Each selection has an individual motor and operates independently from other motors. VendNet™ Each vendor can support a “satellite” vending P. O. Box 488 machine, such as a Can Vendor, Food 165 North 10th Street Merchandiser, or Can/Bottle Vendor.
SPECIFICATIONS Remove the two retaining blocks from the shipping pallet. See Figure 1A. Slide the vendor General forward on the pallet until the side legs are clear Height 71-1/2 inches 182 cm of the pallet. See Figure 1B. Tilt the machine Depth 36-1/2 93 cm...
INSTALLATION Grounding & Electrical Position the vendor no further than nine feet Prior to connecting the equipment, the integrity (2.74 meters) from the power outlet or receptacle of the main electrical supply must be checked for and check that the door will open fully without correct polarity, presence of ground and correct interference.
COIN MECHANISM The coin mechanism pays out nickels, dimes and quarters from self-loading, high capacity change (Applies to U.S. currency coin mechanisms only) tubes in the least number of coins available. Load the coin changer coin tubes with nickels, CAUTION: dimes and quarters.
3. Locate the coin changer option dip switches DOLLAR BILL VALIDATOR and select from the following settings: (Available in certain U.S. currency markets only) Table 2. Coin Mech Option Switches The BA32SA bill validator contains an option switch module allowing the unit to be SWITCH customized to the requirements of an individual U.S.
If you desire settings different from those set at the factory, follow the steps outlined below: 1. Turn off the power switch in the center right side of the cabinet. See Figure 5. WARNING: To avoid electrical shock, always disconnect the power before performing service.
CAUTION: Do not use any petroleum based cleaning solvents, scouring pads or stiff brushes for cleaning. Figure 9 LOADING PRODUCTS Figure 8 To load products, lift tray slightly and pull forward until the tray stops. The upper-most Table 4. Validator Diagnostic Codes trays will tilt for ease of loading.
CHANGING TIMING AND TRAY SPACING Difficult-to-vend items can be dispensed more dependably by retiming the augers. Larger items can be vended by altering tray spacing. Timing Each auger can be rotated in 20-degree increments for a different drop-off point. Most items can be vended successfully when the auger end is positioned at 6 o'clock.
Figure 12 Figure 13 Tray Spacing 7. Pull each rail forward to disengage its rear tab from the hole in the rear wall. See Figure 14. The trays can be raised or lowered in one inch 8. Relocate both left and right rails by reversing increments to provide additional headroom for steps 6 and 7.
9. Replace the tray by placing its rear rollers on CONTROLLER FUNCTIONS the left and right rails and lifting up on the front of the tray as you push it back. Sales Mode 10. Install the tray plug into its receptacle on the The Sales Mode is the normal operating mode of right side wall.
• If an item is selected and the vendor is unable Service Mode to complete the vend cycle, the “MAKE ANOTHER SELECTION” LED will flash for To change any settings and retrieve diagnostic three seconds or until a new selection key is information, the controller must be placed in the pressed.
Displayed Errors Programming the Controller Motor Configuration Errors To access the programming, enter the Service Mode, then choose from the following modes. When the controller is placed in the Service Mode, if any errors were detected during a vend, Table 6. Modes the failed motors display.
Page 15
functional motors displays; individual selection Price Setting Mode numbers do not display. A vend price must be set for each selection. The Press the Service Mode Button, then press <2>. price programmed must match the desired item controller tests each motor and price scroll.
Page 16
Test Vend All Motors Mode Test Vend Single Motor Mode All selections can be tested to verify that they are CAUTION: functioning properly. The controller will check Because this vendor utilizes DC motors, do the motor circuits and run each selection, starting not attempt to turn the helix manually or with the first motor in the first row.
Press the Service Mode Button, then press <E>. Vend Options Mode Optn displays. Various sales options can be enabled and To exit the Vend Options Mode, press a different disabled through this option. See Table 8. function key, or press the Service Mode Button. Table 8.
If you have any questions, check out our Website http:\\www.vendnetusa.com or please call VendNet™. Ask for the Parts Department. We will be happy to assist you. Email: VendNet@Ecity.net...
