Dudley TURBO EDGE Manual

3-part adjustable syphon

Advertisement

Quick Links

IMPORTANT NOTES
Before installation flush supply pipes and
ensure cistern is clean and free from debris.
No sealing compound, paste, flux or solvent
to be used in contact with plastic or rubber
surfaces to avoid damage. Rubber washers
will provide adequate seal. PTFE tape may
be used on threads. No chemical block/
additive to be used in this cistern.
Do not over-tighten plastic fasteners. Hand
tight + ¼ turn is recommended and should
provide an adequate seal.
1a
NEW INSTALL
1b
RETRO-FIT
TURBO EDGE
3-PART ADJUSTABLE SYPHON
CLOSE
COUPLED
ONLY
!
DEBURR
CONTINUED...
2
W A T E R L E V E L

Advertisement

loading
Need help?

Need help?

Do you have a question about the TURBO EDGE and is the answer not in the manual?

Questions and answers

Summary of Contents for Dudley TURBO EDGE

  • Page 1 TURBO EDGE 3-PART ADJUSTABLE SYPHON CONTINUED... IMPORTANT NOTES Before installation flush supply pipes and ensure cistern is clean and free from debris. No sealing compound, paste, flux or solvent to be used in contact with plastic or rubber surfaces to avoid damage. Rubber washers will provide adequate seal.
  • Page 2 Visit www.tyde.co.uk for service & maintenance information. HIGH Only ‘C’ OPEN MAX. All positions CLOSED TYDE A Thomas Dudley Business 295 Birmingham New Road t +44 (0)121 557 5411 Dudley, West Midlands f +44 (0)121 557 5345 United Kingdom e info@tyde.co.uk w www.thomasdudley.co.uk/tyde...
