IMPORTANT MANUAL
OWNER'S MANUAL
MODEL NUMBER:
P521
SNOW THROWER
Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
The use of any gasoline exceeding 10% ethanol (E10) will void the product warranty.
Always Wear Eye Protection During Operation
580 63 29-32 Rev. 2
09.11.12 SR
Do Not Throw Away
WARNING:
Read the Owner's Manual and
fol low all Warnings and Safety
In struc tions. Fail ure to do so
can result in serious injury.
Printed in the U.S.A.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P521 and is the answer not in the manual?

Questions and answers

Related Manuals for Poulan Pro P521

Summary of Contents for Poulan Pro P521

  • Page 1 WARNING: MODEL NUMBER: Read the Owner's Manual and fol low all Warnings and Safety P521 In struc tions. Fail ure to do so can result in serious injury. SNOW THROWER Gasoline containing up to 10% ethanol (E10) is acceptable for use in this machine.
