IMPORTANT NOTES
Before installation flush supply pipes and
ensure cistern is clean and free from debris.
No sealing compound, paste, flux or solvent
to be used in contact with plastic or rubber
surfaces to avoid damage. Rubber washers
will provide adequate seal. PTFE tape may
be used on threads. No chemical block/
additive to be used in this cistern.
Do not over-tighten plastic fasteners. Hand
tight + ¼ turn is recommended and should
provide an adequate seal.
1
2
VICTORIA MECHANICAL
WC FLUSH VALVE
3
4
5
25-32mm
FILL LEVEL
LESS
MORE
LESS
MORE
Advertisement
Related Manuals for Dudley VICTORIA MECHANICAL
Summary of Contents for Dudley VICTORIA MECHANICAL
- Page 1 VICTORIA MECHANICAL WC FLUSH VALVE IMPORTANT NOTES Before installation flush supply pipes and ensure cistern is clean and free from debris. No sealing compound, paste, flux or solvent to be used in contact with plastic or rubber surfaces to avoid damage. Rubber washers will provide adequate seal.
- Page 2 Installer to ensure cistern complies with UK water regulations. Visit www.tyde.co.uk for service & maintenance information. TYDE A Thomas Dudley Business 295 Birmingham New Road t +44 (0)121 557 5411 Dudley, West Midlands f +44 (0)121 557 5345 United Kingdom e info@tyde.co.uk...
- Page 3 VALVE MATE RETRO-FIT FLUSH VALVE ADAPTOR DISCARD CAGE *IMPORTANT Ensure valve is fully rotated anti-clockwise to dead stop to lock 374969...
