. 8. Attach the Mechanical Seal Washer to Pump Casing using hex bolts and lock washers. This will hold the Lower Stationery Seat in place. 9. Attach the Distance Sleeve. Make sure it fits tight between the shaft and the Lip Seal.
TOYO PUMPS NORTH AMERICA CORPORATION 3. Attach the two Oil Sight Glass Covers – one on each side of the pump. 4. Attach the Key into the Keyway. 5. Attach the Impeller. 8.5 Suction Cover and Shim Assembly 1. Attach the Suction Cover to the Pump Casing with lock washers and socket head cap screws.
Page 28
TOYO PUMPS NORTH AMERICA CORPORATION 2. Tighten the Suction Cover firmly against the Pump Casing until it makes contact with the impeller vanes. Measure the remaining gap between the Suction Cover and the Pump Casing. 3. Make up a Shim Pack to get as close as possible to the measured gap.
TOYO PUMPS NORTH AMERICA CORPORATION 8.6 Final Assembly Attach the Agitator. Attach the Washer, Lock Washer, and Hex Nut. 3. Attach the Strainer. 4. Attach the Discharge Elbow with lock washers and hex bolts. TED-236 Section 8 - Pump Assembly...
TOYO PUMPS NORTH AMERICA CORPORATION 8.7 Adding Oil to Oil Chamber Use the table below to determine the correct quantity of oil to use for your pump. Toyo Pumps come assembled with MOBIL SHC 624 Synthetic Bearing and Gear Oil. Use this oil or similar ISO VG 32 oil to refill chambers.
TOYO PUMPS NORTH AMERICA CORPORATION 9.2 Technical Data Sheet – 60Hz Pump Data Pump Model HT-3 HT-5 HT-7.5 Discharge Diameter (in.) Flow at rated point (USgpm) Head at rated point (ft) Impeller Diameter (in.) 4.33 5.12 8.07 Impeller No. of Vanes Max.
TOYO PUMPS NORTH AMERICA CORPORATION 9.3 Technical Data Sheet – 50Hz Pump Data Pump Model HT-3 HT-5 HT-7.5 Discharge Diameter (mm) Flow at rated point (m /hr) Head at rated point (m) Impeller Diameter (mm) Impeller No. of Vanes Max. Solid Size (mm) Rated Output (HP) No.
TOYO PUMPS NORTH AMERICA CORPORATION 9.4 Customer Fill-in Data Sheet Start-up Operating Customer Data Conditions Metric Imperial Flow (USPGM) Normal Maximum Minimum Discharge Pressure (PSI) Slurry S.G. Solids % by volume Maximum particle size (In.) Temperature (°F) Start-up Pump Data...
Page 43
2. ISO VG 32 OIL USED IN THE SEAL BOX 3. 275ml OIL QUANITY PUMP DISCHARGE 3" FLANGE 150# FF ASME / ANSI B16.5 OIL SIGHT GLASS PRODUCT LINE TYPE / FRAME HT-25 SCALE 0.250 DRAWN DATE 20-JUN-14 CHKD. DATE TITLE DRAWING NO.
Page 45
2. ISO VG 32 OIL USED IN THE SEAL BOX 3. 275ml OIL QUANITY PUMP DISCHARGE 3" FLANGE 150# FF ASME / ANSI B16.5 OIL SIGHT GLASS PRODUCT LINE TYPE / FRAME HT-25-MS SCALE 0.250 DRAWN DATE 01-MAY-17 CHKD. DATE TITLE DRAWING NO.
Page 46
2. ** = CRITICAL SPARE (0-2) YEARS) 29086 HT-25-575-60-MS 26416 26364 29112 HT-25-575-60-MS-HC 28939 28937 SEE TABLE 'A' STATOR, ROTOR, SHAFT UNIT, HT-25 SEE TABLE 'A' THERMAL PROTECTION, MOTOR 30305 ASSEMBLY, CABLE, HT-25,50, SHD-GC 26496 SCREW, CROSS RECESSED PAN HEAD 412000_STEEL_GRADE_A2_CLASS_70 26492 NUT, HEXAGON...
Page 47
ZONE CHANGE DESCRIPTION APPROVED DATE 393 (REF) NOTES: REVISED P/N 23965 MATERIAL AND 23999 DWG NO. A.P. 15 DEC 15 1. CONTINUOUS RUNNING WATER LEVEL (C.W.L.) REVISED TITLE, DRAWING NO. & TYPE/FRAME FROM HNS-5 TO HT-5, 172.9 2. ISO VG 32 OIL USED IN THE SEAL BOX CHANGED ITEMS 27 &...
Page 48
STATOR, ROTOR, SHAFT UNIT, HT-50 17.4 29616 HT-50-460-60-HC 28655 28654 SEE TABLE 'A' THERMAL PROTECTION, MOTOR 24656 HT-50-575-60 30306 ASSEMBLY, CABLE HT-25, 50 SOOW 26417 26367 29617 HT-50-575-60-HC 28655 28654 26496 SCREW, CROSS RECESSED PAN HEAD 412000_STEEL_GRADE_A2_CLASS_70 26494 SCREW, HEX HEAD, PT, CAP 412000_STEEL_GRADE_A2_CLASS_70 12.9...
Page 49
ZONE CHANGE DESCRIPTION APPROVED DATE 393 (REF) MODEL NAME WAS HT-5. ADDED 460V P/N AND CABLE ASSEMBLY P/N. 11-JUN-18 172.9 PUMP DISCHARGE 3" FLANGE 150# FF ASME / ANSI B16.5 OIL SIGHT GLASS SCALE 0.250 PRODUCT LINE TYPE / FRAME HT-50-MS SCALE 0.250...
Page 51
ZONE CHANGE DESCRIPTION APPROVED DATE 501 (REF) NOTES: REVISED DRAWING TO AS BUILT 20 JUL 15 1. CONTINUOUS RUNNING WATER LEVEL (C.W.L.) REVISED TITLE, DRAWING NO. & TYPE/FRAME FROM HNS-7.5 TO HT-7.5 4 JAN 16 AND ADDED CRITICAL/RECOMMENDED SPARES DESIGNATIONS 2.
Page 53
ZONE CHANGE DESCRIPTION APPROVED DATE 501 (REF) NOTES: REVISED MODEL NUMBER, WAS HT-7.5. ADDED CABLE ASSY P/N. 19 JUN 18 1. CONTINUOUS RUNNING WATER LEVEL (C.W.L.) 2. ISO VG 32 OIL USED IN THE SEAL BOX 3. 650ml OIL QUANTITY LIFTING EYE BOLTS DIN 580 C15 M12 30mm...
