- Page 1 Remora Pneumatic Stainless Steel Push Button Instructions 0121 557 5411 0121 557 5345 sales@thomasdudley.co.uk www.thomasdudley.co.uk Thomas Dudley Ltd P.O.Box 28 Birmingham New Road Dudley West Midlands DY1 4SN © 2016 Thomas Dudley Ltd 12990 iss A (R330123)
- Page 2 Pack Contents Step 3A Step 3B 10 - 30mm Furniture 30 - 48mm Furniture Button Assembly Step 1 Connect Connect Air Tube Air Tube Mark hole(s). See minimum hole centres for dual ush applications. 56mm MINIMUM Note: Cut air tubes to a minimum working length and avoid kinks Dual Flush Applications For dual ush applications the air tubes must be tted in the following orientation...
