- Page 1 First edition, June 28, 2019. KIKK Teaching Guide Instruction Manual for Auto Tip Changer（TT-ATC-**） Please read this instruction manual carefully and use it correctly before using it. ※KIKK is sold separately.
- Page 2 Content 1. Precautions 2. Suitability Mode 3. How to use Contacts...
- Page 3 1. Precautions ※This product is different from the suitable product by the shape of the cap tip. If you work with a improper teaching guide, It cannot be performed. Please carry out the work after you check the suitability. ■ Precautions The teaching guide for KIKK auto tip changer is used to in our manufacturing tip changer, that it is easy to carry out teaching of robot gun.
- Page 4 2. Suitability Mode ■Line up The matching list of this product is as follows:...
- Page 5 3. How to use ■ Precautions before using ・Cap tip must be equipped with new products and operate. ・Check whether the robot is horizontal or vertical. ・Check the suitability for shape of cap tip and teaching guides. ・When operating a robot, make sure that there is no danger around it. ＜1.
- Page 6 3. Close the gun to the teaching guide. 4. Adjust horizontal and vertical and move directly on the center of the teaching guide.
- Page 7 5. Finely adjust and insert the cap tip into the teaching guide about 10mm. If it is inserted correctly, horizontal and vertical are adjusted. Make sure that the cap tip do not reach to the bottom. If it is continued to insert into the bottom, it may damage the product. Cross section 6.
- Page 8 7. After retreating, remove the teaching guide. 8. Insert the cap tip back into the center of the groove of remover, adjust the cap tip surface to parallel with the remover face ※Make sure that the two red sides of the picture on the right are parallel. Cross section ◆...
- Page 9 ＜2. Bottom teaching＞ ■ Work order 1. After finishing the top teaching, retract the gun to work on the bottom. 2. Check if the grooves are containment in the same way as above. 3. Install the teaching guide.
- Page 10 4. Finely adjust and insert the cap tip into the teaching guide about 10mm. If it is inserted correctly, horizontal and vertical are adjusted. 5. If it is inserted to the center, remove the teaching guide as above, Insert the cap tip again to parallel the surface of cap tip and remover. 6.
- Page 11 Contacts Contact us if there is any damage or machine defects in our products. KYOKUTOH CO., LTD 181-1, Nakayashiki, Orido-cho, Nisshin, Aichi 470-0115 Japan TEL +81-561-72-8811 FAX +81-561-72-8821 sales@kyokutoh.com E-Mail: http://www.kyokutoh.com KANTO SALES OFFICE TEL +81-49-277-4324 FAX +81-49-277-4325 HIROSHIMA SALES OFFICE TEL +81-82-569-6227 FAX +81-82-569-6228 CHANGER ＆...
