Cabinet and Rack Installation
Warning
Note
To install the switch on top of the shelf brackets, follow these steps:
Step 1
Verify that the shelf brackets are level and securely attached to the rack-mounting rails, the crossbar is securely attached
to the shelf brackets, and the rack is stabilized.
Step 2 Slide the switch onto the shelf brackets, ensuring that it is squarely positioned.
Step 3
Attach the switch to the rack-mounting rails.
Caution We recommend grounding the chassis, even if the rack is already grounded. A grounding pad with two
threaded M4 holes is provided on the chassis for attaching a grounding lug.
The grounding lug must be NRTL listed and compatible with copper conductors. Only copper conductors
Note
(wires) must be used and the copper conductor must comply with National Electrical Code (NEC) for
ampacity.

Removing the Shelf Bracket Kit (Optional)

The shelf bracket kit can be removed after the Cisco MDS 9396S switch has been installed in a four-post EIA
rack, and both front rack-mount brackets and both C brackets are securely attached to the rack-mounting rails.
To remove the shelf bracket kit, follow these steps:
Step 1 Remove the screws fastening the slider brackets to the rear rack-mounting rails, and then slide the slider brackets out of
the shelf brackets.
Step 2 Remove the screws fastening the crossbar to the shelf brackets, and then remove the crossbar.
Step 3
Remove the screws fastening the shelf brackets to the front rack-mounting rails and remove the shelf brackets from the
rack.
Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Before you install, operate, or service the system, refer to the Regulatory Compliance and Safety Information
for the Cisco MDS 9000 Family for important safety information.
