  • Page 1 First Edition 2016-03-05 Revised Edition 2023-03-30 Tip Changer KIKK-SG User’s Manual PLEASE RED THIS MANUAL CAREFULLY BEFORE USING THE DIVICE.
  • Page 2 INDEX Safety Precautions 1 Preparation 2 Parts Name 3 Parts List 4 Dimensions 5 Removing, Setting Procedure Method of Changing Magazine/Setting Tips 7 Replacing Method of Remover Unit 8 Replacing Method of Nail 9 Replacing Method of Bush 10 Replacing Method of Spring 11 Troubleshooting 12 Consumption Parts 13 How to Order...

  • Page 3: Handling Precautions

    ATTENTION TO SAFETY This Tip Changer, KIKK-SG, is designed to exchange damaged electrodes (hereinafter called tips) for new tips in car production line. Please do not use for any purpose other than described in this manual. We are not be able to take a responsibility for any damage or injury caused by results other than specified in this document.
  • Page 4 Be sure to protect air pipe from any kinds of damages. Damaged pipe could result in malfunction. Keep hands away from opening part during operation. May be a cause of injury. Do not insert metallic articles such as a pins or needles in rotating part or opening part during operation.
  • Page 5 Firmly fix this unit to stand. Unstable installation causes imbalance tip setting or accident. Remove alcohol or thinner properly after maintenance. The flying sparks can cause fires or explosions. CAUTION Protect air pipe from spatter. The flying spatter causes air leak due to melting pipe. Remove spatter which covers tip remover periodically.
  • Page 6 1. Preparations & Requirements ＜How to Set＞ ① Please set inside robot’s operating area. The attachment pitch of KIKK-SG is 58*70.（Please refer to the drawing below） ② Fix KIKK-SG by using 4×M8 bolts. ③ Please set air filter in the air supplying route.
  • Page 7 ＜Mandatory fixing for a shank and an adaptor＞ Make sure a shank and an adaptor are fixed well before removing a cap to achieve a proper cap removing. Adaptor Cap Tip Shank Taper Fit Taper Fit If it is hard to fix, take off an adaptor and a shank and hit the shank in to the adaptor with paying attention not to hurt the taper then restore it on a gun.

  • Page 8: Parts Name

    2. Parts Name Name Type Name KIKK-SG Body KIKK-SG** MG******MR-U Upper Magazine MG******MR-L Lower Magazine Sensor Pack (Option) KIKK-EL-SE-Pac ④ ④ ② ① ③ ④...

  • Page 9: Parts List

    3. Parts List Name Type Name Remarks Upper Body KIKK-SG-P-001 Lower Body KIKK-SG-P-002 Cylinder CDQ2B-63-75DCM-M9BA Remover Unit KIKK-SG-ReU-TYPE-** ** = Using tip diameter KIKK-SG-P-005U φ13/φ16 Upper Bush KIKK-SG-1920-P-005U φ19/φ20 KIKK-SG-P-005L φ13/φ16 Lower Bush KIKK-SG-1920-P-005L φ19/φ20 Spring 51-22100 Right Magazine Adapter...
  • Page 10 4. Dimensions ＜Weight＞ ・Gross weight 9.3kg 6.5kg ・Body 1.4kg/1 pcs ・Magazine...
  • Page 11 5. Removing/Setting Method Tip Setting Part (Upper) Tip Removing Part Tip Setting Part (Lower) ＜5.1 Cautions and Preparation before Operating＞ ① Make sure that the machine is fixed on stand tightly. ② Confirm the shank is joined tightly to the gun arm. ③...
  • Page 12 ④ After the robot has escaped and is not close to KIKK-SG, return the cylinder and release the tip. If the tip is released with the robot being close to KIKK-SG, the tip may hit the parts such as gun arm and scatter...
  • Page 13 ＜5.3 Upper Tip Setting Procedure＞ ① Move to the below position. The lower tip must be in a position where it is touching the magazine. Pressure from above to set the cap tip. ② The pressure must be from 100kgf~150kgf. ・When set under 100kgf : possibility of the tip to not be set properly.
  • Page 14 ＜5.4 Lower Tip Setting Procedure＞ ① Move to the below position. ② Insert the lower shank to the position where it is completely hidden. （Position witch the magazine is slightly lifted） ③ Pressure from above to set the cap tip. The pressure must be from 100kgf~150kgf.
  • Page 15 ④ Release both upper and lower at the same time and escape. Please escape with the magazine and the shank to be in a vertical position. （To prevent damage to the magazine and the tip.）...
  • Page 16 ◆please read below before going to the magazine/parts changing method. ・Please use protectors such as goggles and gloves. ・Please prevent KIKK-SG to operate by taking off the air hose or making the air not to flow when doing operation. ・Please be sure to follow the orders written above when doing the operation.
  • Page 17 6.1 Magazine Changing Method 1. Turn Off the air supply. 2. Turn the lever to【UNLOCK】（Left） 3. Pull the magazine off from the adapter. ※Caution not to damage the proximity sensor. 4. Set the spare magazine to the adapter. If there are no spare magazines, please charge tips to the using magazine. 5.
  • Page 18 6.2 Changing Magazine / Tip Changing Method 1. Turn the lever to 【UNLOCK】.（Left） 2. Pull the magazine off from the adapter. ※Caution not to damage the proximity sensor. 3. Please be careful of the tips facing way and charge one by one. Revolver Tip Holder 5.
  • Page 19 7. Replacing Method of Remover Unit ※ 「Medium Strength Loctite」is recommended as a slack preventing agent. 1. Remove the magazine by switching the lever from【LOCK】to【UNLOCK】. 2. Unscrew the 8 M6*25L cap bolts of the magazine adapter. ※The screwing torque when assembling must be 7.6N・m with loctite. 3.
  • Page 20 4. Unscrew the M6*25L cap bolts(7pcs) under the lower gear case. ※The screwing torque when assembling must be 7.6N・m with loctite. 5. Take off the upper gear case by unscrewing the M8*125L cap bolts (4pcs) of the cylinder. ※The screwing torque when assembling must be 18.5N・m with loctite. 6.
  • Page 21 7. Remove the E-ring and remove【Remove Shaft 4】 Remove Shaft 4 8. Remove the E ring and take off the【Remove Shaft 3】. Remove Shaft 3 9. Assemble the remover unit by doing the steps 1→8 in a reverse order. ※For changing nails, please refer to【8.0 Nail Changing Method】...
  • Page 22 Nail Changing Method ※ 「Medium Strength Loctite」is recommended as a slack preventing agent. Please finish the 【7.0 Replacement Method of Remover Unit】to process 9. 1. Pull off the φ6 pin and disassemble. 2. Unscrew the M4*15L cap bolts (1 pcs) and disassemble the nails. ※The screwing torque when assembling must be 3.0N・m with loctite.
  • Page 23 3. Unscrew the M3*10L cap bolts (6 pcs) and disassemble the nails. ※The screwing torque when assembling must be 1.0N・m with loctite. 4. To assemble a new nail , do steps 1→3 in a reverse order.
  • Page 24 9. Replacing Method of Bush ※ 「Medium Strength Loctite」is recommended as a slack preventing agent. Please finish the 【7.0 Replacement Method of Remover Unit】 to process 6 and confirm there are no parts inside of the gear case. 1. Unscrew the M4*10L cap bolts (10pcs.) witch are holding the bush to decompose. ※The screwing torque when assembling must be 3.0N・m with loctite.
  • Page 25 10. Replacing Method of Spring Please finish the 【7.0 Replacement Method of Remover Unit】to process 6. 1. Remove the “Spring Guide B” and replace the spring. Spring Guide B...

  • Page 26: Troubleshooting

    11. Troubleshooting TROUBLE Cause and Countermeasure Tip does not remove. ※Breakdown of a remover unit →Confirm the nails of remover unit and change it for new one. ※The spec of tip dia. And the remove unit does not match. →Please confirm the specification. ※The motion when removing is not proper.

  • Page 27: Consumption Parts

    12. Consumption Parts Nail Set Name ：KIKK-SG-N-**AB ※** = Using Tip Diameter （φ13 用 : KIKK-SG-N-13AB） （φ16 用 : KIKK-SG-N-16AB） （φ19 用 : KIKK-SG-N-19AB） （φ20 用 : KIKK-SG-N-20AB） ◆Needed Qty. ：1 Set ◆Replacing Cycle：2000times Upper Bush Name：KIKK-SG-P-005U （φ13/φ16 用） Name：KIKK-SG-1920-P-005U （φ19/φ20 用）...

  • Page 28: How To Order

    13. How To Order 【KIKK-SG Body】 Tip Dia. Type Name KIKK-SG13 φ13 KIKK-SG16 φ16 KIKK-SG19 φ19 KIKK-SG20 φ20 【Sensor Pack（Option）】 Type Name：KIKK-EL-SE-Pac...
  • Page 29 【Magazine】 ◆The available tip shapes are the listed below. For shapes not listed below, please contact our sales department. DR Shape R Shape C Shape Flat Shape Tip Diameter Tip Length (mm) Upper Magazine Type Name Lower Magazine Type Name MG131821MR-U MG131821MR-L 18～21...
  • Page 30 Contact Contact us if there is any damage or machine defects in our products. KYOKUTOH CO,. LTD 181-1, Nakayashiki, Orido-cho, Nisshin, Aichi 470-0115 Japan TEL +81-561-72-8811 FAX +81-561-72-8821 E-Mail: sales@kyokutoh.com http://www.kyokutoh.com SAITAMA Office TEL +81-49-277-4324 FAX +81-49-277-4325 KANAGAWA Office TEL +81-46-204-9260 FAX +81-46-204-9261...
